signal cable

6FX8002-2EQ14-1CF0 SIEMENS SIGNAL CABLE EXTENSION FOR BASE 6FX8002-2EQ10-.... 3X (2X0.14) C+4X 0.14+2X0.5 +4X 0.22 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.8 MM LENGTH (M)= TYPE: 6FX8002-2EQ14 LENGTH (M) = 0 + 20 + 5 + 0

6FX8002-2SL10-1AD0 SIEMENS SINGLE LINE DISPLACEMENT FOR TEMPERATURE SENSOR 3X 2X 0.5+1X 1 C M17 MALE VG ON M17 FEMALE VG MOTION-CONNECT 800PLUS UL/CSA, DESINA, TRAILABLE DMAX=11 MM TYPE OF DELIVERY: RING LENGTH (M)= 0 + 0 + 3 + 0

6FX8002-2CA31-1BE0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED FOR INCR. ENCODER WITH C/D TRACKS INTEGRATED INTO THE MOTOR 3X (2X0.14) C+4X 0.14+2X0.5 +4X 0.22 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.8 MM LENGTH (M)= TYPE: 6FX8002-2CA31 LENGTH (M) = + 0 + 10 + 4 + 0

6FX8002-2CB31-1AF0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED 1FT5 TG/RLG ON 611A 12X0.22 C MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=7.3 MM LENGTH (M)= TYPE: 6FX8002-2CB31 LENGTH (M) = + 0 + 0 + 5 + 0

6FX8002-2SL10-1AE0 SIEMENS SINGLE LINE DISPLACEMENT TYPE: 6FX8002-2SL10 FOR TEMPERATURE SENSOR 3X 2X 0.5+1X 1 C M17 MALE VG ON M17 FEMALE VG MOTION-CONNECT 800PLUS UL/CSA, DESINA, TRAILABLE DMAX=11 MM TYPE OF DELIVERY: RING LENGTH (M)= 0 + 0 + 4 + 0

6FX2002-2EQ10-1DA0 SIEMENS SIGNAL CABLE, PREASSEMBLED (ABSOLUTE MEASURING ENCODER IN MOTOR) 3X2X0.14+4X0.14+2X0.5+4X0.23 C TRAILING TYPE, PERFORMANCE TYPE DMAX = 10.7 MM, LENGTH (M) = 0 + 30 + 0 + 0

6FC9348-2BY00-1BF0 SIEMENS SIGNAL CABLE, PREASSEMBLED TACHOGEN. ON 6SC6101 12X0,22 C MOTION CONNECT 800PLUS TRAILING TYPE UL/CSA DESINA DMAX = 7.3 MM, LENGTH (M)= 0 + 10 + 5 + 0

6FX8002-2EQ10-1FA0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED FOR ABSOLUTE ENCODER ENDAT INTEGRATED INTO THE MOTOR 3X (2X0.14) C+4X 0.14+2X0.5 +4X 0.22 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.8 MM LENGTH (M)= TYPE: 6FX8002-2EQ10 LENGTH (M) = 0 + 50 + 0 + 0

6FX8002-2CA31-1DC0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED FOR INCR. ENCODER WITH C/D TRACKS INTEGRATED INTO THE MOTOR 3X (2X0.14) C+4X 0.14+2X0.5 +4X 0.22 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.8 MM LENGTH (M)= TYPE: 6FX8002-2CA31 LENGTH (M) = + 0 + 30 + 2 + 0

6FX8002-2CA51-1DA0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED FOR 1-PHASE ENCODER/SIMAG H TO 611 A 3X (2X0.14) C+4X 0.14+2X0.5 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.2 MM LENGTH (M)= TYPE: 6FX8002-2CA51 LENGTH (M) = + 0 + 30 + 0 + 0

6FX8002-2CA51-1BJ0 SIEMENS SIGNAL LINE PREFABRICATED FOR 1-PHASE ENCODER/SIMAG H TO 611 A 3X (2X0.14) C+4X 0.14+2X0.5 C PLUG FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.2 MM LENGTH (M)= TYPE: 6FX8002-2CA51 LENGTH (M) = + 0 + 10 + 8 + 0

6FX8002-2DC20-1CA0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED TYPE: 6FX8002-2DC20 DRIVE-CLIQ WITH 24 V CONNECTOR RJ45 IP67 ON BOTH SIDES RELEASED ONLY UP TO 75 M LENGTH DMAX=7.1 MM LENGTH (M)= 0 + 20 + 0 + 0

