Motors

1PH7186-9NE00-0FK3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR

1GG5134-0GY40-6HU7-Z SIEMENS MOTOR

1GG5132-0GZ44-6HU7-Z SIEMENS MOTOR

1PH7163-2ND00-0CB3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 22 KW, 1000 RPM, 210.1 NM, VC: 25 KW, 1150 RPM, 207.6 NM, 55 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE S, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + HALF-KEY BALANCING AIR FLOW FROM NON-DRIVE END TO DRIVE END IP 55, FAN IP 54, STAND. PAINT FINISH (RAL 7016)

1PH5107-4CF44-Z SIEMENS AC MAIN SPINDLE MOTOR 6.5 KW AT 1500 REV/MIN 41 NM IB V 1 INCLUDING ORDER CODE K04

1PH6135-1NF47-2BN1 SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 15 KW, 1500 REV/MIN, 95 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B35; TERMINAL BOX; ON TOP;CABLE INFEED/ND-END; ROT. ACCURACY TOLERANCE R VIBRATION SEVERITY S WITH TWIN-BEARINGS; SHAFT END ON D-END, W/O FEATHER KEY , AIR FLOW DIR. BOTTOM; DEGREE OF PROT. IP 55

1PH6135-1NF46-2BN1 SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 15 KW, 1500 REV/MIN, 95 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B35; TERMINAL BOX; ON TOP;CABLE INFEED/ND-END; ROT. ACCURACY TOLERANCE R VIBRATION SEVERITY S WITH TWIN-BEARINGS; SHAFT END ON D-END, W/O FEATHER KEY , AIR FLOW DIR. BOTTOM; DEGREE OF PROT. IP 55

1PH6135-4NF46-Z SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 15 KW, 1500 REV/MIN, 95 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B 35

1FT5106-1AC71-1EG0 SIEMENS AC FEED DR. MOTOR,UDC LINK 600V 55 NM, 100 K, 2000 RPM; AIR COOLING, TACHOGENERATOR A. SHAFT POSITION ENCODER, IP64, IM B5 (IM V1, IM V3) POWER AND SIGNAL CONNECTORS CONNECTOR OUTGOING DIRECTION, TRAVERSE RIGHT ADDITIONALLY PREPARED FOR ENCODER INSTALLATION; PLAIN SHAFT, WITHOUT HOLDING BRAKE;

1PH7101-2NF02-0CK0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 3.7 KW, 1500 RPM, 23.6 NM, VC: 4.3 KW, 1750 RPM, 23.6 NM 10A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE S, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM NON-DRIVE END TO DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH

1PH7101-2NF32-0CK0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 3.7 KW, 1500 RPM, 23.6 NM, VC: 4.3 KW, 1750 RPM, 23.6 NM 10A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE LEFT DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE S, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM NON-DRIVE END TO DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH

1PH6107-4NF49-Z SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 9 KW, 1500 REV/MIN, 57 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; 91H: TYPE IM V15

1GG5136-0WX41-6HU3-Z SIEMENS MOTOR

6SN2155-2BF10-1BA1 SIEMENS SIMODRIVE POSMO A PROGRAMMABLE POSITIONING MOTOR PROFIBUS DP STANDARD SLAVE BRUSHLESS MOTOR 48 V 300 W PLANETARY GEARS I=7 NO BRAKE IP54

1GL5108-0WW40-6HU7-Z SIEMENS DC MOTOR, IP 23 SEPARATE FAN (COMPACT DESIGN) AXIALLY MOUNTED, 5.9 KW RATED SPEED 2250 REV/MIN IM B 3

1PH5167-4CG40-Z SIEMENS AC MAIN SPINDLE MOTOR 43 KW AT 2000 REV/MIN 216 NM IM B 3

1PH6186-4CE40-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH6131-4NG46-Z SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 12 KW, 2000 REV/MIN, 57 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B 35

1PH6161-4CF06-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH5138-4CF40-Z SIEMENS AC MAIN SPINDLE MOTOR 18 KW AT 1500 REV/MIN 115 NM IM B 3

