Linar Measurement Systems

LS 703 ML 220 ID.-NR. 216750-85 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 220

LS 406 ML 270 ID.-NR. 329982-20 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 270 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH WITH TWO REFERENCE MARKS, FURTHER REFERENCE MARKS 35 MM DISTANCE FROM END OF MEASURING LENGTH WITH TWO REFERENCE MARKS, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LC 483 ML 1440 ID.-NR. 557647-22 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 1440 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 483 ML 370 ID.-NR. 557648-07 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 370 MM, TOTAL LENGTH: ML+105 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 195F ML 240 ID.-NR. 760907-02 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 240 MM, ACCURACY GRADE 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, DATA INTERFACE FANUC05 SERIAL INTERFACE FANUC ALPHA/ALPHAI, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 406 ML 470 ID.-NR. 329982-50 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 470 MM FASTENING TYPE END BLOCK + MOUNTING SPAR OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP) ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 406 ML 320 ID.-NR. 329982-21 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 320 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH WITH TWO REFERENCE MARKS, FURTHER REFERENCE MARKS 35 MM DISTANCE FROM END OF MEASURING LENGTH WITH TWO REFERENCE MARKS, ELECTRICAL CONNECTION EPARATE ADAPTER CABLE

LS 486C ML 670 ID.-NR. 329991-21 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 670 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION: DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: EPARATE ADAPTER CABLE

LF 185 ML 340 ID.-NR. 682442-29 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION FOR HIGHEST REPEATABILITY, MEASURING LENGTH 340 MM, ACCURACY GRADE ±2.0 µM, FASTENING TYPE SCREW-ON STRIP, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION ML/2 - IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 703 ML 1140 ID.-NR. 216750-BX HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1140 MM

LS 477 ML 70 ID.-NR. 605379-01 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 70 MM, TOTAL LENGTH: ML+138 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SQUARE-WAVE SIGNALS, TTL LEVELS WITH 5-FOLD INTERPOLATION, REFERENCE MARK POSITION: ML/2 - IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 303C ML 520 ID.-NR. 364019-10 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 520 MM, ACCURACY GRADE ± 10.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION C001 DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 106C ML 940 ID.-NR. 336961-20 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 940 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 706C ML 3040 ID.-NR. 336968-40 HEIDENHAIN SEALED LINEAR ENCODER HIGH VIBRATION RATING, OUTPUT SIGNALS SINUSSOIDAL 11UASS, REFERENCE MARKS DISTANCE-CODED, ELECTRICAL CONNECTION VIA ADAPTER CABLE, ACCURACY +/- 0,005 MM, MEASURING LENGTH 3040 MM

LC 483 ML 770 ID.-NR. 557647-15 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 770 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 106 ML 2440 ID.-NR. 336958-32 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 2440 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LC 495S ML 570 ID.-NR. 760943-11 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 570 MM, TOTAL LENGTH ML+105 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL NO SPECIFIED VALUE, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 483 ML 270 ID.-NR. 557650-05 HEIDENHAIN HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 270 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 406 ML 120 ID.-NR. 262181-49 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 120 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 60 MM, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 106C ML 190 ID.-NR. 336961-12 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 190 MM

LC 495S ML 520 ID.-NR. 760939-10 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 520 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE END BLOCK + MOUNTING SPAR END BLOCK: 14A OUTPUT SIGNAL NO SPECIFIED VALUE OUTPUT CODE DUAL DATA ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 495S ML 120 ID.-NR. 760939-02 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 120 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE END BLOCK + MOUNTING SPAR END BLOCK: 14A OUTPUT SIGNAL NO SPECIFIED VALUE OUTPUT CODE DUAL DATA ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 703 ML 170 ID.-NR. 216750-89 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 170 CABLE LENGTH 3,00 M

LS 186C ML 1140 ID.-NR. 336963-22 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 1140 MM ACCURACY GRADE: ± 5.0 µM, REFERENCE MARK POSITION: DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LC 185 ML 1840 ID.-NR. 689697-18 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 1840 MM ACCURACY GRADE 5.0 µM FASTENING TYPE SCREW-ON STRIP INTEGRATED DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 800 ML 370 CODE-NR. 005R0-5J HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 370 MM

LS 803 ML 420 CODE-NR. 306R21T HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 420 MM

LS 403 ML 370 ID.-NR. 226520-FH HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASUREMENT LENGTH 370, ACCURACY CLASS +/-0.005 MM, DIVISION PERIOD 0.020 NN, CABLE LENGTH 5.00 M WITH PLUG

LS 803 ML 720 CODE-NR. 010R07F HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 720 MM

LS 803 ML 220 CODE-NR. 002R07F HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 220 MM

LS 501D ML 220 CODE-NR. 002R05J HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 220 MM

