Motors

1PH5131-4CF40-Z SIEMENS AC MAIN SPINDLE MOTOR 9 KW AT 1500 REV/MIN 57 NM IM B 3

1PH5107-4CG49-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH5131-4CF44-Z SIEMENS AC MAIN SPINDLE MOTOR 9 KW AT 1500 REV/MIN 57 NM IB V 1 INCLUDING ORDER CODE K04

1PH7103-2NF02-0CJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 5.5 KW, 1500 RPM, 35 NM, VC: 6.3 KW, 1750 RPM, 34.4 NM 13 A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE S, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH

1PH5131-4CF46-Z SIEMENS AC MAIN SPINDLE MOTOR 9 KW AT 1500 REV/MIN 57 NM IM B 35

1PH5137-4CF44-Z SIEMENS AC MAIN SPINDLE MOTOR 15 KW AT 1500 REV/MIN 95 NM IB V 1 INCLUDING ORDER CODE K04

1PH5137-4CF49-Z SIEMENS AC MAIN SPINDLE MOTOR

1FT5138-4CF49-Z SIEMENS SERVOMOTOR PERMANENT-FIELD EXCITED

1PH5137-4CF41-Z SIEMENS AC MAIN SPINDLE MOTOR 15 KW AT 1500 REV/MIN 95 NM IM B 5 INCLUDING ORDER CODE K04

1PH6161-4NF40-Z SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 22 KW, 1500 REV/MIN, 140 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B 3

1PH7137-2ND22-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 17KW, 1000RPM, 162.3NM VC: 19.5KW, 1150RPM, 161.9NM 43A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE NDE TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH5138-4CF49-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH6135-4CF00-Z SIEMENS AC MAIN SPINDLE MOTOR

1FT6062-1AF71-4AG1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 6.0 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IP65, IM B5 (IM V1, IM V3) INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION AXIAL DRIVE END WITHOUT HOLDING BRAKE;

6SN2155-2BF10-1BA0 SIEMENS SIMODRIVE POSMO A PROGRAMMABLE POSITIONING MOTOR PROFIBUS-DP STANDARD SLAVE BRUSHLESS MOTOR, 48 V, 300 W PLANETARY GEAR I=7 WITHOUT BRAKE IP54

1PH7163-2ND00-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 22 KW, 1000 RPM, 210.1 NM, VC: 25 KW, 1150 RPM, 207.6 NM, 55 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH

1PH6130-4NG46-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH7133-2ND00-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 12 KW, 1000 RPM, 114.6 NM, VC: 13.5KW, 1150 RPM, 112.1 NM, 30 A, VC: 29.5 A, W7O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH

1PH7163-2ND03-0CJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR, CORE TYPE 22KW, 1000RPM, 210.1NM VC: 25KW, 1150RPM, 207.6NM 55A, 400V 3AC 50HZ WITH FAN, WITHOUT BRAKE RELATIVE MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP CABLE ON RIGHT PG CABLE ENTRY DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE S SHAFT/FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1FT6062-1AF71-4AH1 SIEMENS SIMOTICS S SYNCHRONOUS SERVOMOTOR 1FT6 6.0 NM, 100 K, 3000 RPM NATURAL AIR COOLING, IP65, IM B5 (IM V1, IM V3) INCREM. ENCODER, SIN/COS 1 VPP 2048 P/REV (ENCODER I-2048); FOR POWER/SIGNAL CONNECTOR CONNECTOR OUTGOING DIRECTION AXIAL DRIVE END WITH HOLDING BRAKE;

6SN2155-2BD11-1BA1 SIEMENS SIMODRIVE POSMO A PROGRAMMABLE POSITIONING MOTOR PROFIBUS DP STANDARD SLAVE BRUSHLESS MOTOR 48 V / 300 W PLANETARY GEARBOX I=4 WITH BRAKE IP54

1PH4138-4NF26 SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V, 30 KW, 190 NM, 1500 RPM, WATER-COOLED, IP65, SHAFT GLAND IP55, ENCODER 1 VPP 2048 INCR/REV, IM B35, TERMINAL BOX, SIGNAL CONNECTOR

1GCS182-0WE40-6HU5 SIEMENS MOTOR

1GF5184-0WE41-Z SIEMENS MOTOR

6SN2155-2CH11-1BA1 SIEMENS SIMODRIVE POSMO A PROGRAMMABLE POSITIONING MOTOR PROFIBUS DP STANDARD SLAVE BRUSHLESS MOTOR 48 V / 300 W PLANETARY GEAR I=12 WITH BRAKE IP54

1PH7137-2NF00-0BA0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 22KW, 1500RPM, 140.1NM VC: 25KW, 1750RPM, 136.4NM 57A, VC: 56A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B3 (IM V5, IM V6) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH6135-4NF46 SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 15 KW, 1500 REV/MIN, 95 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B 35

1PH5138-4CF46-Z SIEMENS AC MAIN SPINDLE MOTOR 18 KW AT 1500 REV/MIN 115 NM IM B 35

1PH6103-4NG40-Z SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 7 KW, 2000 REV/MIN, 33 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B3

1PH7137-2NF00-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 22 KW, 1500 RPM, 140.1 NM, VC: 25 KW, 1750 RPM, 136.4 NM 56 A, W/O BRAKE, 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH

1PH6133-4NF09-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH6103-1NF46-4AA0 SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 5.5 KW, 1500 REV/MIN, 35 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B35; TERMINAL BOX; RIGHT; CABLE INFEED/BOTTOM; ROT. ACCURACY TOLERANCE N VIBRATION SEVERITY R WITH TWIN-BEARINGS; SHAFT END ON D-END, W. FEATHER KEY , AIR FLOW DIR. BOTTOM; DEGREE OF PROT. IP 54

1FT5106-1AC71-1EA0 SIEMENS AC FEED DR. MOTOR,UDC LINK 600V 55 NM, 100 K, 2000 RPM; AIR COOLING, TACHOGENERATOR A. SHAFT POSITION ENCODER, IP64, IM B5 (IM V1, IM V3) POWER AND SIGNAL CONNECTORS CONNECTOR OUTGOING DIRECTION, TRAVERSE RIGHT ADDITIONALLY PREPARED FOR ENCODER INSTALLATION; SHAFT WITH FEATHER KEY/KEYWAY WITHOUT HOLDING BRAKE;

1PH5104-4CG40 SIEMENS AC MAIN SPINDLE MOTOR  6 KW AT 2000 REV/MIN 28 NM IM B 3

6SN2132-1CK11-1BA0 SIEMENS SIMODRIVE POSMO A PROGRAMMABLE POSITIONING MOTOR PROFIBUS-DP NORM-SLAVE BRUSHLESS MOTOR 24V /75W PLANETARY GEAR UNIT I=20.25 IP54 INCREMENTAL POS. ENCODER 2-WIRE CABLE TERMINAL CONNECT.

1PH6103-4NF40-Z SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 5.5 KW, 1500 REV/MIN, 35 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B3

1PH7101-2NF02-0DJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 3.7 KW, 1500 RPM, 23.6 NM, VC: 4.3 KW, 1750 RPM, 23.6 NM 10A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE SR, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH

1PH5139-4CG49-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH7133-2NG02-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 20 KW, 2000RPM, 95.5NM VC: 22.5KW, 2300RPM, 93.4NM 45 A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH7133-2NF02-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 15 KW, 1500 RPM, 95.5 NM, VC: 17.5KW, 1750 RPM, 95.5 NM, 34 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH

1PH7167-2NF03-0CJ3 SIEMENS SIMOTICS M COMPACT ASYNCHRONOUS MOTOR, CORE TYPE 37 KW, 1500 RPM, 235.5 NM, VC: 41 KW, 1750 RPM, 223.7 NM, 82 A, VC: 79 A, 3-PH. 400 V 50 HZ, WITH FAN, WITHOUT BRAKE, REL. MOTOR ENCODER 1 VPP 2048 P/REV, TERMINAL BOX ON TOP, CABLE ON RIGHT, PG GLAND, DESIGN IM B35 (IM V15, IM V36), VIBRATION SEVERITY GRADE S, SHAFT/FLANGE ACCURACY R, PLAIN SHAFT WITHOUT FEATHERKEY, AIR FLOW FROM DRIVE TO NON- DRIVE END, IP55, FAN IP54, STANDARD PAINT FINISH (RAL7016)

1PH7167-2NF03-0CJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR, CORE TYPE 37KW, 1500RPM, 235.5NM VC: 41KW, 1750RPM, 223.7NM 82A, VC: 79A, 400V 3AC 50HZ WITH FAN, WITHOUT BRAKE RELATIVE MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP: CABLE ON RIGHT PG CABLE ENTRY DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE S SHAFT/FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PH5137-4CF40-Z SIEMENS AC MAIN SPINDLE MOTOR 15 KW AT 1500 REV/MIN 95 NM IM B 3

1PH7101-2NF02-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 3.7 KW, 1500 RPM, 23.6 NM, VC: 4.3 KW, 1750 RPM, 23.6 NM 10A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH

1FT5134-0AC24-1-Z SIEMENS SERVOMOTOR PERMANENT-FIELD EXCITED

1PH7133-2NG03-0CJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 20 KW, 2000RPM, 95.5NM VC: 22.5KW, 2300RPM, 93.4NM 45 A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY LEVEL S, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED

1PM6103-4LZ84-3ZR1-Z SIEMENS AC MSD HOLLOW-SHAFT MOTOR

1PH7133-7QD03-5KA3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 12 KW, 1000 RPM, 114.6 NM, VC: 13.5KW, 1150 RPM, 112.1 NM, 30 A, VC: 29.5 A, WITH BRAKE 3 AC 400 V, 50 HZ, WITH FAN, METRIC CABLE ENTRY ACCORDING TO EN 50262 REL. MOTOR ENCODER 1 VPP 2048 P/REV; WITH DRIVE-CLIQ INTERFACE, ND-END AT TERMINAL BOX TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B35 (IM V15, IM V36) WITH 24 V DC BRAKE; VIBRATION SEVERITY GRADE A, SHAFT A. FLANGE ACCURACY N; FITTED KEY + HALF-KEY BALANCING AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, STAND. PAINT FINISH (RAL 7016)

1PH7133-2NG02-0BJ3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 20 KW, 2000 RPM, 95.5 NM, VC: 22.5 KW, 2300 RPM, 93.4 NM, 45 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, STANDARD PAINT FINISH (RAL 7016)

1PH5167-4CF46-Z SIEMENS AC MAIN SPINDLE MOTOR 34 KW BEI 1500 MIN-1 216 NM IM B 35
