Linar Measurement Systems

LS 403 ML 370 ID.-NR. 226520-DC HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 370, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 25, ELECTRICAL CONNECTION 34S09 FLANGE SOCKET MALE 9-PIN ON CONNECTION FIXTURE, CABLE LENGTH 0,30 M

LS 403 ML 470 ID.-NR. 297810-61 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY GRADE 3,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, FURTHER REFERENCE MARK POSITON 400, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 403 ML 470 ID.-NR. 297810-24 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, FURTHER REFERENCE MARK POSITION 400, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 403 ML 470 ID.-NR. 226520-7Z HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY GRADE 3,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, FURTHER REFERENCE MARK POSITION 50,  ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 403 ML 470 ID.-NR. 228249-23 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY GRADE 3,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, FURTHER REFERENCE MARK POSITION 400, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 403 ML 470 ID.-NR. 226520-EB HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, FURTHER REFERENCE MARK POSITION 400, ELECTRICAL CONNECTION 31S09 CONNECTOR MALE 9-PIN W/METAL ARMOR, CABLE LENGTH 0,50 M

LS 403 ML 470 ID.-NR. 334755-EB HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, ELECTRICAL CONNECTION 31S09 CONNECTOR MALE 9-PIN W/ METAL ARMOR, CABLE LENGTH 0,50 M

LS 403C ML 470 ID.-NR. 233191-47 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION 34S09 FLANSCHDOSE STIFT 9-POLIG AUF MONTAGEBLOCK, CABLE LENGTH 0,30 M

LS 403 ML 470 ID.-NR. 226520-08 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, ELECTRICAL CONNECTION 37S09 CONNECTOR MALE 9-PIN (METAL HOUSING), CABLE LENGTH 0,50 M

LS 403 ML 620 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 403 ML 620 ID.-NR. 297810-26 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 620, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, FURTHER REFERENCE MARK POSITION 550, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 403 ML 70 ID.-NR. 226520-81 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 70, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 403 ML 720 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 403 ML 720 ID.-NR. 334755-9A HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 720, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, FURTHER REFERENCE MARK POSITION 650, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 4,50 M

LS 403 ML 770 ID.-NR. 226520-95 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 770, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, FURTHER REFERENCE MARK POSITION 700,  ELECTRICAL CONNECTION 31S09 CONNECTOR MALE 9-PIN W/ METAL ARMOR, CABLE LENGTH 3,00 M

LS 403 ML 820 ID.-NR. 226520-29 HEIDENHAIN INCRMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 820, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35,  FURTHER REFERENCE MARK POSITION 750, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 403C ML 670 ID.-NR. 310724-15 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 670, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M

LS 406C ML 1240 ID.-NR. 268549-56 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1240 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION: DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 406C ML 1240 ID.-NR. 310750-29 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1240 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION: DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 406C ML 220 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 406C ML 220 ID.-NR. 266045-44 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 220 MM ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION: DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 406C ML 420 ID.-NR. 329983-14 HEIDENHAIN INKREMENTALES GEKAPSELTES LÄNGENMESSGERÄT MIT KLEINPROFILIGEM MASSSTABGEHÄUSE MESSLÄNGE: 420 MM GENAUIGKEITSKLASSE: ± 5,0 µM, BEFESTIGUNGSART: ENDSTÜCKE + MONTAGESCHIENE AUSGANGSSIGNAL: SINUSFÖRMIGE STROMSIGNALE (11 µASS) REFERENZMARKENLAGE: ABSTANDSCODIERTE REFERENZMARKEN MIT GRUNDABSTAND 1000 X TEILUNGSPERIODE, ELEKTRISCHER ANSCHLUSS: SEPARATES ADAPTERKABEL

LS 406C ML 270 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 406C ML 470 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 406 ML 316 HEIDENHAIN INKREMENTALES GEKAPSELTES LÄNGENMESS-SYSTEM

LS 303C ML 120 ID.-NR. 334752-0R HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 120 MM ACCURACY GRADE: ± 10.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION:C001 DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: CONNECTOR, MALE, 9-PIN WITH ARMOR CABLE LENGTH: 4.00 M

LS 406C ML 720 ID.-NR. 329983-21 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 770 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION: DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 476 ML 220 ID.-NR. 310753-04 HEIDENHAIN SEALED LINEAR ENCODER WITH OPTIMIZED THERMAL BEHAVIOR WITHOUT MOUNTING SPAR MEASURING LENGTH 220, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL TTLX5 SQUARE-WAVE SIGNALS, REFERENCE MARK POSITION 35, FURTHER REFERENCE MARK POSITION 150, ELECTRICAL CONNECTION 66S12 SEPARATE ADAPTER CABLE

LS 476 ML 70 ID.-NR. 329986-01 HEIDENHAIN SEALED LINEAR ENCODER WITH OPTIMIZED THERMAL BEHAVIOR WITHOUT MOUNTING SPAR MEASURING LENGTH 70, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL TTLX5 SQUARE-WAVE SIGNALS, REFERENCE MARK POSITION ML/2 IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION 66S12 SEPARATE ADAPTER CABLE

LC 495S ML 170 ID.-NR. 760938-03 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 170 MM, TOTAL LENGTH: ML+138 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: NO SPECIFIED VALUE, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 486 ML 1140 ID.-NR. 310113-81 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1140 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:570 ML/2, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 486 ML 620 ID.-NR. 310113-80 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 620 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:310 ML/2, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 486 ML 720 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 486 ML 770 ID.-NR. 310113-84 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 770 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:385 ML/2, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 486 ML 770 ID.-NR. 310113-62 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 770 MM ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:35 MM, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 486C ML 220 ID.-NR. 310873-10 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 220 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 486C ML 220 ID.-NR. 329993-68 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 220 MM ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION: DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 486C ML 270 ID.-NR. 329991-44 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 270 MM ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 486C ML 620 ID.-NR. 329993-20 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 620 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 486C ML 620 ID.-NR. 285260-20 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 620 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 486C ML 770 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 486C ML 770 ID.-NR. 329993-23 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 770 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 503 ML 1240 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 486 ML 170 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LC 181 ML 240 ID.-NR. 341240-01 HEIDENHAIN ABSOLUTE LENEAR ENCODER MEASURING LENGTH 240, ACCURACY GRADE 5,0, FASTENING TYPE I SCREW-ON STRIP, OUTPUT SIGNAL 1 VPP SINUSOIDAL VOLTAGE SIGNALS, DATA INTERFACE ENDAT01 SYNCHRONOUS N-SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION 52S12 SEPARATE ADAPTER CABLE

LC 483 ML 120 ID.-NR. 557649-02 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 120 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 483 ML 70 ID.-NR. 557649-01 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 70 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 503 ML 1240 ID.-NR. 216760-CD HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1240, ACCURACY GRADE 10,0, FASTENING TYPE W MOUNTING BRACKET, OUTPUT SIGNAL 15...35µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 620, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE

LS 507 ML 1240 ID.-NR. 217483-19 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1240, ACCURACY GRADE 10,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 15...35µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 100, ELECTRICAL CONNECTION 37S09 CONNECTOR MALE 9-PIN (METAL HOUSING), CABLE LENGTH 3,00 M

LS 486 ML 1020 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER
