Motors

1FT6086-8SF71-4AH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 35 NM, 100 K, 3000 RPM SEPARATE VENTILATION; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL DRIVE END INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); PLAIN SHAFT, ACCURACY TOLERANCE N, W. HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END

1FK6040-6AK71-1TH0 SIEMENS SYNCHRONOUS SERVOMOTOR 1FK6 6-POLE MOTOR, 1.6 NM, 100 K, 6000 RPM NATURAL AIR COOLING, IM B5 (V1, V3) POWER/SIGNAL CONNECTORS CONNECTOR ROTAT. BY 270 DEG., 270 DEGR., RESOLVER 2-POLE (RESOLVER P=1); PLAIN SHAFT, TOLERANCE N WITH HOLDING BRAKE; DEGREE OF PROT. IP64;

1FT6062-1AH71-3EH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 6.0 NM, 100 K, 4500 RPM NATURAL AIR COOLING, IP65 IM B5 (IM V1, IM V3) ABSOLUTE VALUE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION AXIAL NON-DRIVE END WITH HOLDING BRAKE;

1FT6064-6AK71-4AA2 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 9.5 NM, 100 K, 6000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL, DRIVE END INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); WITH FITTED KEY, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, ROTARY SHAFT SEAL (IP 67)

1FT6062-6AK71-3AG2 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 6.0 NM, 100 K, 6000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL, NON-DRIVE END INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); PLAIN SHAFT, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, ROTARY SHAFT SEAL (IP 67)

1FT6086-8AF71-3EG2 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 27 NM, 100 K, 3000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL NON-DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, ROTARY SHAFT SEAL (IP 67)

1FK6042-6AF71-1TH0 SIEMENS SYNCHRONOUS SERVOMOTOR 1FK6 6-POLE MOTOR, 3.2 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IM B5 (V1, V3) POWER/SIGNAL CONNECTORS CONNECTOR ROTAT. BY 270 DEG., 270 DEGR., RESOLVER 2-POLE (RESOLVER P=1); PLAIN SHAFT, TOLERANCE N WITH HOLDING BRAKE; DEGREE OF PROT. IP64

1FT6082-8AF71-3AB1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 13 NM, 100 K, 3000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL NON-DRIVE END INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); WITH FITTED KEY, ACCURACY TOLERANCE N, W. HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END

1FK7064-7AF71-1AA3 SIEMENS SIMOTICS S SYNCHRONOUS SERVO MOTOR 1FK7 HIGH DYNAMIC, 12.0 NM 100K, 3000 RPM, 2.5 KW NATURALLY COOLED IM B5 (V1, V3) POWER/SIGNAL CONNECTOR PLUG ROTATABLE BY 270° INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); SHAFT WITH FITTED KEY, TOLERANCE N; W/O HOLDING BRAKE DEGREE OF PROTECTION IP64; PAINT FINISH RAL7016

1FT6108-8AB71-4AA0 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 70 NM, 100 K, 1500 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL DRIVE END INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); WITH FITTED KEY, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, DIAPHRAGM SEAL (IP 64)

1FT6086-8AC71-3EA1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 27NM, 100K, 2000RPM, 4,7KW NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL NON-DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; WITH FITTED KEY, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END

1FT6086-8AC71-3EG1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 27NM, 100K, 2000RPM, 4,7KW NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL NON-DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END

1FT6105-1AC71-3EG1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 50 NM, 100 K, 2000 RPM NATURAL AIR COOLING, IP65 IM B5 (IM V1, IM V3) ABSOLUTE VALUE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION AXIAL NON-DRIVE END WITHOUT HOLDING BRAKE;

1FT5072-0AK01-2-Z   Z= K01 SIEMENS AC FEED DRIVE MOTOR, DC LINK 210 V 12 NM, 100 K, 6000 RPM, AIR COOLING, TACHOGENERATOR A. SHAFT POSITION ENCODER, IP64, IM B5 (IM V1,IM V3) F. TERMINAL BOX AND SIGNAL CONNECTOR ADD.

1FT6044-1AF71-4AH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 5.0 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IP65 IM B5 (IM V1, IM V3) INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION AXIAL DRIVE END WITH HOLDING BRAKE;

1FT6064-6AC71-4EH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 9.5 NM, 100 K, 2000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL, DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W. HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65)

1FT6021-6AK71-4HH5 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 0.4 NM, 100 K, 6000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION AXIAL DRIVE END ABSOLUTE ENCODER 512 P/REV (ENCODER A-512); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ROTAT.TOLERANCE N, WITH HOLDING BRAKE; VIBRATION SEVERITY GRADE R ROTARY SHAFT SEAL (IP 67)

1FT6108-8AB71-3EA1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 70 NM, 100 K, 1500 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL NON-DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; WITH FITTED KEY, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END

1FT6064-1AH71-3EH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 9.5 NM, 100 K, 4500 RPM NATURAL AIR COOLING, IP65, IM B5 (IM V1, IM V3) ABSOLUTE VALUE ENCODER ENDAT 2048 P/REV (ENCODER A-2048) FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION AXIAL NON-DRIVE END WITH HOLDING BRAKE;

1FT6034-1AK71-3EH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 2.0 NM, 100 K, 6000 RPM NATURAL AIR COOLING, IP65 IM B5 (IM V1, IM V3) ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION AXIAL NON-DRIVE END WITH HOLDING BRAKE;

1FT6086-8AC71-3EH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 27NM, 100K, 2000RPM, 4,7KW NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL NON-DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W. HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END

1FT6105-8AB71-4EG1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 50 NM, 100 K, 1500 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END

1FT6105-8AB71-3EA1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 50 NM, 100 K, 1500 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL NON-DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; WITH FITTED KEY, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END

1FT6044-4AF71-3EH6 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 5.0 NM, 100 K, 3000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL, NON-DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W. HOLDING BRAKE VIBRATION SEVERITY GRADE N, KEROSENE SEAL (IP 68)

1FT6082-1AH71-1EG1 SIEMENS AC FDD MOTOR, 600 V DC LINK, 13 NM, 100 K, 4500 RPM NATURAL AIR COOLING, IP65 IM B5 (IM V1, IM V3) ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION TRAVERSE RIGHT WITHOUT HOLDING BRAKE;

1FT6086-1AF71-3EH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 27 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IP65, IM B5 (IM V1, IM V3) ABSOLUTE VALUE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL NON-DRIVE END WITH HOLDING BRAKE;

1FT6082-8AH71-1EG1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 13 NM, 100 K, 4500 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION TRAVERSE RIGHT ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END

1FT6082-8AC71-1AG0 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 13NM, 100K, 2000RPM NATURALLY COOLED IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR CONNECTOR OUTLET DIRECTION TRANSVERSE RIGHT INCREMENTAL ENCODER SIN/COS 1 VSS 2048 S/R (ENCODER I-2048) SMOOTH SHAFT, CIRCULAR RUNOUT TOLERANCE N WITHOUT HOLDING BRAKE VIBRATION SEVERITY GRADE N LABYRINTH SEAL (IP64)

1FT6061-6AF71-3TG1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 4.0NM, 100K, 3000RPM, 1,1KW NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL, NON-DRIVE END RESOLVER 2-POLE (RESOLVER P=1); PLAIN SHAFT, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65)

1FT6108-8AC71-3EH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 70 NM, 100 K, 2000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL NON-DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W. HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END

1FT6086-1AF71-1AH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 27 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IP65, IM B5 (IM V1, IM V3) INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION TRAVERSE RIGHT WITH HOLDING BRAKE;

1FT6105-8AF71-4EH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 50 NM, 100 K, 3000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W. HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65) GAMMA SEALING RING ON DRIVE END

1FT6044-4AK71-3EG1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 5.0 NM, 100 K, 6000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL, NON-DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65)

1FT6064-6AC71-4EG1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 9.5 NM, 100 K, 2000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL, DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65)

1FT6064-6AC71-4EG2 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 9.5 NM, 100 K, 2000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL, DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, ROTARY SHAFT SEAL (IP 67)

1FT5072-0AK71-1-Z SIEMENS AC FEED DRIVE MOTOR, DC LINK 600 V 12 NM, 100 K, 6000 RPM, AIR COOLING, TACHOGENERATOR A. SHAFT POSITION ENCODER, IP64, IM B5 (IM V1,IM V3) FOR POWER AND SIGNAL CONNECTORS

1FT6082-1AF71-1EG1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 13 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IP65 IM B5 (IM V1, IM V3) ABSOLUTE VALUE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION TRAVERSE RIGHT WITHOUT HOLDING BRAKE;

1FT6064-1AF71-1EG1 SIEMENS SIMOTICS S SYNCHRON-SERVOMOTOR 1FT6 9.5NM, 100K, 3000 U/MIN SELBSTGEKUEHLT, IP65 IM B5 (IM V1, IM V3) ABSOLUTWERTGEBER ENDAT 2048 S/R (ENCODER A-2048); OHNE HALTEBREMSE;

1FT6041-4AF71-3EH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 2.5 NM, 100 K, 3000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL, NON-DRIVE END ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); PERFORMANCE REDUCTION BY 10% DUE TO ABSOLUTE ENCODER; PLAIN SHAFT, ACCURACY TOLERANCE N, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65)

1FT6044-1AF71-3EH1                                     SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 5.0 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IP65 IM B5 (IM V1, IM V3); ABSOLUTE ENCODER ENDAT 2048 P/REV (ENCODER A-2048); FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION AXIAL NON-DRIVE END WITH HOLDING BRAKE;

1FT6082-1AF71-1EH0 SIEMENS AC FEED DR. MOTOR, 600V DC LINK, 13 NM, 100 K, 3000 REV/MIN; NATURAL AIR COOLING, ABSOLUTE OPTICAL ENCODER, IP64, IM B5 (IM V1,IM V3) POWER AND SIGNAL CONNECTORS, ADD.REPAIR SERVICE:AV000802, AV003240 FOR POWER/SIGNAL CONNECTORS: OUTLET DIRECTION TRANSVERSE RIGHT WITH HOLDING BRAKE

1FT6064-1AF71-3AG1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 9.5 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IP65 OPTICAL IM B5 (IM V1, IM V3) IINCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION AXIAL NON-DRIVE END WITHOUT HOLDING BRAKE;

1FK7103-5AF71-1AG5 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTORS 1FK7 COMPACT,36 NM, 100 K, 3000 RPM, 4,40KW NATURAL AIR COOLING, IM B5 (IM V1, IM V3) POWER/SIGNAL CONNECTORS CONN. CAN BE ROTATED BY 270 DEGR., INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); PLAIN SHAFT, TOLERANCE N; W/O HOLDING BRAKE DEGREE OF PROTECTION IP65 AS FLANGE IP67; PAINT FINISH RAL7016

1FK6103-8AF71-1AA2 SIEMENS SYNCHRONOUS SERVOMOTOR, 1FK6 8-POLE MOTOR, 36 NM, 100 K, 3000 RPM AIR COOLING, IM B5 (V1, V3) POWER/SIGNAL CONNECTORS CONNECTOR ROTAT. BY 270 DEG., INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); SHAFT WITH FITTED KEY, TOLERANCE N WITHOUT HOLDING BRAKE; DEGREE OF PROT. IP65 FLANGE D-END IP67;

1FK6101-8AF71-1AB0 SIEMENS SYNCHRONOUS SERVOMOTOR 1FK6 8-POLE MOTOR, 27 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IM B5 (V1, V3) POWER/SIGNAL CONNECTORS CONNECTOR ROTAT. BY 270 DEG., 270 DEGR., INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); SHAFT WITH FITTED KEY, TOLERANCE N WITH HOLDING BRAKE; DEGREE OF PROT. IP64;

1FK6083-6AF71-1AA2 SIEMENS SYNCHRONOUS SERVOMOTOR 1FK6 6-POLE MOTOR, 16 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IM B5 (V1, V3) POWER/SIGNAL CONNECTORS CONNECTOR ROTAT. BY 270 DEG., 270 DEGR., INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); SHAFT WITH FITTED KEY, TOLERANCE N WITHOUT HOLDING BRAKE; DEGREE OF PROT. IP65 FLANGE D-END IP67;

1FT6062-1AF71-4EG1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 6.0 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IP65, IM B5 (IM V1, IM V3) ABSOLUTE VALUE ENCODER ENDAT 2048 P/REV (ENCODER A-2048) FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION AXIAL DRIVE END WITHOUT HOLDING BRAKE;

1FK7060-5AF71-1TH0 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTORS 1FK7 COMPACT 6,0NM, 100K, 3000RPM, 1,48KW NATURAL AIR COOLING, IM B5 (IM V1, IM V3) POWER/SIGNAL CONNECTORS CONN. CAN BE ROTATED BY 270 DEGR., RESOLVER 2-POLE RESOLVER P=1); PLAIN SHAFT, TOLERANCE N; WITH HOLDING BRAKE DEGREE OF PROTECTION IP64

1FT6064-6AF71-4AD1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 9.5 NM, 100 K, 3000 RPM NATURAL AIR COOLING; IM B5 (IM V1, IM V3) FOR POWER AND SIGNAL CONNECTOR OUTGOING CONNECTOR DIRECTION AXIAL, DRIVE END INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); WITH FITTED KEY, ACCURACY TOLERANCE R, W/O HOLDING BRAKE VIBRATION SEVERITY GRADE N, GAMMA SEALING RING (IP 65)

1FK7085-7AF71-1AG0 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR, 1FK7 HIGH DYNAMIC 22 NM, 100 K, 3000 RPM, 3,14KW NATURAL COOLING, IM B5 (V1, V3) POWER/SIGNAL CONNECTORS CONNECTOR CAN BE ROTATED BY 270 DEGR. INCREM. ENCODER, IN/COS 1 VPP 2048 P/REV (ENCODER I-2048); PLAIN SHAFT, TOLERANCE N; W/O HOLDING BRAKE DEGREE OF PROTECTION IP64
