Linar Measurement Systems
Linar Measurement Systems
LS 403 ML 620 LS 403 ML 620 ID.-NR. 334755-26 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 620, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 35, FURTHER REFERENCE MARK POSITION 550, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABEL LENGTH 3,00 M
Linar Measurement Systems
LC 483 ML 270 LC 483 ML 270 ID.-NR. 557647-05 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 270 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN
Linar Measurement Systems
LS 486C ML 1240 LS 486C ML 1240 ID.-NR. 329991-64 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1240 MM ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LS 406C ML 320 LS 406C ML 320 ID.-NR. 329983-12 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 320 MM ACCURACY GRADE: ± 5.0 µM GRATING PERIOD: 20.000 µM; FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION: DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD; ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LS 486C ML 720 LS 486C ML 720 ID.-NR. 329991-22 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 720 MM ACCURACY GRADE: ± 5.0 µM GRATING PERIOD: 20.000 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LS 107 ML 1140 LS 107 ML 1140 ID.-NR. 243889-3M HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1140, ACCURACY GRADE 5,0, FASTENING TYPE G SCREW-ON STRIP, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 570, ELECTRICAL CONNECTION 55S08 SEPARATE ADAPTER CABLE
Linar Measurement Systems
LS 503 ML 470 LS 503 ML 470 ID-NR. 216760-14 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470, ACCURACY 10,0, FASTENING TYPE W MOUNTING BRACKET , OUTPUT SIGNAL 15...35µAPP SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 235, ELECTRICAL CONNECTION 31S09 CONNECTOR MALE 9-PIN W/ METAL ARMOR, CABLE LENGTH 3,00 M
Linar Measurement Systems
LS 603C ML 920 LS 603C ML 920 ID.-NR. 249922-84 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 920 MM ACCURACY GRADE: ± 10.0 µM, FASTENING TYPE: MOUNTING BRACKET OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION: DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 483 ML 920 LC 483 ML 920 ID.-NR. 557653-10 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 920 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN
Linar Measurement Systems
LC 483 ML 920 LC 483 ML 920 ID.-NR. 557654-25 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 920 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: OMS14 FLANGE SOCKET, MALE 14-PIN
Linar Measurement Systems
LC 483 ML 920 LC 483 ML 920 ID.-NR. 557647-17 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 920 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN
Linar Measurement Systems
LS 403 ML 270 LS 403 ML 270 ID.-NR. 334756-36 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 270, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, OUTPUT SIGNAL 11µASS SINUSOIDAL CURRENT SIGNALS, REFERENCE MARK POSITION 4444 DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 3,00 M
Linar Measurement Systems
LS 403C ML 470 LS 403C ML 470 ID.NR 334756-47 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH: 470 MM, ACCURACY: +/- 0,005 MM, FASTENING TYPE B END BLOCK, OUTPUT SIGNALS: SINUSOIDAL POWER SIGNALS (11 µASS), REFERENCE MARKS: DISTANCE CODED, ELECTRICAL CONNECTION: CABLE 0,30 M WITH FLANGE SOCKET ON CONNECTION FIXTURE, CABLE LENGTH 0,30 M
Linar Measurement Systems
LS 623 ML 220 LS 623 ML 220 ID.-NR. 336974-4G HEIDENHAIN INCREMENTAL LINEAR ENCODER MEASURING LENGTH: 220MM, OUTPUT SIGNALS: SQUARE-WAVE SIGNAL,TTL LEVEL, ACCURACY GRADE: +/- 0,010MM, REFERENCE MARKS: EVERY 50MM, MOVABLE WITH SELECTOR MAGNET STARTING AT MIDPOINT OF MEASURING LENGTH, ELECTRICAL CONNECTION: VIA ADAPTER CABLE
Linar Measurement Systems
LS 487C ML 1440 LS 487C ML 1440 ID.-NR. 572248-21 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1440 MM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:C001 - DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN
Linar Measurement Systems
LC 181 ML 1240 LC 181 ML 1240 ID.NR. 341240-11 HEIDENHAIN ABSOLUT SEALED LINEAR ENCODER MEASURING LENGTH 1240, ACCURACY GRADE 5,0, FASTENING TYPE I SCREW-ON STRIP, OUTPUT SIGNAL 1VPP SINUSOIDAL VOLTAGE SIGNALS, DATA INTERFACE ENDAT01 SYNCHRONOUS N-SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION 52S12 SEPARATE ADAPTER CABLE
Linar Measurement Systems
LS 486 ML 770 LS 486 ML 770 ID.-NR. 329990-23 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 770 MM, ACCURACY GRADE: ± 5.0 µM, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION:35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH WITH TWO REFERENCE MARKS FURTHER REFERENCE MARKS:35 MM DISTANCE FROM END OF MEASURING LENGTH WITH TWO REFERENCE MARKS, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 183 ML 3440 LC 183 ML 3440 ID.-NR. 557678-02 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 3440 MM ACCURACY GRADE: 5.0 µM, FASTENING TYPE: SCREW-ON STRIP INTEGRATED, OUTPUT SIGNAL: 1VPP SINUSOIDAL VOLTAGE SIGNALS, DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN
Linar Measurement Systems
LS 486C ML 1140 LS 486C ML 1140 ID.-NR. 329991-31 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1140 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION:DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LS 303 ML 170 LS 303 ML 170 D.-NR. 334751-02 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 170 MM ACCURACY GRADE: ± 10.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION:R35 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH WITH TWO REFERENCE MARKS, FURTHER REFERENCE MARKS R 35 35MM DISTANCE FROM END OF MEASURING LENGTH WITH TWO REFERENCE MARKS, ELECTRICAL CONNECTION: CONNECTOR, MALE, 9-PIN WITH ARMOR CABLE LENGTH: 3.00 M
Linar Measurement Systems
LC 491F ML 720 LC 491F ML 720 ID.-NR. 372854-22 HEIDENHAIN ABSOLUT SEALED LINEAR ENCODER MEASURING LENGTH 720, ACCURACY GRADE 5,0, FASTENING TYPE MOUNTING SPAR, DATA INTERFACE FANUC01, ELECTRICAL CONNECTION 66S12 SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 483 ML 470 LC 483 ML 470 ID.-NR. 557649-09 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 470 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP)
Linar Measurement Systems
LC 491F ML 320 LC 491F ML 320 ID.-NR. 372852-11 HEIDENHAIN ABSOLUT SEALED LINEAR ENCODER MEASURING LENGTH 320, ACCURACY GRADE 5,0, FASTENING TYPE B END BLOCK, DATA INTERFACE FANUC01, ELECTRICAL CONNECTION 66S12 SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 483 ML 1020 LC 483 ML 270 ID.-NR. 557647-1/8 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1020 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN
Linar Measurement Systems
LC 483 ML 1020 LC 483 ML 1020 ID.-NR. 557647-40 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1020 MM, TOTAL LENGTH: ML+105 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN
Linar Measurement Systems
LC 481 ML 70 LC 481 ML 70 ID.-NR. 337461-46 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 70 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 70 LC 481 ML 70 ID.-NR. 372849-03 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 70 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 770 LC 481 ML 770 ID.-NR. 372849-47 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 770 MM ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 420 LC 481 ML 420 ID.-NR. 372849-12 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 420 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 370 LC 481 ML 370 ID.-NR. 372849-15 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 370 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 320 LC 481 ML 320 ID.-NR. 337461-06 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 320 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 320 LC 481 ML 320 HEIDENHAIN ABSOLUT SEALED LINEAR ENCODER MEASURING LENGTH 320
Linar Measurement Systems
LC 481 ML 270 LC 481 ML 270 ID.-NR. 327300-47 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 270 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 270 LC 481 ML 270 ID.-NR. 337461-50 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 270 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LS 303 ML 320 LS 303 ML 320 ID.-NR. 334751-08 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 320 MM ACCURACY GRADE: ± 10.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION:R35 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH WITH TWO REFERENCE MARKS, ELECTRICAL CONNECTION: CONNECTOR, MALE, 9-PIN WITH ARMOR CABLE LENGTH: 3.00 M
Linar Measurement Systems
LC 481 ML 170 LC 481 ML 170 ID.-NR. 353703-01 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 170 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 170 LC 481 ML 170 ID.-NR. 372849-13 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 170 MM ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 170 LC 481 ML 170 ID.-NR. 327300-01 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 170 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 170 LC 481 ML 170 ID.-NR. 372849-04 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 170 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 120 LC 481 ML 120 ID.-NR. 327300-16 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 120 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LC 481 ML 120 LC 481 ML 120 ID.-NR. 327300-04 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 120 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
Linar Measurement Systems
LS 303C ML 170 LS 303C ML 170 ID.-NR. 334752-02 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 170 MM ACCURACY GRADE: ± 10.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP) REFERENCE MARK POSITION:C001 DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: CONNECTOR, MALE, 9-PIN WITH ARMOR CABLE LENGTH: 3.00 M
Linar Measurement Systems
LC 182 ML 740 LC 182 ML 740 ID.-NR. 387092-29 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION FOR ABSOLUTE POSITION CAPTURE WITH ENDAT INTERFACE MEASURING LENGTH: 740 MM, ACCURACY GRADE: 3.0 µM, FASTENING TYPE: SCREW-ON STRIP INTEGRATED, DATA INTERFACE: SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE
