Linar Measurement Systems

LC 485 ML 820 ID.-NR. 689679-16 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 820 MM, TOTAL LENGTH ML+105 MM, ACCURACY GRADE ± 3.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, END BLOCK 14A, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 485 ML 220 ID.-NR. 689681-04 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 220 MM, TOTAL LENGTH ML+105 MM, ACCURACY GRADE  ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 486C ML 1240 ID.-NR. 329993-32 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 1240 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE MOUNTING SPAR OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LC 115 ML 3640 ID.-NR. 689693-03 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 3640 MM, ACCURACY GRADE 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, DATA INTERFACE ENDAT22 SYNCHRONOUS SERIAL ENDAT 2.2 WITHOUT INCREMENTAL SIGNALS, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 493F ML 920 ID.-NR. 557642-17 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 920 MM ACCURACY GRADE ± 5.0 µM GRATING PERIOD 20.000 µM FASTENING TYPE MOUNTING SPAR OUTPUT CODE BINARY DATA INTERFACE FANUC02 SERIAL INTERFACE ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 495F ML 920 ID.-NR. 760933-18 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 920 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, END BLOCK 14A, OUTPUT SIGNAL NO SPECIFIED VALUE, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 487 ML 120 ID.-NR. 560528-02 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 120 MM, ACCURACY GRADE ± 3.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH, FURTHER REFERENCE MARKS 35 MM DISTANCE FROM THE END OF THE MEASURING LENGTH, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 185 ML 1640 ID.-NR. 689701-15 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 1640 MM, ACCURACY GRADE 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 185 ML 1640 ID.-NR. 689696-16 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 1640 MM GRATING PERIOD 20.000 µM FASTENING TYPE SCREW-ON STRIP INTEGRATED DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 485 ML 1340 ID.-NR. 689684-43 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 1340 MM, TOTAL LENGTH ML+105 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 403C ML 520 ID.-NR. 334756-34 HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 520 MM OUTPUT SIGNALS SINUSOIDAL POWER SIGNALS (11 µASS) REFERENCE MARKS DISTANCE CODED ELECTRICAL CONNECTION CABLE 0,30 M WITH FLANGE SOCKET ON CONNECTION FIXTURE

LC 195F ML 140 ID.-NR. 760907-01 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 140 MM, ACCURACY GRADE 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 403 ML 920 ID.-NR. 334755-9B HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 920 MM, ACCURACY +/- 0,005 MM, REFERENCE MARK Z = 35 MM, Z1 = 850 MM, OUTPUT SIGNALS SINUSOIDAL POWER SIGNALS (11 µASS), ELECTRICAL CONNECTION CABLE 6 M WITH CONNECTOR WITHOUT ARMOR

LS 403 ML 520 ID.-NR. 226520-B4 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 520 MM

LS 1679 ML 420 ID.-NR. 589221-40 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION WITH INTEGRATED GUIDE WAY FOR BENDING MACHINES MEASURING LENGTH 420 MM ACCURACY GRADE ± 10.0 µM FASTENING TYPE END BLOCK CONNECTING DIRECTION CABLE OUTLET RIGHT CABLE LENGTH 0.50 M ELECTRICAL CONNECTION CONNECTOR M23, MALE, 12-PIN

LS 673C ML 470 ID.-NR. 1366572-07 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 470 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE MOUNTING BRACKET, REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, OUTPUT SIGNAL SQUARE-WAVE SIGNALS, TTL LEVELS WITH 1-FOLD INTERPOLATION, NON-CLOCKED, ELECTRICAL CONNECTION D-SUB CONNECTOR, METALIZED PLASTIC HOUSING, 2-ROW, WITH LOCKING SCREWS, MALE, 9-PIN, CABLE LENGTH 3.00 M

LC 195S ML 2240 ID.-NR. 760912-20 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 2240 MM, ACCURACY GRADE 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, DATA INTERFACE DQ01 DRIVE-CLIQ ENCODER INTERFACE DQ01, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 703 ML 1340 ID.-NR. 336976-17 HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 1340 MM OUTPUT SIGNALS SINUSOIDAL (11 UASS) REFERENCE MARKS ONE REFERENCE MARK AT MID- POINT OF MEASURING LENGTH MOVEABLE BY 50 MM STEPS ELECTRICAL CONN. WITHOUT CABLE

LC 183 ML 190 ID.-NR. 557679-25 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 190 MM ACCURACY GRADE 5.0 µM FASTENING TYPE SCREW-ON STRIP INTEGRATED DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 706 ML 920 ID.-NR. 295703-25 HEIDENHAIN SEALED LINEAR ENCODER

LS 106C ML 1340 ID.-NR. 336961-24 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 1340 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 403C ML 1020 ID.-NR. 334756-58 HEIDENHAIN SEALED LINEAR ENCODER, MEASURING LENGTH 1020 MM, ACCURACY +/- 0,005 MM, OUTPUT SIGNALS SINUSOIDAL POWER SIGNALS (11 µASS), REFERENCE MARKS DISTANCE CODED, ELECTRICAL CONNECTION ABLE 0,30 M WITH FLANGE SOCKET ON CONNECTION FIXTURE

LS 503 ML 1640 ID.-NR. 216760-39 HEIDENHAIN INCREMENTAL SEALED LNEAR ENCODER MEASURING LENGTH 1640 MM

LS 623 ML 220 ID.-NR. 228861-2T HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 220 MM, GRATING PITCH 0,020MM, ACCURACY GRADE +/-0,010MM, REFERENCE MARK AT Z= 200MM , CABLE LENGTH 1,00M WITHOUT CONNECTOR

LS 403C ML 520 ID.-NR. 233191-29 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 520 MM

