LC 485 ML 870 ID.NR. 689681-17 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH: 870 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR END BLOCK: 14A, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), OUTPUT CODE: DUAL, DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 603 ML 770 ID.-NR. 336972-6Y HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH: 770 MM, ACCURACY GRADE: ± 10.0 µM, FASTENING TYPE: MOUNTING BRACKET, OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION: IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 487C ML 420 ID.-NR. 572249-08 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 420 MM ACCURACY GRADE: ± 5.0 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:C001 - DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD POWER SUPPLY: 5 V (+-5 %) ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 195F ML 2440 ID.-NR. 760905-21 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 2440 MM ACCURACY GRADE: 3.0 µM FASTENING TYPE: SCREW-ON STRIP INTEGRATED DATA INTERFACE: FANUC05 SERIAL INTERFACE FANUC ALPHA/ALPHAI ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LF 485C ML 350 ID.-NR. 635327-07 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR HIGHEST REPEATABILITY, MEASURING LENGTH 350 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE, SIGNALS (1 VPP), REFERENCE MARK POSITION: DISTANCE-CODED REFERENCE,  MARKS WITH NOMINAL INCREMENT 5000 X SIGNAL PERIOD, ELECTRICAL CONNECTION:   FLANGE SOCKET, MALE, 14-PIN

LC 495F ML 720 ID.-NR. 760933-14 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 720 MM ACCURACY GRADE: ± 5.0 µM GRATING PERIOD: 20.000 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR END BLOCK: 14A OUTPUT SIGNAL: NO SPECIFIED VALUE OUTPUT CODE: DUAL DATA INTERFACE: FANUC05 SERIAL INTERFACE FANUC ALPHA/ALPHAI ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 195S ML 340 ID.-NR. 760916-03 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 340 MM ACCURACY GRADE: 5.0 µM FASTENING TYPE: SCREW-ON STRIP INTEGRATED DATA INTERFACE: DQ01 DRIVE-CLIQ ENCODER INTERFACE DQ01 ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN SAFETY CONCEPT: FOR APPLICATIONS UP TO SIL

LC 495S ML 520 ID.-NR. 760938-10 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 520 MM ACCURACY GRADE: ± 5.0 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR END BLOCK: 12A OUTPUT SIGNAL: NO SPECIFIED VALUE OUTPUT CODE: DUAL DATA INTERFACE: DQ01 DRIVE-CLIQ ENCODER INTERFACE DQ01 ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 495S ML 420 ID.-NR. 760942-08 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 420 MM ACCURACY GRADE: ± 5.0 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR END BLOCK: 12A OUTPUT SIGNAL: NO SPECIFIED VALUE OUTPUT CODE: DUAL DATA INTERFACE: DQ01 DRIVE-CLIQ ENCODER INTERFACE DQ01 ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN SAFETY CONCEPT: FOR APPLICATIONS UP TO SIL

LS 303 ML 270 ID.-NR. 228975-2D HEIDENHAIN EALED LINEAR ENCODER GRATING PITCH 0,020MM REFERENZMARK AT Z= 35MM, Z1= 200MM CABLE LENGTH ??,00M, WITHOUT CONNECTOR WITHOUT ARMOR MEASURING LENGTH 270MM

LS 487C ML 620 ID.-NR. 572249-12 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMAL CROSS SECTION MEASURING LENGTH: 620 MM, TOTAL LENGTH: ML+105 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION:C001 - DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 193F ML 1540 ID.-NR. 557676-15 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH: 1540 MM, ACCURACY GRADE: 5.0 µM, FASTENING TYPE: SCREW-ON STRIP INTEGRATED, DATA INTERFACE: FANUC02 SERIAL INTERFACE, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 495F ML 1740 ID.-NR. 760932-25 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1740 MM ACCURACY GRADE: ± 5.0 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR END BLOCK: 12A OUTPUT SIGNAL: NO SPECIFIED VALUE OUTPUT CODE: DUAL DATA INTERFACE: FANUC05 SERIAL INTERFACE FANUC ALPHA/ALPHAI ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 195F ML 1040 ID.-NR. 760905-10 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 1040 MM ACCURACY GRADE: 3.0 µM FASTENING TYPE: SCREW-ON STRIP INTEGRATED DATA INTERFACE: FANUC05 SERIAL INTERFACE FANUC ALPHA/ALPHAI POWER SUPPLY: 3.6 V ... 14 V ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 403 ML 120 ID.-NR. 334755-34 HEIDENHAIN SEALED LINEAR ENCODER POWER SUPPLY: +5 V OUTPUT SIGNALS: SINUSOIDAL POWER SIGNALS (11 µASS) REFERENCE MARK: Z = 35 MM, Z1 = 50 MM ELECTRICAL CONNECTION: CABLE 3 M WITH CONNECTOR WITH ARMOR MEASURING LENGTH: 120 MM

LC 485 ML 1840 ID.-NR. 689681-26 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1840 MM, TOTAL LENGTH: ML+105 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 485 ML 570 ID.-NR. 689678-11 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 570 MM ACCURACY GRADE: ± 3.0 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR END BLOCK: 12A OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) OUTPUT CODE: DUAL DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 487C ML 470 ID.-NR. 572248-09 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 470 MM ACCURACY GRADE: ± 5.0 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:C001 - DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD FURTHER REFERENCE MARKS:NONE ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 487 ML 1020 ID.-NR. 572250-17 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1020 MM ACCURACY GRADE: ± 5.0 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH FURTHER REFERENCE MARKS:35 MM DISTANCE FROM THE END OF THE MEASURING LENGTH POWER SUPPLY: 5 V (+-5 %) ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 115 ML 840 ID.-NR. 689690-08 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 840 MM, FASTENING TYPE: SCREW-ON STRIP INTEGRATED, ELECTRICAL CONNECTION:  FLANGE SOCKET, MALE, 14-PIN

LS 487 ML 120 ID.-NR. 572250-02 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH: 120 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION:35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH, FURTHER REFERENCE MARKS:35 MM DISTANCE FROM THE END OF THE MEASURING LENGTH, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 495S ML 720 ID.-NR. 760942-14 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 720 MM TOTAL LENGTH: ML+138 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: NO SPECIFIED VALUE, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 107C ML 1740 ID.-NR. 244860-22 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1740 MM

LS 107C ML 3040 ID.-NR. 264070-1A HEIDENHAIN SEALED LINEAR ENCODER GRATING PITCH 0,020 MM WITH DISTANCE-CODED REFERENCE MARKS WITHOUT CABLE AND LID FOR MOUNTING BLOCK MEASURING LENGTH 3040 MM

LS 704 ML 2040 ID.-NR. 237133-15 HEIDENHAIN SEALED LINEAR ENCODER SURING LENGTH 2040MM,  CCURACY GRADE +/-0,005MM, REFERENCE MARK AT Z= 1020MM, CABLE LENGTH 3,00M, WITH CONNECTOR, WITHOUT ARMOR

LC 185 ML 2040 ID.-NR. 689701-18 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 2040 MM, ACCURACY GRADE: 5.0 µM, FASTENING TYPE: SCREW-ON STRIP INTEGRATED, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 513 ML 220 ID.-NR. 217393-02 HEIDENHAIN INCREMETNAL SEALED LINEAR ENCODER MEASURING LENGTH 220 MM

LS 623 ML 220 ID.-NR. 228861-03 HEIDENHAIN INCREMENTAL ENCLOSED LENGTH MEASURING SYSTEM WITH BUILT-IN DIGITIZING ELECTRONICS MEASURING LENGTH 220, ACCURACY CLASS +/- 0.010, REFERENCE MARK POSITION 110, CABLE LENGTH 3.00 M WITH PLUG

LS 513 ML 220 ID.-NR. 217393-65 HEIDENHAIN INCREMETNAL SEALED LINEAR ENCODER

LS 704C ML 720 ID.-NR. 237134-15 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH: 720 MM

LS 107 ML 940 ID.-NR. 264069-1M HEIDENHAIN SEALED LINEAR ENCODER ACCURACY GRADE +/-0,005MM REFERENCE MARK AT Z= 470 MM, CABLE LENGTH 3,00M, WITH CONNECTOR, WITHOUT ARMOR, MEASURING LENGTH 940 MM

LS 328C ML 370 ID.-NR. 559682-36 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL  CROSS SECTION MEASURING LENGTH: 370 MM TOTAL LENGTH:  ML+105 MM, ACCURACY GRADE: ± 10.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SQUARE-WAVE SIGNALS, TTL LEVELS, REFERENCE MARK POSITION:DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION:  FLANGE SOCKET, MALE, 14-PIN

LS 328C ML 1240 ID.-NR. 559682-51 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL  CROSS SECTION MEASURING LENGTH:1240 MM, TOTAL LENGTH: ML+105 MM, ACCURACY GRADE: ± 10.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SQUARE-WAVE SIGNALS, TTL LEVELS, REFERENCE MARK POSITION:DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 493F ML 820 ID.-NR. 557642-16 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 820 MM ACCURACY GRADE: ± 5.0 µM FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: NO SPECIFIED VALUE OUTPUT CODE: DUAL DATA INTERFACE: FANUC02 SERIAL INTERFACE ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 415 ML 920 ID.-NR. 689675-18 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 920 MM, TOTAL LENGTH: ML+105 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR END BLOCK: 14A, OUTPUT SIGNAL: NO SPECIFIED VALUE, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 485 ML 620 ID.-NR. 689680-12 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH: 620 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR END BLOCK: 12A, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS, (1 VPP), ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LB 326 ML 1240 ID.-NR. 253718-96 HEIDENHAIN SEALED LINEAR ENCODER GRATING PITCH 0,100 MM CABLE LENGTH 0,50 M, WITH CONNECTOR CABLE WITHOUT ARMOR MEASURING LENGTH 1240 MM

LB 301 ML 1440 ID.-NR. 284669-06 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1440

LB 326 ML 1440 ID.-NR. 229201-97 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1440

LB 326 ML 1040 ID.-NR. 253718-04 HEIDENHAIN SEALED LINEAR ENCODER GRATING PITCH 0,100 MM CABLE LENGTH 3,00 M, WITH CONNECTOR CABLE WITH ARMOR MEASURING LENGTH 1040 MM

LB 326 ML 1040 ID.-NR. 229201-95 HEIDENHAIN SEALED LINEAR ENCODER GRATING PERIOD 0,100MM CABLE LENGTH 0,50M, WITH CONNECTOR CABLE WITHOUT ARMOR MEASURING LENGTH 1040MM

LB 326 ML 1040 ID.-NR. 222370-47 HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 1040 MM

LB 326 ML 1440 ID.-NR. 229201-06 HEIDENHAIN SEALED LINEAR ENCODER CABLE LENGTH 3,00M, WITH CONNECTOR CABLE WITH ARMOR MEASURING LENGTH 1440MM

LS 303C ML 220 ID.-NR. 334752-03 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 220 MM ACCURACY GRADE: ± 10.0 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION:C001 DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD ELECTRICAL CONNECTION: CONNECTOR M23, MALE, 9-PIN CABLE LENGTH: 3.00

LF 481 ML 150 ID.-NR. 355529-60 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR HIGHEST REPEATABILITY MEASURING LENGTH: 150 MM ACCURACY GRADE: ± 3.0 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION: 25 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH WITH TWO REFERENCE MARKS FURTHER REFERENCE MARKS: 25 MM DISTANCE FROM END OF MEASURING LENGTH WITH TWO REFERENCE MARKS ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LIDA 325 ML 1440 ID.-NR. 214087-34 HEIDENHAIN SCALE TAPE FOR LIDA MEASURING LENGTH 1440

LS 406 ML 820 ID.-NR. 329982-31 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 820 MM ACCURACY GRADE: ± 5.0 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION: 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH WITH TWO REFERENCE MARKS FURTHER REFERENCE MARKS: 35 MM DISTANCE FROM END OF MEASURING LENGTH WITH TWO REFERENCE MARKS ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 486 ML 470 ID.-NR. 285090-17 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 470 MM ACCURACY GRADE: ± 5.0 µM FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:35 MM ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 486 ML 820 ID.-NR. 310113-24 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 820 MM ACCURACY GRADE: ± 5.0 µM FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:35 MM ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 503 ML 1020 ID NO. 216760-28 HEIDENHAIN INCREMENTAL ENCLOSED LENGTH MEASURING SYSTEM MEASURING LENGTH 1020, ACCURACY CLASS +/- 0.010 MM, REFERENCE MARK POSITION Z = 85 MM, WITHOUT METAL PROTECTIVE TUBE WITH PLUG 22856103, CABLE LENGTH 170 MM