1PH7167-2NF00-0CB3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 37 KW, 1500 RPM, 235.5 NM, VC: 41 KW, 1750 RPM, 223.7 NM, 82 A, VC: 79 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE S, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + HALF-KEY BALANCING AIR FLOW FROM NON-DRIVE END TO DRIVE END IP 55, FAN IP 54, STAND. PAINT FINISH (RAL 7016)

1PH7103-2MG02-0CA0-Z SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 7 KW, 2000 RPM, 33.4 NM, VC:7.5 KW, 2300 RPM, 31.1 NM 17.5 A, VC: 17 A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV; TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE S, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + HALF-KEY BALANCING AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH

1HC5102-0EH19-0EU1-Z SIEMENS DC MOTOR IP 54 NAT.AIR COOLING

1PH7103-2NG00-0BA0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 7 KW, 2000 RPM, 33.4 NM, VC:7.5 KW, 2300 RPM, 31.1 NM 17.5 A, VC: 17 A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B3 (IM V5, IM V6) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + HALF-KEY BALANCING AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH

1PH7103-2NG02-0CJ3 SIEMENS SIMOTICS M COMPACT ASYNCHRONOUS MOTOR, CORE TYPE 7 KW, 2000 RPM, 33.4 NM, VC: 7.5 KW, 2300 RPM, 31.1 NM, 17.5 A, VC: 17 A, 3-PH. 400 V 50 HZ, WITH FAN, WITHOUT BRAKE, REL. MOTOR ENCODER 1 VPP, 2048 P/REV, TERMINAL BOX ON TOP, CABLE ON RIGHT, PG GLAND, DESIGN IM B5 (IM V1, IM V3), VIBRATION SEVERITY GRADE S, SHAFT/FLANGE ACCURACY R, PLAIN SHAFT WITHOUT FEATHERKEY, AIR FLOW FROM D-END TO ND-END IP55, FAN IP54, STANDARD PAINT FINISH (RAL 7016);

1PH7103-2NF02-0CJ3 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 5.5 KW, 1500 RPM, 35 NM, VC: 6.3 KW, 1750 RPM, 34.4 NM 13 A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE S, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, STANDARD PAINT FINISH (RAL 7016)

1PH6161-4CF00-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH7137-2ND00-0BA0 SIEMENS SIMOTICS M KOMPAKT-ASYNCHRONMOTOR, 17 KW, 1000 U/MIN, 162.3 NM, VC: 19.5KW, 1150 U/MIN, 161.9NM 43 A, OHNE BREMSE; 3AC 400 V 50 HZ, MIT LUEFTER; REL. MOTORGEBER 1 VSS 2048 P/U; KL-KASTEN OBEN, KABEL RECHTS; BAUFORM IM B3 (IM V5, IM V6); SCHWINGSTAERKESTUFE R, WELLEN- UND FLANSCHGENAUIGKEIT R; PASSFEDER + HALBKEILWUCHTUNG, LUFTRICHTUNG VON AS NACH BS; IP 55, LUEFTER IP 54, OHNE FARBANSTRICH;

1PH7103-2NG00-0CJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 7 KW, 2000 RPM, 33.4 NM, VC:7.5 KW, 2300 RPM, 31.1 NM 17.5 A, VC: 17 A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B3 (IM V5, IM V6) VIBRATION SEVERITY GRADE S, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH

1FT5136-0SC71-1-Z SIEMENS AC FEED DRIVE MOTOR, DC LINK 600 V, 145 NM, 100 K, 2000 RPM, SEPARATE VENTILATION, TACHOGENERATOR A.SHAFT POSITION ENCODER,IP64,IM B5 (IM V1,IM 3)

1PH6131-4NG46 SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 12 KW, 2000 REV/MIN, 57 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B 35

1PH6137-4NB49-Z SIEMENS SPINDLE MOTOR

1PH5137-4CG40 SIEMENS AC MAIN SPINDLE MOTOR 20 KW AT 2000 REV/MIN 95 NM IM B 3

6SN2132-1DE11-1BA1 SIEMENS SIMODRIVE POSMO A PROGRAMMABLE POSITIONING MOTOR PROFIBUS DP STANDARD SLAVE BRUSHLESS MOTOR 24 V 75 W PLANETARY GEARING I=126.56 IP54

1PH6105-4NF49-Z SIEMENS AC MAIN SPINDLE MOTOR

1GG5134-0WH40-6HU3-Z SIEMENS MOTOR

1PH5101-4CG40-Z SIEMENS AC MAIN SPINDLE MOTOR 4 KW AT 2000 REV/MIN 19 NM IM B 3

6SN2155-1AA10-1BA1 SIEMENS SIMODRIVE POSMO A PROGRAMMABLE POSITIONING MOTOR PROFIBUS DP STANDARD SLAVE BRUSHLESS MOTOR 48 V 300 W NO GEARS, SMOOTH SHAFT NO BRAKE IP64

1PH7131-2NF02-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 11 KW, 1500 RPM, 70 NM, VC: 13 KW, 1750 RPM, 70.9 NM, 24 A, VC: 25 A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH

1PH7137-2NG00-0BA0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 28 KW, 2000 RPM, 133.7 NM, VC: 29 KW, 2300 RPM, 120.4 NM 60 A, VC: 56 A, W/O BRAKE, 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + HALF-KEY BALANCING AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH

1PH7137-2NG20-0BA0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 28 KW, 2000 RPM, 133.7 NM, VC: 29 KW, 2300 RPM, 120.4 NM 60 A, VC: 56 A, W/O BRAKE, 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON NON-DRIVE END DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + HALF-KEY BALANCING AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH

1PH7137-2NF02-0DK2 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 22 KW, 1500 RPM, 140.1 NM, VC: 25 KW, 1750 RPM, 136.4 NM 56 A, W/O BRAKE, 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE SR, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM NON-DRIVE END TO DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH, FLANGE ON DRIVE END WITH SHAFT SEAL

1PH7133-2NG00-0BD0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 20 KW, 2000 RPM, 95.5 NM, VC: 22.5 KW, 2300 RPM, 93.4 NM, 45 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + FULL-KEY BALANCING AIR FLOW FROM NON-DRIVE END TO DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH

1PH7137-2SG02-0BJ0-Z SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 28 KW, 2000 RPM, 133.7 NM, VC: 29 KW, 2300 RPM, 120.4 NM 60 A, VC: 56 A, W/O BRAKE, 3AC 400 V 50 HZ, WITH FAN TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH

1PH7133-2NG30-0CJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 20 KW, 2000 RPM, 95.5 NM, VC: 22.5 KW, 2300 RPM, 93.4 NM, 45 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE LEFT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE S, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH

1PH6138-4ZZ84-Z SIEMENS AC MAIN SPINDLE MOTOR

1PH7131-2NF20-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 11 KW, 1500 RPM, 70 NM, VC: 13 KW, 1750 RPM, 70.9 NM, 24 A, VC: 25 A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON NON-DRIVE END DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH

1PH6103-4LZ84-3ZR1-Z SIEMENS MOTOR

1PH7167-2NF03-0BD0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 37 KW, 1500 RPM, 235.5 NM, VC: 41 KW, 1750 RPM, 223.7 NM, 82 A, VC: 79 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + FULL-KEY BALANCING AIR FLOW FROM NON-DRIVE END TO DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH

1PH7137-7QG00-0DA0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 28 KW, 2000 RPM, 133.7 NM, VC: 29 KW, 2300 RPM, 120.4 NM 60 A, VC: 56 A, W/O BRAKE, 3 AC 400 V, 50 HZ, WITH FAN, METRIC CABLE ENTRY ACCORDING TO EN 50262 REL. MOTOR ENCODER 1 VPP 2048 P/REV; WITH DRIVE-CLIQ INTERFACE, ND-END AT TERMINAL BOX TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE SR, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + HALF-KEY BALANCING AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH
