LC 183 ML 1440 ID.-NR. 557680-14 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 1440 MM ACCURACY GRADE: 3.0 µM, FASTENING TYPE: SCREW-ON STRIP INTEGRATED DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 513D ML 420 ID.-NR. 217394-66 HEIDENHAIN INCREMETNAL SEALED LINEAR ENCODER MEASURING LENGTH LENGTH 420, ACCURACY GRADE 10,0, FASTENING TYPE W MOUNTING BRACKET, OUTPUT SIGNAL TTLX1 SQUARE-WAVE SIGNALS, REFERENCE MARK POSITION 210, ELECTRICAL CONNECTION 02S12 CONNECTOR MALE 12-PIN, CABLE LENGTH 3,00 M

LS 603 ML 170 ID.-NR. 316558-34 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 170 MM ACCURACY GRADE: ± 10.0 µM, FASTENING TYPE: MOUNTING BRACKET OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION: 85 ML/2, ELECTRICAL CONNECTION: CONNECTOR, MALE, 9-PIN WITH ARMOR

LS 623 ML 170 ID.-NR. 336974-01 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 170, ACCURACY GRADE 10,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL TTLX1 SQUARE-WAVE SIGNALS, TTL LEVELS WITH 1-FOLD INTERPOLATION, REFERENCE MARK POSITION ML/2 IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION 02S12 CONNECTOR MALE 12-PIN, CABLE LENGTH 3,00 M

LS 623 ML 170 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 703 ML 1140 ID.-NR. 336976-15 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH: 1140 MM, ACCURACY GRADE: +/- 0,005 MM, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNALS: SINUSOIDAL (11 UASS), REFERENCE MARKS: ONE REFERENCE MARK AT MID- POINT OF MEASURING LENGTH MOVEABLE BY 50 MM STEPS, ELECTRICAL CONNECTION: VIA ADAPTER CABLE

LS 703 ML 1140 ID.-NR. 216750-15 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1140, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 570, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 1240 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 703 ML 1240 ID.-NR. 316562-50 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1240, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 1195, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE

LS 903 ML 770 ID.-NR. 209081-B4 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 770, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 635, ELECTRICAL CONNECTION 37S09 CONECTOR MALE 9-PIN (METAL HOUSING), CABLE LENGTH 3,00 M

LS 701 ML 420 ID.-NR. 203263-67 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 420, ACCURACY GRADE 3,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 210, ELECTRICAL CONNECTION 37S09 CONNECTOR MALE 9-PIN (METAL HOUSING), CABLE LENGTH 3,00 M

LS 701 ML 420 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 701 ML 420 ID.-NR. 203263-E8 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 420, ACCURACY GRADE 3,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 210, ELECTRICAL CONNECTION 38S09 CONNECTOR MALE 9-PIN (METAL HOUSING) WITH ARMOR, CABLE LENGTH 3,00 M

LS 703 ML 1340 ID.-NR. 216750-17 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1340, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 670, ELECTRICAL CONNECTION 02S09 CONNECTOR, MALE 9-PIN, CABLE LENGTH 3,00 M

LS 487C ML 220 ID.-NR. 572248-04 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 220 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:C001 - DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 703 ML 1440 ID.-NR. 216750-M5 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1440, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 720, ELECTRICAL CONNECTION 34S09 FLANGE SOCKET MALE 9-PIN ON CONNECTION FIXTURE, CABLE LENGTH 0,30 M

LS 703 ML 1440 ID.-NR. 216750-18 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1440, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 720, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 1440 ID.-NR. 336976-18 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH: 1440 MM, ACCURACY GRADE: +/- 0,005 MM, FASTENING TYPE: R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNALS: SINUSOIDAL (11 UASS), REFERENCE MARKS: ONE REFERENCE MARK AT MID- POINT OF MEASURING LENGTH MOVEABLE BY 50 MM STEPS, ELECTRICAL CONNECTION: VIA ADAPTER CABLE

LS 703 ML 170 ID.-NR. 336976-29 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 170, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 85, ELECTRICAL CONNECTION 02S09 55S08 SEPARATE ADAPTER CABLE