LS 487 ML 1740 ID.-NR. 344835-0N HEIDENHAIN SEALED LINEAR ENCODER WITH OPTIMIZED THERMAL BEHAVIOR WITH LOW SCANNING HEAD WITH MOUNTING SPAR MEASURING LENGTH 1740 MM, OUTPUT SIGNALS SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ACCURACY +/- 0,005 MM, REFERENCE MARK POSITION Z = 45 MM, Z1 = 1650MM FURTHER REFERENCE-MARKS: SELECTABLE BY MAGNET, ELECTRICAL CONNECTION VIA CABLE ASSEMBLY

LC 481 ML 820 ID.-NR. 353703-26 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 820 MM, TOTAL LENGTH ML+105 MM, ACCURACY GRADE ± 3.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 706C ML 1840 ID.-NR. 295706-34 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LC 185 ML 2440 ID.-NR. 689701-20 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 2440 MM ACCURACY GRADE 5.0 µM FASTENING TYPE SCREW-ON STRIP INTEGRATED DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LB 326 ML 1040 ID.-NR. 222370-32 HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 1040 MM

LB 326 ML 2440 ID.-NR. 222370-39 HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 2440 MM

LC 485 ML 1640 ID.-NR. 689679-24 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1640 MM FASTENING TYPE: END BLOCK + MOUNTING SPAR END BLOCK: 14A OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) OUTPUT CODE: BINARY DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 183 ML 2040 ID.-NR. 557660-18 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 2040 MM, ACCURACY GRADE 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 487C ML 770 ID.-NR. 572248-14 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 770 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION C001 - DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, FURTHER REFERENCE MARKS NONE, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 704 ML 1840 ID.-NR. 237133-51 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1840

LS 477 ML 220 ID.-NR. 605379-23 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 220 MM, TOTAL LENGTH ML+138 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SQUARE-WAVE SIGNALS, TTL LEVELS WITH 10-FOLD INTERPOLATION, REFERENCE MARK POSITION 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH, FURTHER REFERENCE MARKS 35 MM DISTANCE FROM THE END OF THE MEASURING LENGTH, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 415 ML 520 ID.-NR. 689675-10 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 520 MM, TOTAL LENGTH ML+105 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, END BLOCK 14A, OUTPUT SIGNAL NO SPECIFIED VALUE, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 415 ML 270 ID.-NR. 689675-05 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 270 MM, TOTAL LENGTH ML+105 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, END BLOCK 14A, OUTPUT SIGNAL NO SPECIFIED VALUE, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 485 ML 2040 ID.-NR. 689681-56 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH: 2040 MM, TOTAL LENGTH: ML+105 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, END BLOCK: 14A, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LF 485C-250 ID.-NR. 635327-05 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR HIGHEST REPEATABI ITY MEASURING LENGTH 250 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 5000 X SIGNAL PERIOD, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN,

LS 486 ML 570 ID.-NR. 329990-83 HEIDENHAIN INKREMENTALES GEKAPSELTES LÄNGENMESSGERÄT MIT KLEINPROFILIGEM MASSSTABGEHÄUSE MESSLÄNGE: 570 MM, GENAUIGKEITSKLASSE: ± 5,0 ΜM, BEFESTIGUNGSART: ENDSTÜCKE + MONTAGESCHIENE, AUSGANGSSIGNAL: SINUSFÖRMIGE SPANNUNGSSIGNALE (1 VSS), REFERENZMARKENLAGE: IN DER MITTE DER MESSLÄNGE, ELEKTRISCHER ANSCHLUSS SEPARATES ADAPTERKABEL

LC 485 ML 220 ID.-NR. 689683-19 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 220 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 303C ML 620 ID.-NR. 249909-18 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 620 MM, ACCURACY GRADE ± 10.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION C001 DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION CONNECTOR, MALE, 9-PIN WITH ARMOR, CABLE LENGTH 3.00 M

LB 326 ML 2640 ID.-NR. 222370-40 HEIDENHAIN SEALED LINEAR ENCODER MEASURING, LENGTH 2640 MM

LS 403 ML 570 ID.-NR. 226520-63 HEIDENHAIN SEALED LINEAR ENCODER, GRATING PITCH 0,020 MM, ACCURACY GRADE +/-0,005 MM, REFERENCE MARK AT Z= 35 MM, Z1= 500 MM, CABLE LENGTH 3,00 M, WITH CONNECTOR, WITHOUT ARMOR MEASURING LENGTH 570 MM

LS 405 ML 166 ID.-NR. 245100-13 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER, MEASURING LENGTH 166 MM

LB 302C ML 11440 ID.-NR. 315422-42 HEIDENHAIN PARTS KIT LB 302C FOR INCREMENTAL MULTI-SECTION SEALED LINEAR ENCODER WITH LARGE CROSS-SECTION HOUSING FOR LARGE MEASURING LENGTHS CONSISTING OF 1 SCALE TAPE, 1 END SECTION WITH CLAMPING DEVICE, 1 END SECTION WITH TENSIONING DEVICE, 1 SEALING LIP, 3 BEARING STRIP, 3 HOUSING SEALS, SMALL PARTS, MEASURING LENGTH 11440 MM, ACCURACY GRADE ± 5.0 µM GRATING PERIOD 40.000 µM, REFERENCE MARK DISTANCE-CODED, REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 2000 X GRATING PERIOD

LS 406 ML 220 ID.-NR. 329982-62 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 220 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 303C ML 620 ID.-NR. 334752-17 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 620 MM, ACCURACY GRADE ± 10.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION C001 DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION CONNECTOR M23, MALE, 9-PIN

LC 483 ML 2040 ID.-NR. 557654-41 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 2040 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN
