LC 495S ML 120 ID.-NR. 760940-02 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH: 120 MM, TOTAL LENGTH: ML+138 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 495F ML 70 ID.-NR. 760932-01 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH: 70 MM, TOTAL LENGTH: ML+138 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 495F ML 220 ID.-NR. 760932-04 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH: 220 MM, TOTAL LENGTH: ML+138 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 495S ML 370 ID.-NR. 760942-07 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 370 MM, TOTAL LENGTH ML+138 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, END BLOCK 12A, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 406C ML 770 ID.-NR. 310750-21 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION, MEASURING LENGTH 770 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LIP 489A ID.-NR. 1284898-02 HEIDENHAIN INCREMENTAL EXPOSED LINEAR ENCODER WITH HIGH ACCURACY, SIGNAL PERIOD 2µM, ACCURACY GRADE +/-1µM, MEASURING LENGTH 16MM, REFERENCEMARK POSITION NONE, ADDITIONAL REFER. MARKS NONE, OUTPUT SIGNALS SINUSOIDAL VOLTAGE SIGNALS (1VPP), CABLE LENGTH 1,0M, ELECTRICAL CONNECTION D-SUB CONNECTOR MALE, 15-PIN, 2-ROW WITH INTEGRATED ELECTRONICS

LC 183 ML 940 ID.-NR. 557660-08 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH: 940 MM, ACCURACY GRADE: 5.0 µM, FASTENING TYPE: SCREW-ON STRIP INTEGRATED, DATA INTERFACE: ENDAT02 SYNCHRONOUS SERIAL, ENDAT 2.2 WITH INCREMENTAL SIGNALS, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 629 ML 220 ID.-NR. 643307-01 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION WITH INTEGRATED GUIDEWAY FOR BENDING MACHINES MEASURING LENGTH: 220 MM ACCURACY GRADE: ± 10.0 µM, FASTENING TYPE: END BLOCKS, RIGHT END BLOCK FLEXIBLE OUTPUT SIGNAL: SQUARE-WAVE SIGNALS, TTL LEVELS REFERENCE MARK POSITION:ML/2 IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 495F ML 570 ID.-NR. 760930-11 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 570 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: NO SPECIFIED VALUE, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 495S ML 670 ID.-NR. 760939-13 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 670 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE END BLOCK + MOUNTING SPAR END BLOCK: 14A OUTPUT SIGNAL NO SPECIFIED VALUE OUTPUT CODE DUAL DATA ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 486 ML 570 ID.-NR. 329990-19 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 570 MM ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION:35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH WITH TWO REFERENCE MARKS, FURTHER REFERENCE MARKS:35 MM DISTANCE FROM END OF MEASURING LENGTH WITH TWO REFERENCE MARKS, ELECTRICAL CONNECTION: SEPARATE ADAPTER CABLE

LS 187C ML 740 ID.-NR. 527392-07 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 740 MM ACCURACY GRADE: ± 3.0 µM FASTENING TYPE: SCREW-ON STRIP INTEGRATED OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 187C ML 1040 ID.-NR. 527392-10 HEIDENHAIN NCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH: 1040 MM ACCURACY GRADE: ± 3.0 µM FASTENING TYPE: SCREW-ON STRIP INTEGRATED OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP) ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 303 ML 420 ID.-NR. 228975-11 HEIDENHAIN SEALED LINEAR ENCODER, MEASURING LENGTH 420MM, ACCURACY GRADE +/- 0,010MM, CABLE LENGTH 3,00M, WITH CONNECTOR WITHOUT ARMOR

LC 485 ML 1540 ID. 689681-52 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 1540 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE END BLOCK + MOUNTING SPAR END BLOCK 14A OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP) OUTPUT CODE BINARY ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 704 ML 720 ID.-NR. 237133-05 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER, MEASURING LENGTH 720MM, ACCURACY GRADE +/-0,005MM, CABLE LENGTH 3,00M, WITH CONNECTOR WITHOUT ARMOR

LS 403 ML 370 ID.-NR. 297810-59 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER

LIDA 325 ML 1040 ID.-NR. 214087-32 HEIDENHAIN SCALE TAPE, MEASURING LENGTH 1040

LIDA 325 ML 440 ID.-NR. 214087-29 HEIDENHAIN SCALE TAPE, MEASURING LENGTH 440

LS 303 ML 570 ID.-NR. 228975-39 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER, MEASURING LENGTH 570

LS 383C ML 270 ID.-NR. 1326653-19 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER LS383C WITH SMALL CROSS SECTION MEASURING LENGTH 270 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE END BLOCKS FOR M4 MOUNTING SCREWS OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD CABLE LENGTH 3.00 M ELECTRICAL CONNECTION CONNECTOR M23, MALE, 12-PIN

LC 181 ML 1140 ID.-NR. 341240-32 HEIDENHAIN ABSOLUTE LINEAR ENCODER, MEASURING LENGTH 1140MM, ACCURACY GRADE +/-0,003 MM, INCREMENTAL SIGNALS SINUSOIDAL VOLTAGE SIGNALS (1VPP), ELECTRICAL CONNECTION VIA CABLE ASSEMBLY

LS 186 ML 190 ID.-NR. 295711-37 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 190 MM, ACCURACY GRADE ± 3.0 µM, FASTENING TYPE SCREW-ON STRIP, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION 120 ML/2, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 476C ML 70 ID.-NR. 329989-01 HEIDENHAIN SEALED LINEAR ENCODER WITH OPTIMIZED THERMAL BEHAVIOR WITH MOUNTING SPAR MEASURING LENGTH 70 MM, ACCURACY GRADE 0,005 MM, OUTPUT SIGNALS SQUAREWAVE TTL, REFERENCE MARK DISTANCE-CODED, ELECTRICALCONNECTION WITH SEPARATE CABLE ASSEMBLY

LS 403 ML 320 ID.-NR. 334755-8E HEIDENHAIN SEALED LINEAR ENCODER OUTPUT SIGNALS SINUSOIDAL POWER SIGNALS (11 µASS) SIGNAL PERIOD 0,020 MM ACCURACY +/- 0,005 MM ELECTRICAL CONNECTION CABLE 3 M WITH CONNECTOR WITHOUT ARMOR MEASURING LENGTH 320 MM

LF 185 ML 540 ID.-NR. 682433-02 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 540 MM, ACCURACY GRADE ±3.0 µM, FASTENING TYPE SCREW-ON STRIP, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION ML/2 - IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 176 ML 440 ID.-NR. 295710-95 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 440 MM, ACCURACY GRADE 5.0 µM, FASTENING TYPE A SCREW-ON STRIP, OUTPUT SIGNAL SQUARE-WAVE SIGNALS, TTL LEVELS WITH 5-FOLD INTERPOLATION REFERENCE MARK POSITION 220, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 487 ML 520 ID.-NR. 572251-10 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 520 MM ACCURACY GRADE ± 5.0 µM FASTENING TYPE END BLOCK + MOUNTING SPAR OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP) REFERENCE MARK POSITION 35 MM DISTANCE FROM THE BEGINNING OF THE MEASURING LENGTH ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LC 195F ML 940 ID.-NR. 760907-09 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 940 MM ACCURACY GRADE 5.0 µM GRATING PERIOD 20.000 µM FASTENING TYPE SCREW-ON STRIP INTEGRATED DATA INTERFACE FANUC05 SERIAL INTERFACE FANUC ALPHA/ALPHAI ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 1679 ML 420 ID.-NR. 589221-39 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION, MEASURING LENGTH 420 MM, ACCURACY GRADE ± 10.0 µM, FASTENING TYPE END BLOCK, REFERENCE MARK POSITION 35 MM (DISTANCE IN MM FROM THE END OF THE MEASURING LENGTH, SELECTABLE), ELECTRICAL CONNECTION CONNECTOR M23, MALE, 12-PIN, CABLE LENGTH 0.50 M

LS 623 ML 320 ID.-NR. 336974-7T HEIDENHAIN INCREMENTAL LINEAR ENCODER, MEASURING LENGTH 320MM, ACCURACY GRADE +/- 0,010MM, OUTPUT SIGNALS SQUARE-WAVE SIGNAL,TTL LEVEL, REFERENCE MARKS Z=300MM, ELECTRICAL CONNECTION VIA ADAPTER CABLE

LS 503 ML 1140 ID.-NR. 216760-29 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1140

LS 487C ML 1540 ID.-NR. 560526-23 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 1540 MM, TOTAL LENGTH: ML+105 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION: C001 - DISTANCE-CODED  REFERENCE MARKS WITH NOMINAL INCREMENT 1000 X GRATING PERIOD, ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 485 ML 770 ID.-NR. 689678-15 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 770 MM, TOTAL LENGTH:  ML+138 MM, ACCURACY GRADE: ± 3.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LC 191F ML 2440 ID.-NR. 341241-44 HEIDENHAIN SEALED ABSOLUTE LINEAR ENCODER, ACCURAY: +/-0,003MM, MEASURING LENGTH: 2440MM, ELECTRICAL CONNECTION: VIA ADAPTER CABLE

LC 483 ML 620 ID.-NR. 557653-06 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH: 620 MM, TOTAL LENGTH: ML+138 MM, ACCURACY GRADE: ± 5.0 µM, FASTENING TYPE: END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION: FLANGE SOCKET, MALE, 14-PIN

LS 704 ML 470 ID.-NR 237133-72 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 470,

LS 704 ML 370 ID.-NR. 237133-1M HEIDENHAIN INCREMENTAL SEALED MEASURING LENGTH: 370 MM

LS 107 ML 1140 ID.-NR. 243889-0F HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 1140, ACCURACY GRADE +/-0,003MM, REFERENCE MARK AT Z= 570MM, CABLE LENGTH 3,00M, WITH CONNECTOR WITHOUT ARMOR

LS 704 ML 920 ID.-NR. 237133-FG HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 920,

LS 704 ML 2240 ID.-NR. 237133-FN HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 2240 M

LC 481 ML 720 ID.-NR. 337461-01 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE MEASURING LENGTH 720 MM, ACCURACY GRADE ± 3.0 µM, FASTENING TYPE MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LC 481 ML 720 ID.-NR. 372849-01 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE MEASURING LENGTH 720 MM, ACCURACY GRADE ± 3.0 µM, FASTENING TYPE MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 186 ML 340 ID.-NR. 336960-39 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 340 MM, ACCURACY GRADE ± 3.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION IN THE MIDDLE OF THE MEASURING LENGTH, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LC 481 ML 820 ID.-NR. 337461-42 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION FOR ABSOLUTE POSITION CAPTURE MEASURING LENGTH 820 MM, ACCURACY GRADE ± 3.0 µM, FASTENING TYPE MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LC 195S ML 340 ID.-NR. 760914-03 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH LARGE CROSS SECTION MEASURING LENGTH 340 MM, ACCURACY GRADE 3.0 µM, FASTENING TYPE SCREW-ON STRIP INTEGRATED, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN

LS 486C ML 120 ID.-NR. 310873-04 HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 120 MM, ACCURACY GRADE ± 5.0 µM, FASTENING TYPE END BLOCK + MOUNTING SPAR, OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK POSITION DISTANCE-CODED REFERENCE MARKS, ELECTRICAL CONNECTION SEPARATE ADAPTER CABLE

LS 403 ML 620 ID.-NR. 334755-3V HEIDENHAIN SEALED LINEAR ENCODER MEASURING LENGTH 620 MM, ACCURACY +/- 0,003 MM, REFERENCE MARK Z=35 MM, Z1=550 MM, OUTPUT SIGNALS SINUSOIDAL POWER SIGNALS (11 µASS), ELECTRICAL CONNECTION CABLE 0,30 M WITH FLANGE SOCKET ON CONNECTION FIXTURE

LS 704 ML 2840 ID.-NR. 237133-CT HEIDENHAIN INCREMENTAL SEALED LINEAR ENCODER MEASURING LENGTH 2840 MM

LC 483 ML 820 ID.-NR. 557648-16 HEIDENHAIN ABSOLUTE SEALED LINEAR ENCODER WITH SMALL CROSS SECTION MEASURING LENGTH 820 MM ACCURACY GRADE ± 3.0 µM GRATING PERIOD  20.000 µM FASTENING TYPE MOUNTING SPAR OUTPUT SIGNAL SINUSOIDAL VOLTAGE SIGNALS (1 VPP) OUTPUT CODE BINARY DATA INTERFACE ENDAT02 SYNCHRONOUS SERIAL ENDAT 2.2 WITH INCREMENTAL SIGNALS ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 14-PIN