6FX8002-2SL10-1AJ0 SIEMENS SINGLE LINE DISPLACEMENT TYPE: 6FX8002-2SL10 FOR TEMPERATURE SENSOR 3X 2X 0.5+1X 1 C M17 MALE VG ON M17 FEMALE VG MOTION-CONNECT 800PLUS UL/CSA, DESINA, TRAILABLE DMAX=11 MM TYPE OF DELIVERY: RING LENGTH (M)= 0 + 0 + 8 + 0

6FX8002-2CA51-1AF0 SIEMENS SIGNAL LINE PREFABRICATED FOR 1-PHASE ENCODER/SIMAG H TO 611 A 3X (2X0.14) C+4X 0.14+2X0.5 C PLUG FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.2 MM LENGTH (M)= TYPE: 6FX8002-2CA51 LENGTH (M) = + 0 + 0 + 5 + 0

6FX8002-2CB51-1AF0 SIEMENS SIGNAL LINE PRE-ASSEMBLED FOR INCREMENTAL ENCODER TTL 5V, 6FX2001-2 4X (2X0.34)+4X 0.5 C PLUG FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=9.3 MM LENGTH (M)= TYPE: 6FX8002-2CB51 LENGTH (M) = + 0 + 0 + 5 + 0

6FX8002-8QN04-1AF0 SIEMENS SINGLE CABLE PREFABRICATED 4G0.38+2X0.38+4X0.2 C SPEED-CONNECT M12 CONNECTOR CORES WITH END SLEEVE DATA CABLE WITH IX CONNECTOR UL/CSA DESINA MOTION-CONNECT 800PLUS DMAX.=9.7 MM, LENGTH(M)= 0 + 0 + 5 + 0

6FX8002-8QN08-1BA0 SIEMENS SINGLE CABLE CONNECTION PREFABRICATED 4G0.75+2X0.5+4X0.2 C SPEED-CONNECT CONNECTOR M17 CORES WITH END SLEEVE DATA CABLE WITH IX CONNECTOR UL/CSA DESINA MOTION-CONNECT 800PLUS DMAX=10.5 MM, LENGTH(M)= 0 + 10 + 0 + 0

6FX8002-8QN04-1AC0 SIEMENS SINGLE CABLE PREFABRICATED 4G0.38+2X0.38+4X0.2 C SPEED-CONNECT M12 CONNECTOR CORES WITH END SLEEVE DATA CABLE WITH IX CONNECTOR UL/CSA DESINA MOTION-CONNECT 800PLUS DMAX.=9.7 MM, LENGTH(M)= 0 + 0 + 2 + 0

6FX2002-2CA11-1AF0 SIEMENS SIGNAL CABLE, PREASSEMBLED (ENCOD. SINUS 1 VPP AND TTL) 3X2X0.14+4X0.14+2X0.5 C, TRAILING TYPE, PERFORMANCE TYPE DMAX = 9.5 MM, LENGTH (M) = + 0 + 0 + 5 + 0

6FX8002-2CA51-1CF0 SIEMENS SIGNAL LINE PREFABRICATED FOR 1-PHASE ENCODER/SIMAG H TO 611 A 3X (2X0.14) C+4X 0.14+2X0.5 C PLUG FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.2 MM LENGTH (M)= TYPE: 6FX8002-2CA51 LENGTH (M) = + 0 + 20 + 5 + 0

6FX8012-2CF02-1BA0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED FOR RESOLVERS 3X (2X0.14) C+4X 0.14+2X0.5 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=9.2 MM LENGTH (M)= TYPE: 6FX8012-2CF02 MODULE SIDE: CRIMPED CONTACTS, CONNECTOR HOUSING INCLUDED LENGTH (M) = 0 + 10 + 0 + 0

6FX8002-2CA21-1BA0 SIEMENS SIGNAL LINE PRE-ASSEMBLED FOR INCREMENTAL ENCODER CURRENT SIGNALS TO 611D 3X (2X0.14) C+2X0.5C C PLUG FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=9.4 MM LENGTH (M)= TYPE: 6FX8002-2CA21 LENGTH (M) = + 0 + 10 + 0 + 0

6FX8002-2CA31-1BH0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED FOR INCR. ENCODER WITH C/D TRACKS INTEGRATED INTO THE MOTOR 3X (2X0.14) C+4X 0.14+2X0.5 +4X 0.22 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.8 MM LENGTH (M)= TYPE: 6FX8002-2CA31 LENGTH (M) = + 0 + 10 + 7 + 0