LC 483 ML 270 ID.-NR. 557653-09 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 270 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 703 ML 2040 ID.-NR. 216750-GY HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 2040, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 20, ELECTRICAL CONNECTION 02S09 CONNECTOR, MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 220 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 703 ML 220 ID.-NR. 316562-02 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 220, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 110, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE

LS 703 ML 220 ID.-NR. 216750-6V HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 220, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 40, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 220 ID.-NR. 216750-7L HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 220, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 210, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN; CABLE LENGTH 3,00 M

LS 703 ML 220 ID.-NR. 216750-MS HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 220, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBEL, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 160, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS703 ML 270 ID.-NR. 316562-03 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 270, ACCURACY GRADE 5,0, FASTENING TYPE RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 135, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE

LS 703 ML 270 ID.-NR. 216750-UW HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 270, ACCURACY GRADE 3,0, FASTENING TYPE F RIGID END BLOCKS, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 135, ELECTRICAL CONNECTION 31S09 CONNECTOR MALE 9-PIN W/METAL ARMOR, CABLE LENGTH 3,00 M

LS 703 ML 270 ID.-NR. 216750-03 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 270, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 135, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 270 ID.-NR. 216750-31 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 270, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 135, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 290 ID.-NR. 216750-YH HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 290, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 45, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 320 ID.-NR. 316562-48 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 320, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 15, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE

LS 703 ML 320 ID.-NR. 336976-72 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 320, ACCURACY GRADE 3,0, FASTENING TYPE F RIGID END BLOCKS, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 160, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE

LS 703 ML 320 ID.-NR. 336976-32 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 320, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 160, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE

LS 703 ML 370 ID.-NR. 216750-74 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 370, ACCURACY GRADE 5,0, FASTENING TYPE  RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 185, ELECTRICAL CONNECTION 31S09 CONNECTOR MALE 9-PIN W/ METAL ARMOR, CABLE LENGTH 3,00 M

LS 703 ML 370 ID.-NR. 216750-05 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 370, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 185, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN CABLE LENGTH 3,00 M

LS 703 ML 420 ID.-NR. 216750-06 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 420, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 210, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 420 ID.-NR. 216750-VV HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 420, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11µAPP), REFERENCE MARK POSITION 360, ELECTRICAL CONNECTION 34S09 FLANGE SOCKET MALE 9-PIN ON CONNECTION FIXTURE, CABLE LENGTH 0,30 M

LS 703 ML 420 ID.-NR. 216750-NT HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 420, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 210, ELECTRICAL CONNECTION 34S09 FLANGE SOCKET MALE 9-PIN ON CONNECTION FIXTURE, CABLE LENGTH 0,30 M

LS 703 ML 470 ID.-NR. 216750-98 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11 µAPP SINUSOIDAL CURRENT SIGNALS (11µAPP), REFERENCE MARK POSITION 235, ELECTRICAL CONNECTION 31S09 CONNECTOR MALE 9-PIN W/ METAL ARMOR, CABLE LENGTH 3,00 M

LS 703 ML 470 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 703 ML 470 ID.-NR. 216750-07 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY GRADE 5,0, FASTENING TYPE  RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 235, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 520 ID.-NR. 336976-08 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 520, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 260, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE

LS 703 ML 520 ID.-NR. 216750-0A HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 520, ACCURACY GRADE 5,0, FASTENING TYPE RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11µ APP), REFERENCE MARK POSITION 260, ELECTRICAL CONNECTION 31S09 CONNECTOR MALE 9-PIN W/ METAL ARMOR, CABLE LENGTH 3,00 M

LS 703 ML 520 ID.-NR. 316562-08 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 520, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11µAPP), REFERENCE MARK POSITION 260, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE

LS 703 ML 620 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 703 ML 620 ID.-NR. 216750-6Z HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 620, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 560, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 620 ID.-NR. 216750-0C HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 620, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 310, ELECTRICAL CONNECTION 31S09 CONNECTOR MALE 9-PIN W/ METAL ARMOR, CABLE LENGTH 3,00 M

LS 703 ML 620 ID.-NR. 216750-2L HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 620, ACCURACY GRADE 3,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 50, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 703 ML 620 ID.-NR. 216750-5L HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 620, ACCURACY GRADE 5,0, FASTENING TYPE R RIGHT END BLOCK FLEXIBLE, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 610, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M
