1PH

1PH7167-2QF03-0CJ2 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 37 KW, 1500 RPM, 235.5 NM, VC: 41 KW, 1750 RPM, 223.7 NM, 82 A, VC: 79 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV; WITH DRIVE-CLIQ INTERFACE, ND-END AT TERMINAL BOX TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE S, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH, FLANGE ON DRIVE END WITH SHAFT SEAL

1PH8105-1FG22-0CH1-Z SIEMENS SIMOTICS M COMPACT ASYNCHRONOUS MOTOR 2000RPM, 13KW,62NM, 34,5A,326V 2300RPM, 15KW, 62NM, 34A, 370V 2650RPM, 17KW,61NM, 33,5A, 424V WATER COOLING DEGREE OF PROTECTION IP65 ABSOLUTE ENCODER 22 BIT SINGLETURN AND 12 BIT MULTITURN (ENCODER AM22DQ) WITH DRIVE-CLIQ INTERFACE DESIGN IM B5 (IMV 1,IM V3) PLAIN SHAFT WITHOUT FITTED KEY; BEARING: STANDARD WITH FIXED BEARING, VIBRATION SEVERITY GRADE: S/A, SHAFT AND FLANGE ACCURACY: R POWER CONNECTOR (ABOVE) CABLE ENTRY ON THE ND-END SIGNAL CONNECTION LEFT

1PH6137-4CF46-Z SIEMENS SPINDLE MOTOR

1PH7133-2ND00-0BA0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 12KW, 1000RPM, 114.6NM VC: 13.5KW, 1150RPM, 112.1NM 30 A, VC: 29.5A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B3 (IM V5, IM V6) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH7103-2NG02-0CB0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 7KW, 2000RPM, 33.4NM VC: 7.5KW, 2300RPM, 31.1NM 17.5A, VC: 17A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY LEVEL S, SHAFT AND FLANGE ACCURACY R FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM BS TO AS IP55, FAN IP54 UNPAINTED

1PH7107-2NF03-0BK0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 9KW, 1500RPM, 57.3NM VC: 10 KW, 1750RPM, 54.6NM 23.5A, VC: 23A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM BS TO AS IP55, FAN IP54 UNPAINTED

1PH7107-7QF03-0BK0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 9KW, 1500RPM, 57.3NM VC: 10 KW, 1750RPM, 54.6NM 23.5A, VC: 23A, WITHOUT BRAKE 400 V 3 AC, 50 HZ, WITH FAN METRIC CABLE ENTRY TO EN 50262 REL. MOTOR ENCODER 1 VSS 2048 P/U WITH DRIVE-CLIQ INTERFACE NDE-SIDE ON TERMINAL BOX TERMINAL BOX ON TOP, CABLE ON RIGHT DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM BS TO AS IP55, FAN IP54 UNPAINTED

1PH7167-2NF03-0BC0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 37KW, 1500RPM, 235.5NM VC: 41KW, 1750RPM, 223.7NM 82A, VC: 79A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R FITTED KEY + FULL-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH8107-1SG02-3LE1 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 2000RPM, 10.5KW 50NM, 26 A, 355V 2300RPM, 12KW 50NM, 26 A, 406V 2650RPM, 13KW 47NM, 24A, 460 V FORCED VENTILATION; DIRECTION OF AIR FLOW DE--> NDE; DEGREE OF PROTECTION IP55 INCREMENTAL ENCODER 19 BIT WITH COMMUTATING POSITION (ENCODER IN19DQ) WITH DRIVE-CLIQ INTERFACE DESIGN IM B5 (IMV 1,IM V3) PLAIN HOLLOW-SHAFT BEARING: PERFORMANCE, VIBRATION SEVERITY GRADE SPECIAL/B; SHAFT A. FLANGE ACCURACY GR. SPECIAL POWER CONNECTOR (ABOVE) CABLE ENTRY ON THE RIGHT SIGNAL CONNECTION D-END

1PH7184-2NE30-0GC0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 40KW, 1250RPM, 306NM 85A, WITHOUT BRAKE WITH FAN CABLE GLAND ENTRY REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON LEFT TYPE OF CONSTRUCTION IM B3 BEARING FOR BELT OUTPUT (WITH SHEAR FORCE) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY N FITTED KEY + FULL-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 PRIME-COATED PAINT FINISH

1PH8165-1DF03-0CA1 SIEMENS SIMOTICS M COMPACT ASYNCHRONOUS MOTOR 1500RPM, 37KW, 236NM, 78A, 350V 1750RPM, 41KW, 224NM, 76A, 400V 2000RPM, 45KW, 215NM, 75A, 440V FORCED VENTILATION; DIRECTION OF AIR FLOW DE --> NDE; DEGREE OF PROTECTION IP55 INCREMENTAL ENCODER 22 BIT WITH COMMUTATING POSITION (ENCODER IC22DQ) WITH DRIVE-CLIQ INTERFACE DESIGN IM B35 (IM V15, IM V35) PLAIN SHAFT WITHOUT FITTED KEY; BEARING: STANDARD WITH FIXED BEARING, VIBRATION SEVERITY GRADE S/A; SHAFT AND FLANGE ACCURACY: R TERMINAL BOX (ABOVE) CABLE ENTRY ON THE RIGHT SIGNAL CONNECTION D-END

1PH7133-2NF02-0CJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 15 KW, 1500RPM, 95.5NM VC: 17.5KW, 1750RPM, 95.5NM 34A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY LEVEL S, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH7131-2NF00-0BC0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 11KW, 1500RPM, 70NM VC: 13KW, 1750RPM, 70.9NM 24A, VC: 25A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B3 (IM V5, IM V6) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R FITTED KEY + FULL-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH6103-1NF47-2AA0 SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 5.5 KW, 1500 REV/MIN, 35 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM V15; TERMINAL BOX; ON TOP;CABLE INFEED/ND-END; ROT. ACCURACY TOLERANCE N VIBRATION SEVERITY R WITH TWIN-BEARINGS; SHAFT END ON D-END, W. FEATHER KEY , AIR FLOW DIR. BOTTOM; DEGREE OF PROT. IP 54

1PH7163-7ND03-0CJ3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR, CORE TYPE 22KW, 1000RPM, 210.1NM VC: 25KW, 1150RPM, 207.6NM 55A, 400V 3AC 50HZ WITH FAN, WITHOUT BRAKE RELATIVE MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP CABLE ON RIGHT METRICAL CABLE ENTRY DESIGN IM B35 (IM V15, IM V36)

1PH6186-4CB90-Z SIEMENS AC-MOTOR

1PH7107-2HD00-0BC3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 6.25KW, 1000RPM, 59.7NM VC: 7.2KW, 1150RPM, 59.8NM 17.5A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN RELATIVE MOTOR ENCODER HTL 1024 INCR./REV. TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B3 (IM V5, IM V6) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R FITTED KEY + FULL-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 STANDARD PAINT FINISH (RAL 7016)

1PH8107-1VG02-3LE1 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 2000RPM, 10.5KW 50NM, 26 A, 355V 2300RPM, 12KW 50NM, 26 A, 406V 2650RPM, 13KW 47NM, 24A, 460 V FORCED VENTILATION; DIRECTION OF AIR FLOW DE--> NDE; DEGREE OF PROTECTION IP55 INCREMENTAL ENCODER 19 BIT WITH COMMUTATING POSITION (ENCODER IN19DQ) WITH DRIVE-CLIQ INTERFACE DESIGN IM B5 (IMV 1,IM V3) PLAIN HOLLOW-SHAFT BEARING: PERFORMANCE, VIBRATION SEVERITY GRADE SPECIAL/B; SHAFT A. FLANGE ACCURACY GR. SPECIAL POWER CONNECTOR (ABOVE) CABLE ENTRY ON THE RIGHT SIGNAL CONNECTION D-END

1PH7163-2NF00-0DK3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 30 KW, 1500RPM, 191NM VC: 34KW, 1750RPM, 185.5NM 72A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B3 (IM V5, IM V6) VIBRATION SEVERITY GRADE SR, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM BS TO AS IP55, FAN IP54 STANDARD PAINT FINISH (RAL 7016)

1PH7103-7JF33-2KA3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 5.5KW, 1500RPM, 35NM VC: 6.3KW, 1750RPM, 34.4NM 13 A, WITH BRAKE 400 V 3 AC, 50 HZ, WITH FAN METRIC CABLE ENTRY TO EN 50262 RELATIVE MOTOR ENCODER HTL 2048 INCR./REV. TERMINAL BOX ON TOP, CABLE ON LEFT DESIGN IM B35 (IM V15, IM V36) WITH 230 V BRAKE AND MICROSWITCH VIBRATION SEVERITY GRADE A, SHAFT AND FLANGE PRECISION N FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 STANDARD PAINT FINISH (RAL 7016)

