Linar Measurement Systems

LS 107 ML 440 ID.-NR. 243889-3N HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 440

LC 485 ML 70 ID.-NR. 689681-01 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS  SECTION, MEASURING LENGTH 70 MM, TOTAL LENGTH ML+105 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, END BLOCK 14A, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 406 ML 470 ID.-NR. 329982-24 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION ACCURACY GRADE ± 5.0 µM FASTENING TYPE END BLOCK + MOUNTING SPAR OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH WITH TWO REFERENCE MARKS FURTHER REFERENCE MARKS 35 MM DISTANCE FROM END OF MEASURING LENGTH WITH TWO REFERENCE MARKS ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE MEASURING LENGTH 470 MM

LC 192F ML 1040 ID. 387089-09 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH SERIAL INTERFACE ACCURACY GRADE 5.0 µM MEASURING STEP 50 NM FASTENING TYPE SCREW-ON STRIP INTEGRATED DATA INTERFACE FANUC01 SERIAL INTERFACE MEASURING LENGTH 1040 MM

LIDA 403 ML 1440 ID.-NR. 1145814-14 HEIDENHAIN LINEAR SCALE FOR LIDA INCREMENTAL EXPOSED LINEAR ENCODER MEASURING LENGTH:1440 MM, ACCURACY GRADE: ± 1.0 µM, REFERENCE MARK POSITION: IN THE MIDDLE OF THE MEASURING LENGTH

LC 485 ML 420 ID.-NR. 689681-08 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 420 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE END BLOCK + MOUNTING SPAR END BLOCK 14A OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP) OUTPUT CODE BINARY DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 487C ML 1740 ID.-NR. 572249-24 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 1740 MM, TOTAL LENGTH ML+105 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION C001 - DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 803 ML 420 ID.-NR. 204418-GG HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 420 MM ACCURACY GRADE 10.0 µM FASTENING TYPE END BLOCK OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (25 µAPP) REFERENCE MARK POSITION 60 MM REFERENCE MARK POSITION 2 300 MM ELECTRICAL CONNECTION CONNECTOR M23, METAL HOUSING, MALE, 9-PIN CABLE LENGTH 6.00 M

LC 483 ML 1340 ID.-NR. 557647-54 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 1340 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE MOUNTING SPAR OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP) OUTPUT CODE BINARY DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 406C ML 220 ID.-NR. 329983-10 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 220 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE END BLOCK + MOUNTING SPAR OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LC 495S ML 470 ID.-NR. 760938-09 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 470 MM, TOTAL LENGTH ML+138 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, END BLOCK 12A, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 485 ML 920 ID.-NR. 689684-25 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH: 920 MM, TOTAL LENGTH: ML+105 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, END BLOCK: 14A, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION:  FLANGE SOCKET, MALE, 14-PIN

LS 487C ML 1020 ID.-NR. 572248-17 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 1020 MM, TOTAL LENGTH ML+138 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION C001 - DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 485 ML 1840 ID.-NR. 689681-55 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH: 1840 MM, TOTAL LENGTH: ML+105 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, END BLOCK: 14A, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 485 ML 320 ID.-NR. 689684-06 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH: 320 M, TOTAL LENGTH: ML+105 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, END BLOCK: 14A, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION:  FLANGE SOCKET, MALE, 14-PIN

LC 485 ML 670 ID.-NR. 689680-13 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 670 MM GRATING PERIOD 20.000 µM FASTENING TYPE END BLOCK + MOUNTING SPAR END BLOCK 12A OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP) OUTPUT CODE BINARY DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 603 ML 1540 ID.-NR. 336972-7H HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 1540 MM, ACCURACY GRADE: ± 10.0 µM, FASTENING TYPE: MOUNTING BRACKET, OUTPUT SIGNAL: SINUSOIDAL CURRENT  SIGNALS (11 µAPP), REFERENCE MARK POSITION: IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION:  SEPARATE ADAPTER CABLE

LF 485C ML 300 ID.-NR. 635327-06 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR HIGHEST REPEATABILITY, MEASURING LENGTH 300 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 5000 X SIGNAL PERIOD, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 603C ML 1640 ID.-NR. 336973-92 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 1640 MM ACCURACY GRADE ± 10.0 µM FASTENING TYPE MOUNTING BRACKET OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 477 ML 270 ID.-NR. 605379-30 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 270 MM TOTAL LENGTH ML+138 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE END BLOCK + MOUNTING SPAR OUTPUT SIGNAL SQUARE-WAVE SIGNALS, TTL LEVELS WITH 5-FOLD INTERPOLATION REFERENCE MARK POSITION 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH FURTHER REFERENCE MARKS 35 MM DISTANCE FROM THE END OF THE MEASURING LENGTH ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 495S ML 920 ID.-NR. 760943-18 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 920 MM TOTAL LENGTH ML+105 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE END BLOCK + MOUNTING SPAR END BLOCK 14A ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 495S ML 70 ID.-NR. 760938-01 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 70 MM, TOTAL LENGTH ML+138 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, END BLOCK 12A, DATA INTERFACE DQ01 DRIVE-CLIQ ENCODER INTERFACE DQ01, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 185 ML 3240 ID.-NR. 689698-01 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 3240 MM, ACCURACY GRADE 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 107 ML 640 ID.-NR. 264069-47 HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 640 MM, GRATING PITCH 0,020 MM

LS 603 ML 320 ID.-NR. 228529-07 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 320 MM

LS 107 ML 1140 ID.-NR. 264069-52 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1140 MM

LS 106 ML 640 ID.-NR. 275066-42 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 640 MM FASTENING TYPE SCREW-ON STRIP ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 107 ML 1140 ID.-NR. 243889-52 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1140

LS 107 ML 940 ID.-NR. 264069-99 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 940 MM

LS 106 ML 840 ID.-NR. 275066-19 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE MEASURING LENGTH 840 MM

LS 107 ML 840 ID.-NR. 264069-49 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 840 MM

LS 106 ML 940 ID.-NR. 275066-45 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION FASTENING TYPE SCREW-ON STRIP ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE MEASURING LENGTH 940 MM

LS 503 ML 1440 ID.-NR. 216760-35 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1440 MM

LS 107 ML 1440 ID.-NR. 243889-3B HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1440 MM

LS 303 ML 720 ID.-NR. 228975-63 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 720 MM

LS 107 ML 1740 ID.-NR. 264069-0H HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1740 MM

LS 703 ML 720 ID.-NR. 216750-0F HEIDENHAIN INCREMENTAL ENCAPSULATED LENGTH MEASURING SYSTEM MEASURING LENGTH 720, ACCURACY CLASS +/- 0.003 MM, OUTPUT SIGNAL 11µASS SINUSAL CURRENT SIGNALS (11µASS), REFERENCE MARK LOCATION ALL 50 MM EXCEEDING MAGNETIC EXTENDED BY MAGNETIC EXTRAS

LS 704 ML 720 ID.-NR. 237133-CD HEIDENHAIN INCREMENTAL ENCLOSED LENGTH MEASURING SYSTEM MEASURING LENGTH 720, ACCURACY CLASS +/- 0.005 MM, OUTPUT SIGNAL 11µASS SINUSAL CURRENT SIGNALS, REFERENCE MARK POSITION 50, ELECTRICAL CONNECTION VIA ADAPTER CABLE

LS 704 ML 1540 ID.-NR. 237133-50 HEIDENHAIN INCREMENTAL ENCLOSED LENGTH MEASURING SYSTEM MEASURING LENGTH 1540, ACCURACY CLASS +/- 0.005MM

LS 501 ML 2640 ID.-NR. 206681-0L HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 510D ML 1740 ID.-NR: 205036-2P 205036-2P HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 703 ML 2040 ID.-NR. 216750-1W HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 2040

LS 406C ML 420 ID.-NR. 329983-32 HEIDENHAIN INCREMENTAL ENCLOSED LENGTH MEASUREMENT DEVICE WITH SMALL-PROFILE SCALE HOUSING MEASURING LENGTH: 420 MM

LS 406C ML 470 ID.-NR. 329983-38 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 470 MM, SMALL-PROFILE SIZE HOUSING

LS 704 ML 720 ID.-NR. 336978-CD HEIDENHAIN INCREMENTAL ENCLOSED LENGTH MEASURING SYSTEM MEASURING LENGTH 720, ACCURACY CLASS +/- 0.005 MM, OUTPUT SIGNAL 11µASS SINUSAL CURRENT SIGNALS, REFERENCE MARK POSITION 50, ELECTRICAL CONNECTION VIA ADAPTER CABLE

LS 704 ML 720 ID.-NR. 336958-23 HEIDENHAIN INCREMENTAL ENCLOSED LENGTH MEASURING SYSTEM MEASURED LENGTH 720, ACCURACY CLASS 0.005, OUTPUT SIGNAL 11µASS SINUSAL CURRENT SIGNALS, REFERENCE MARK POSITION 50

LS 503 ML 1540 ID.-NR. 216760-0C 216760-0C HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER, MEASURING LENGTH 1540

LS 703 ML 2040 ID.-NR. 336976-23 HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 2040 MM,  OUTPUT SIGNALS SINUSOIDAL (11 UASS), REFERENCE MARKS ONE REFERENCE MARK AT MID- POINT OF MEASURING LENGTH MOVEABLE BY 50 MM STEPS, ACCURACY GRADE +/- 0,005 MM, ELECTRICAL CONNECTION VIA ADAPTER CABLE

LS 406C ML 11540 ID-NR. 329985-03 HEIDENHAIN INCREMENTAL ENCLOSED LENGTH MEASUREMENT DEVICE WITH SMALL-PROFILE SCALE HOUSING MEASURING LENGTH: 1540 MM, ACCURACY CLASS: ± 5.0 µM; FASTENING TYPE: MOUNTING RAIL; OUTPUT SIGNAL: SINE-SHAPED CURRENT SIGNALS (11 µAPP) REFERENCE MARK LOCATION:  DISTANCE-CODED REFERENCE MARKERS WITH BASE DISTANCE 1000 X DIVISION PERIOD; ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 703 ML 1640 ID.-NR. 216750-HN HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 2040 MM