LS 406 ML 270 ID.-NR. 329984-77 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 270 MM, ACCURACY GRADE ± 3.0 µM, FASTENING TYPE MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH WITH TWO REFERENCE MARKS, FURTHER REFERENCE MARKS 35 MM DISTANCE FROM END OF MEASURING LENGTH WITH TWO REFERENCE MARKS, ELECTRICAL CONNECTION SEPARATE ADAPTER CA

LS 406 ML 620 ID.-NR. 329984-80 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 620 MM, ACCURACY GRADE ± 3.0 µM, FASTENING TYPE MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH WITH TWO REFERENCE MARKS, FURTHER REFERENCE MARKS 35 MM DISTANCE FROM END OF MEASURING LENGTH WITH TWO REFERENCE MARKS, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 187 ML 240 ID.-NR. 527389-02 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 240 MM, ACCURACY GRADE ± 3.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION IN THE MIDDLE OF THE MEASURING LENGTH, FURTHER REFERENCE MARKS NONE, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 403 ML 920 ID.-NR. 226520-0A HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 920 MM

LC 483 ML 120 ID.-NR. 557647-02 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 120 MM, TOTAL LENGTH ML+105 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 177C ML 140 ID.-NR. 605354-01 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 140 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, OUTPUT SIGNAL SQUARE-WAVE SIGNALS, TTL LEVELS WITH 5-FOLD INTERPOLATION, REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 183 ML 2240 ID.-NR. 557680-20 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 2240 MM ACCURACY GRADE 3.0 µM FASTENING TYPE SCREW-ON STRIP INTEGRATED DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 628C ML 170 ID.-NR. 605802-03 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 170 MM, ACCURACY GRADE ± 10.0 µM, FASTENING TYPE MOUNTING BRACKET OUTPUT SIGNAL SQUARE-WAVE SIGNALS, TTL LEVELS REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 195S ML 2840 ID.-NR. 760916-23 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 2840 MM, ACCURACY GRADE 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, DATA INTERFACE DQ01 DRIVE-CLIQ ENCODER INTERFACE DQ01, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 195S ML 3640 ID.-NR. 760917-03 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 2840 MM, ACCURACY GRADE 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, DATA INTERFACE DQ01 DRIVE-CLIQ ENCODER INTERFACE DQ01, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 485 ML 470 ID.-NR. 689678-09 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH: 470 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR END BLOCK: 12A, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), OUTPUT CODE: BINARY, DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 603 ML 470 ID.-NR. 237640-07 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LS 903 ML 170 ID.-NR. 209081-94 HEIDENHAIN INCREMENTAL ENCAPSULATED LENGTH GAUGE WITH SMALL PROFILED SCALE HOUSING MEASURING LENGTH: 1240 MM ACCURACY CLASS: 5.0 ΜM, MOUNTING TYPE: END PIECES, OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11ΜA) REFERENCE MARKING: 45, MM, REFERENCE MARKING 2: 1150MM, ELECTRICAL CONNECTION: PLUG M23, METAL HOUSING, PEN 9 PIN, CABLE LENGTH: 3.00 M

LS 106 ML 140 ID.-NR. 275066-11 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 140 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE SCREW-ON STRIP, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 106 ML 440 ID.-NR. 275066-15 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 440 MM, ACCURACY GRADE ± 5.0 µM, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 106 ML 140 ID.-NR 295709-11 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 140 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE SCREW-ON STRIP, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION 70 ML/2, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 477 ML 420 ID.-NR. 605379-42 HEIDENHAIN INCREMENTAL ENCAPSULATED LENGTH GAUGE WITH SMALL PROFILED SCALE HOUSING MEASURING LENGTH: 420 MM, ACCURACY CLASS: ± 5.0 ΜM, FASTENING MODE: END PIECES + MOUNTING RAIL OUTPUT SIGNAL: RECTANGULAR SIGNALS, TTL LEVEL WITH 5-FOLD INTERPOLATION REFERENCE MARKING: DISTANCE 35 MM FROM THE BEGINNING OF THE MEASURING LENGTH, ELECTRICAL CONNECTION: FLANGE SOCKET, PIN, 14-PIN

LC 183 ML 640 ID.-NR. 557660-05 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 640 MM, ACCURACY GRADE 5.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 703 ML 3040 ID.-NR. 336976-28 HEIDENHAIN SEALED LINEAR ENCODER, MEASURING LENGTH 3040 MM, ACCURACY GRADE +/- 0,005 MM, OUTPUT SIGNALS SINUSOIDAL (11 UASS), REFERENCE MARKS ONE REFERENCE MARK AT MID- POINT OF MEASURING LENGTH MOVEABLE BY 50 MM STEPS, ELECTRICAL CONNECTION VIA ADAPTER CABLE