1PH7131-2NF02-0CJ2 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 11KW, 1500RPM, 70NM VC: 13KW, 1750RPM, 70.9NM 24A, VC: 25A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY LEVEL S, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED AS FLANGE WITH SHAFT SEALING RING

1PH7167-2QF03-0CJ3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR, CORE TYPE 37KW, 1500RPM, 235.5NM VC: 41KW, 1750RPM, 223.7NM 82A, VC: 79A, 400V 3AC 50HZ WITH FAN, WITHOUT BRAKE RELATIVE MOTOR ENCODER 1 VSS 2048 P/U WITH DRIVE-CLIQ INTERFACE ON NDE SIDE ON TERMINAL BOX TERMINAL BOX ON TOP: CABLE ON RIGHT PG CABLE ENTRY DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE S SHAFT/FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 STANDARD PAINT FINISH (RAL 7016)

1PH7107-2NF02-0CA3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR, CORE TYPE 9KW, 1500RPM, 57.3NM VC: 10 KW, 1750RPM, 54.6NM 23.5A, VC: 23A, 400V 3AC 50HZ WITH FAN, WITHOUT BRAKE RELATIVE MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP CABLE RIGHT PG CABLE ENTRY TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE S SHAFT/FLANGE ACCURACY R FEATHER KEY AND HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 STANDARD PAINT FINISH (RAL 7016)

1PH8105-1AF02-2BA1 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 1500RPM, 7.0 KW 45NM, 17.5A, 348V 1750RPM, 8.0KW 44NM, 17.5A, 400 V 2000RPM, 9.0KW 43NM, 17.0A, 453V FORCED VENTILATION; DIRECTION OF AIR FLOW DE--> NDE; DEGREE OF PROTECTION IP55 W/O ENCODER WITH TEMPERAT. SENSOR KTY84-130 DESIGN IM B5 (IMV 1,IM V3) SHAFT WITH FITTED KEY HALF-KEY BALANCING BEARING: STANDARD WITH FIXED BEARING, VIBRATION SEVERITY GRADE: R/A, SHAFT AND FLANGE ACCURACY: R TERMINAL BOX (ABOVE) CABLE ENTRY ON THE RIGHT SIGNAL CONNECTION D-END

1PH6163-4NB49-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH6138-4FF00-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH7133-2QD02-0CB0-Z SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 12KW, 1000RPM, 114.6NM VC: 13.5KW, 1150RPM, 112.1NM 30 A, VC: 29.5A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U WITH DRIVE-CLIQ INTERFACE NDE-SIDE ON TERMINAL BOX TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY LEVEL S, SHAFT AND FLANGE ACCURACY R FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM BS TO AS IP55, FAN IP54 UNPAINTED

1PH6133-4ZF00-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH7107-8ND32-0CJ3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 6.25KW, 1000RPM, 59.7NM VC: 7.2KW, 1150RPM, 59.8NM 17.5A, WITHOUT BRAKE WITHOUT FAN, FOR PIPE CONNECTION, METRIC CABLE ENTRY TO EN 50262 REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON LEFT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY LEVEL S, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 STANDARD PAINT FINISH (RAL 7016)

1PH7107-2NG02-0CJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 10.5KW, 2000RPM, 50.1NM VC: 12KW, 2300RPM, 49.8NM 26 A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY LEVEL S, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH7163-2QF03-0CJ3-Z SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR, CORE TYPE 30 KW, 1500RPM, 191NM VC: 34KW, 1750RPM, 185.5NM 72A, 400V 3AC 50HZ WITH FAN, WITHOUT BRAKE RELATIVE MOTOR ENCODER 1 VSS 2048 P/U WITH DRIVE-CLIQ INTERFACE ON NDE SIDE ON TERMINAL BOX TERMINAL BOX ON TOP: CABLE ON RIGHT PG CABLE ENTRY DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE S SHAFT/FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 STANDARD PAINT FINISH (RAL 7016)

1PH8137-3DD02-0AF1-Z SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 1000RPM, 17KW 162NM, 43A, 307V 1150RPM, 19.5KW 162NM, 43A, 350 V 1350RPM, 22 KW 156NM, 42A, 404V FORCED VENTILATION; DIRECTION OF AIR FLOW DE--> NDE; DEGREE OF PROTECTION IP55

1PH8107-1DG02-0CE1 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 2000RPM, 10.5KW 50NM, 26 A, 355V 2300RPM, 12KW 50NM, 26 A, 406V 2650RPM, 13KW 47NM, 24A, 460 V FORCED VENTILATION; DIRECTION OF AIR FLOW DE--> NDE; DEGREE OF PROTECTION IP55 INCREMENTAL ENCODER 22 BIT WITH COMMUTATING POSITION (ENCODER IC22DQ) WITH DRIVE-CLIQ INTERFACE DESIGN IM B5 (IMV 1,IM V3) PLAIN SHAFT WITHOUT FITTED KEY; BEARING: STANDARD WITH FIXED BEARING, VIBRATION SEVERITY GRADE: S/A, SHAFT AND FLANGE ACCURACY: R POWER CONNECTOR (ABOVE) CABLE ENTRY ON THE RIGHT SIGNAL CONNECTION D-END

1PH7167-2HF03-0LB3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 37KW, 1500RPM, 235.5NM VC: 41KW, 1750RPM, 223.7NM 82A, VC: 79A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN RELATIVE MOTOR ENCODER HTL 1024 INCR./REV. TERMINAL BOX ON TOP, CABLE ON RIGHT DESIGN IM B35 (IM V15, IM V36) BEARING FOR INCREASED MAXIMUM SPEED VIBRATION SEVERITY GRADE SR, SHAFT AND FLANGE ACCURACY R FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM BS TO AS IP55, FAN IP54 STANDARD PAINT FINISH (RAL 7016)

1PH7184-2HF04-0GB3-Z SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 51KW, 1500RPM, 324.7NM VC: 60KW, 1750RPM, 327.4NM 122A, WITHOUT BRAKE WITH FAN CABLE GLAND ENTRY RELATIVE MOTOR ENCODER HTL 1024 INCR./REV. TERMINAL BOX ON TOP, CABLE ON RIGHT DESIGN IM B35, FLANGE 450 BEARING FOR BELT OUTPUT (WITH SHEAR FORCE) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY N FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM NDE TO DE IP55, FAN IP54 STANDARD PAINT FINISH (RAL 7016)

1PH7103-7DG02-0KA0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 7KW, 2000RPM, 33.4NM VC: 7.5KW, 2300RPM, 31.1NM 17.5A, VC: 17A, WITHOUT BRAKE 400 V 3 AC, 50 HZ, WITH FAN METRIC CABLE ENTRY TO EN 50262 REL. MOTOR ENCODER 1 VSS 2048 P/U; WITH DRIVE-CLIQ INTERFACE NDE-SIDE ON TERMINAL BOX TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE A, SHAFT AND FLANGE ACCURACY N FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH7103-7DG02-5KA0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 7KW, 2000RPM, 33.4NM VC: 7.5KW, 2300RPM, 31.1NM 17.5A, VC: 17A, WITH BRAKE 400 V 3 AC, 50 HZ, WITH FAN METRIC CABLE ENTRY TO EN 50262 REL. MOTOR ENCODER 1 VSS 2048 P/U; WITH DRIVE-CLIQ INTERFACE NDE-SIDE ON TERMINAL BOX TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) WITH 24 V DC BRAKE VIBRATION SEVERITY GRADE A, SHAFT AND FLANGE PRECISION N FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH7133-2QG02-0CJ2 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 20 KW, 2000RPM, 95.5NM VC: 22.5KW, 2300RPM, 93.4NM 45 A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U WITH DRIVE-CLIQ INTERFACE NDE-SIDE ON TERMINAL BOX TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY LEVEL S, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED AS FLANGE WITH SHAFT SEALING RING

1PH7163-2NF00-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 30 KW, 1500RPM, 191NM VC: 34KW, 1750RPM, 185.5NM 72A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B3 (IM V5, IM V6) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH7186-7QE00-0GC0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 60KW, 1250RPM, 458.4NM 120 A, WITHOUT BRAKE WITH FAN, METRIC CABLE ENTRY TO EN 50262 INCREMENTAL ENCODER SIN/COS 1 VPP (WITH C AND D TRACK) WITH DRIVE-CLIQ INTERFACE TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B3 BEARING FOR BELT OUTPUT (WITH SHEAR FORCE) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY N FITTED KEY + FULL-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 PRIME-COATED PAINT FINISH

1PH7107-2NF22-0LJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 9KW, 1500RPM, 57.3NM VC: 10 KW, 1750RPM, 54.6NM 23.5A, VC: 23A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE NDE TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) BEARING FOR INCREASED MAXIMUM SPEED VIBRATION SEVERITY GRADE SR, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH7107-2AF02-0BJ3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 9KW, 1500RPM, 57.3NM VC: 10 KW, 1750RPM, 54.6NM 23.5A, VC: 23A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN NO MOTOR ENCODER TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 STANDARD PAINT FINISH (RAL 7016)

1PH7133-2NG02-0DA0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 20 KW, 2000RPM, 95.5NM VC: 22.5KW, 2300RPM, 93.4NM 45 A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE SR, SHAFT AND FLANGE ACCURACY R FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH7137-2NG22-0CA2 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 28KW, 2000RPM, 133.7NM VC: 29KW, 2300RPM, 120.4NM 60A, VC: 56A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE NDE TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY LEVEL S, SHAFT AND FLANGE ACCURACY R FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED AS FLANGE WITH SHAFT SEALING RING

1PH7103-2QG32-0LJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 7KW, 2000RPM, 33.4NM VC: 7.5KW, 2300RPM, 31.1NM 17.5A, VC: 17A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U WITH DRIVE-CLIQ INTERFACE NDE-SIDE ON TERMINAL BOX TERMINAL BOX ON TOP, CABLE ON LEFT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) BEARING FOR INCREASED MAXIMUM SPEED VIBRATION SEVERITY GRADE SR, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH7137-2NG22-0CB2 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 28KW, 2000RPM, 133.7NM VC: 29KW, 2300RPM, 120.4NM 60A, VC: 56A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE NDE TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY LEVEL S, SHAFT AND FLANGE ACCURACY R FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM BS TO AS IP55, FAN IP54 UNPAINTED AS FLANGE WITH SHAFT SEALING RING

1PH8107-1MF02-2CD1 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 1500RPM, 9.0KW 57NM, 23.5A, 330V 1750RPM, 10.0KW 55NM, 22A, 380 V 2000RPM, 11 KW 53NM, 21.5A, 428V FORCED VENTILATION; DIRECTION OF AIR FLOW DE--> NDE; DEGREE OF PROTECTION IP55 INCREMENTAL ENCODER SIN/COS 1VPP 2048 S/R WITH ND-END AT TERMINAL BOX (ENCODER IC2048S/R) WITH TEMPERAT. SENSOR KTY84-130 DESIGN IM B5 (IMV 1,IM V3) SHAFT WITH FITTED KEY HALF-KEY BALANCING BEARING: STANDARD WITH FIXED BEARING, VIBRATION SEVERITY GRADE: S/A, SHAFT AND FLANGE ACCURACY: R TERMINAL BOX (ABOVE) CABLE ENTRY ON THE D-END SIGNAL CONNECTION LEFT

1PH8137-1CG02-0LA1-Z SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 2000RPM, 28KW, 134NM, 60A, 350 V 2300RPM, 29KW, 120NM, 56A, 400 V 2650RPM, 30 KW, 108NM, 52A, 460 V FORCED VENTILATION; DIRECTION OF AIR FLOW DE--> NDE; DEGREE OF PROTECTION IP55

1PH8138-4EF20-0AA2 SIEMENS SIMOTICS M COMPACT SYNCHRONOUS MOTOR 1500RPM,44,9KW,286NM,118A, 316V 1750RPM,52,4KW,286NM,118A, 366V 2000RPM,59,7KW,285NM,118A, 416V WATER COOLING DEGREE OF PROTECTION IP65 ABSOLUTE ENCODER ENDAT 2048 S/R (ENCODER AM2048S/R) with TEMPERATURE SENSOR PT1000 DESIGN IM B3 (IM V5, IM V6) PLAIN SHAFT WITHOUT FITTED KEY; BEARING: STANDARD VIBRATION SEVERITY GRADE A; SHAFT A.FLANGE ACCURACY GR.N TERMINAL BOX (ABOVE) CABLE ENTRY ON THE RIGHT SIGNAL CONNECTION D-END

1PH6167-4NG46-Z SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 45 KW, 2000 REV/MIN, 215 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B 35
