LS 703 ML 620 ID.-NR. 336976-09 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH: 620 MM, ACCURACY GRADE: +/- 0,005 MM, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNALS: SINUSOIDAL (11 UASS), REFERENCE MARKS: ONE REFERENCE MARK AT MID- POINT OF MEASURING LENGTH MOVEABLE BY 50 MM STEPS, ELECTRICAL CONNECTION: VIA ADAPTER CABLE

LS 703 ML 720 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 703 ML 720 ID.-NR. 336976-10 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH: 720 MM, ACCURACY GRADE: +/- 0,005 MM, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, REFERENCE MARKS: ONE REFERENCE MARK AT MID- POINT OF MEASURING LENGTH MOVEABLE BY 50 MM STEPS, ELECTRICAL CONNECTION: VIA ADAPTER CABLE

LS 703 ML 720 ID.-NR. 216750-NE HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 720, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBEL, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 0 NONE, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CALBLE LENGTH 3,00 M

LC 195S ML 240 ID.NR. 760912-03 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 240 MM ACCURACY GRADE: 5.0 µM, FASTENING TYPE: SCREW-ON STRIP INTEGRATED, DATA INTERFACE: DQ01 DRIVE-CLIQ ENCODER INTERFACE DQ01, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 703 ML 720 ID.-NR. 216750-3E HEIDENHAIN INCRMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 720, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11µAPP), REFERENCE MARK POSITION 60, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 720 ID.-NR. 216750-0E HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 720, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µ APP), REFERENCE MARK POSITION 360, ELECTRICAL CONNECTION 31S09 CONNECTOR MALE 9-PIN W/ METAL ARMOR, CABLE LENGTH 3,00 M

LS 703 ML 720 ID.-NR. 216750-N2 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 720, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 10, FURTHER REFERENCE MARK POSITION N50, ELECTRICAL CONNECTION 34S09 FLANGE SOCKET MALE 9-PIN ON CONNECTION FIXTURE, CABLE LENGTH 0,30 M

LS 703 ML 720 ID.-NR. 216750-38 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 720, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCKS FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 610, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 720 ID.-NR. 216750-38 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 720, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11µAPP), REFERENCE MARK POSITION 360, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 770 ID.-NR. 216750-3A HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 770, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 635, ELECTRICAL CONNECTION 02S09 CONECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 770 ID.-NR. 216750-FM HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 770, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 385, ELECTRICAL CONNECTION 34S09 FLANGE SOCKET MALE 9-PIN ON CONNECTION FIXTURE, CABLE LENGTH 0,30 M

LS 703 ML 770 ID.-NR. 336976-11 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH: 770 MM, ACCURACY GRADE: +/- 0,005 MM, FASTENING TYPE: R RIGHT END BLOCK FLEXIBLE, REFERENCE MARKS: ONE REFERENCE MARK AT MID- POINT OF MEASURING LENGTH MOVEABLE BY 50 MM STEPS, ELECTRICAL CONNECTION: VIA ADAPTER CABLE

LS 703 ML 920 ID.-NR. 336976-13 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH: 920 MM, ACCURACY GRADE: +/- 0,005 MM, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNALS: SINUSOIDAL (11 UASS), REFERENCE MARKS: ONE REFERENCE MARK AT MID- POINT OF MEASURING LENGTH MOVEABLE BY 50 MM STEPS, ELECTRICAL CONNECTION: VIA ADAPTER CABLE

LC 481 ML 1020    ID.NR. 327300-11 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 1020 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 704 ML 1140 HEIDENHAIN INCRMENTAL SEALED LINEAR ENCODER

LS 704 ML 1240 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 704 ML 220 ID.-NR. 336978-C3 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH: 220 MM, ACCURACY GRADE: +/- 0,005 MM, FASTENING TYPE: B END BLOCK, OUTPUT SIGNALS:: SINUSOIDAL ELECTRIC SIGNALS (11 UASS), REFERENCE MARK: EVERY 50 MM STARTING FROM MIDPOINT OF MEASURING LENGTH, AVAILABLE WITH ADD. SELECTOR MAGNETS, ELECTRICAL CONNECTION: VIA ADAPTER CABLE

LS 704 ML 270 ID.-NR. 237133-BB HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 270, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11µAPP), REFERENCE MARK POSITION 35, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 704 ML 270 ID.-NR. 237133-C4 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 270, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11µAPP), REFERENCE MARK POSITION 135, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE

LS 704 ML 320 ID.-NR. 237133-43 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 320, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 160, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 704 ML 320 ID.-NR. 237133-BC HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 320, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 260, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 704 ML 320 ID.-NR. 237133-C6 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 320, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 160, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE

LS 704 ML 370 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 704C ML 920 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LC 495S ML120 ID.-NR. 760938-02 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 120 MM, TOTAL LENGTH: ML+138 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 706 ML 320 ID.-NR. 295703-14 HEIDENHAIN INKREMENTALES GEKAPSELTES LÄNGENMESS-SYSTEM MIT ERHÖHTER VIBRATIONSBELASBARKEIT MESSLÄNGE: 320 MM, GENAUIGKEITSKLASSE: 5,0, BEFESTIGUNGSART B ENDSTÜCKE, AUSGANGSSIGNALE: SINUSFÖRMIGE STROMSIGNALE (11 UASS), REFERENZMARKENLAGE: 160, ELEKTRISCHER ANSCHLUSS: 52S12 SEPARATES ADAPTERKABEL

LS 706 ML 420 ID.-NR. 336965-16 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER HIGH VIBRATION RATING MEASURING LENGTH: 420 MM, ACCURACY: +/- 0,005 MM, FASTENING TYPE: B END BLOCK, OUTPUT SIGNALS: SINUSOIDAL (11 UASS ), REFERENCE MARKS: Z=210MM FURTHER REFERENCE MARKS AVAILABLE EVERY 50MM, SELECTABLE VIA MAGNET, ELECTRICAL CONNECTION: VIA ADAPTER CABLE

LS 803 ML 320 ID.-NR. 204418-86 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 320 MM ACCURACY GRADE: 10.0 µM, FASTENING TYPE: END BLOCK OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (25 µAPP) REFERENCE MARK POSITION:35 MM, FURTHER REFERENCE MARK POSITION 250 MM, ELECTRICAL CONNECTION: CONNECTOR, MALE 9-PIN (BLANK), CABLE LENGTH: 3.00 M

LC 193F ML 340 ID.-NR. 557665-03 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 340 MM ACCURACY GRADE: 3.0 µM, FASTENING TYPE: SCREW-ON STRIP INTEGRATED, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 803 ML 420 ID.-NR. 204418-B9 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 420 MM ACCURACY GRADE: 10.0 µM, FASTENING TYPE: END BLOCK, OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (25 µAPP) REFERENCE MARK POSITION:210 MM, ELECTRICAL CONNECTION: CONNECTOR, MALE, 9-PIN (BLANK) WITH ARMOR, CABLE LENGTH: 3.00 M

LS 803 ML 420 ID.-NR. 204418-0L HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 420 MM ACCURACY GRADE: 10.0 µM, FASTENING TYPE: END BLOCK OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (25 µAPP) REFERENCE MARK POSITION:35 MM, FURTHER REFERENCE MARK POSITION. 350 MM, ELECTRICAL CONNECTION: FREE CABLE END, CABLE LENGTH: 3.00 M

LS 803 ML 420 ID.-NR. 204418-9P HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 420, ACCURACY GRADE 10,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 15:::35APP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 60, FURTHER REFERENCE MARK POSITION 200, ELECTRICAL CONNECTION 37S09 CONNECTOR MALE 9-PIN (METAL HOUSING), CABLE LENGTH 6,00 M

LS 803D ML 320 ID.-NR. 209089-73 HEIDENHAIN INCRMENTAL SEALED LINEAR ENCODER MEASEURING LENGTH 320, ACCURACY GRADE 10,0, FASTENING TYPE B END BOCK, OUTPUT SIGNAL 15:::35µAPP, REFERENCE MARK POSITION 35, REFERENCE MARK POSITION 2 250, ELECTRICAL CONNECTION 37S09 CONNECTOR MALE 9-PIN (METAL HOUSING), CABLE LENGTH 0,65 M

LS 903 ML 220 ID.-NR. 209081-1X HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 220 MM ACCURACY GRADE: 3.0 µM, FASTENING TYPE: END BLOCK OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION:35 MM, REFERENCE MARK POSITION 2: 150 MM, ELECTRICAL CONNECTION: CONNECTOR, MALE, 9-PIN (BLANK) WITH ARMOR, CABLE LENGTH: 3.00 M

LS 903 ML 270 ID.-NR. 209081-4V HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 270 MM ACCURACY GRADE: 5.0 µM, FASTENING TYPE: END BLOCK OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION:35 MM, REFERENCE MARK POSITION 2: 200 MM, ELECTRICAL CONNECTION: CONNECTOR, MALE 9-PIN ON MOUNTING BASE, CABLE LENGTH: 0,30 M

LS 477 ML 170    ID.NR. 605379-14 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 170 MM TOTAL LENGTH: ML+138 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SQUARE-WAVE SIGNALS, TTL LEVELS WITH 10-FOLD INTERPOLATION REFERENCE MARK POSITION:35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH FURTHER REFERENCE MARKS:35 MM DISTANCE FROM END OF MEASURING LENGTH, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 477 ML 270    ID.NR. 605379-28 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 270 MM TOTAL LENGTH: ML+138 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SQUARE-WAVE SIGNALS, TTL LEVELS WITH 10-FOLD INTERPOLATION REFERENCE MARK POSITION:35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH FURTHER REFERENCE MARKS:35 MM DISTANCE FROM END OF MEASURING LENGTH, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 903 ML 770 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 186C ML 1240 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 405 ML 316 ID.-NR. 245100-24 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 316 MM, ACCURACY GRADE 3,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 133, REFERENCE MARK POSITION 2 250, ELECTRICAL CONNECION 31S09 CONNECTOR MALE 9-PIN METAL ARMOR, CABLE LENGTH 3,00 M

LS 486C ML 420 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCOER

LS 623 ML 370 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 903 ML 120 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 903 ML 920 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 703 ML 370 ID.-NR. 216750-74 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 370, ACCURACY GRADE 5,0, FASTENING TYPE  RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 185, ELECTRICAL CONNECTION 31S09 CONNECTOR MALE 9-PIN W/ METAL ARMOR, CABLE LENGTH 3,00 M

LS 487C ML 1340 ID.-NR. 572248-20 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1340 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:C001 - DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 481 ML 70 ID.-NR. 353703-05 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 70 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LC 481 ML 320 ID.NR. 353703-14 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 320 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 403C ML 470 ID.-NR. 233191-22 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M