6FX8042-2EQ10-1GF0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED FOR ABSOLUTE ENCODER ENDAT INTEGRATED INTO THE MOTOR 3X (2X0.14) C+4X 0.14+2X0.5 +4X 0.22 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.8 MM LENGTH (M)= TYPE: 6FX8042-2EQ10 MOTOR SIDE: CRIMPED CONTACTS, CONNECTOR HOUSING INCLUDED LENGTH (M) = 0 + 60 + 5 + 0

6FX2002-1AB84-1AF0 SIEMENS SIGNAL LINE, PRE-ASSEMBLED EXTENSION TYPE: 6FX2002-1AB84 (BHG-NC) 11X0.14+6X0.5 C 4-CORE ENABLE 45 DEGREES CODED PLUG STRAIGHT NC SIDE LONG (M)=5

6FX8002-2CB31-1AJ0 SIEMENS SIGNALLEITUNG KONFEKTIONIERT 1FT5 TG/RLG AN 611A 12X0.22 C MOTION-CONNECT 800PLUS SCHLEPPFÄHIG, UL/CSA, DESINA DMAX=7.3MM LÄNGE (M)= TYP: 6FX8002-2CB31 LÄNGE (M)= + 0 + 0 + 8 + 0

6FX8002-2CR00-1DB0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED TYPE: 6FX8002-2CR00 FOR INCREMENTAL ENCODER TTL RS422 5 V DC, 6FX2001-2 4X 2X 0.34+4X 0.5 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.3 MM; LENGTH (M)= 0 + 30 + 1 + 0

6FX8002-5CA01-1AK0 SIEMENS POWER CABLE PRE-ASSEMBLED 4X 1.5 C, PLUG FULL-THREAD SIZE 1 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.5 MM, LENGTH (M)= TYPE: 6FX8002-5CA01 LENGTH (M) = 0 + 0 + 9 + 0

6FX8002-2EQ20-1CA0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED TYPE: 6FX8002-2EQ20 FOR ABSOLUTE ENCODER ENDAT IN MOTOR AH20 WITH CONNECTOR FULL THREAD M17 (3X 2X 0.14) C+4X 0.14+2X 0.5+4X 0.22 C MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.8 MM LENGTH (M)= 0 + 20 + 0 + 0

6FX8002-2CA20-1BA0 SIEMENS SIGNAL CABLE, PRE-ASSEMBLED TYPE: 6FX8002-2CA20 FOR INCREMENTAL ENCODER WITH C/D TRACKS IN MOTOR AH20 CONNECTOR FULL THREAD M17 (3X 2X 0.14) C+4X 0.14+2X 0.5+4X 0.22 C MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.8 MM; LENGTH (M)= 0 + 10 + 0 + 0

6FX8002-2CA34-1CA0 SIEMENS SIGNAL CABLE EXTENSION FOR BASE 2CA31-2CA80 OR -2CA88 3X (2X0.14) C + 4X 0.14+2X0.5+4X 0.22 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.8 MM LENGTH (M)= TYPE: 6FX8002-2CA34 LENGTH (M) = 0 + 20 + 0 + 0

6FX8002-2CB31-1CA0 SIEMENS SIGNAL LINE PREFABRICATED 1FT5 TG/RLG ON 611A 12X0.22 C MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=7.3 MM LENGTH (M)= TYPE: 6FX8002-2CB31 LENGTH (M) = + 0 + 20 + 0 + 0

6FX8002-2DD40-1BF0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED TYPE: 6FX8002-2DD40 DRIVE-CLIQ WITH 24 V M17 FEMALE FULL THREAD/ RJ45 IP20 MOTION-CONNECT 800PLUS UL/CSA, DESINA, TRAILABLE DMAX=7.1 MM LENGTH (M)= 0 + 10 + 5 + 0

6FX8002-2CA51-1BF0 SIEMENS SIGNAL LINE PREFABRICATED FOR 1-PHASE ENCODER/SIMAG H TO 611 A 3X (2X0.14) C+4X 0.14+2X0.5 C PLUG FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.2 MM LENGTH (M)= TYPE: 6FX8002-2CA51 LENGTH (M) = + 0 + 10 + 5 + 0

6FX8002-2DC40-1BF0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED TYPE: 6FX8002-2DC40 DRIVE-CLIQ WITH 24 V M17 FEMALE SPEED-CONNECT/ RJ45 IP20 MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=7.1 MM LENGTH (M)= 0 + 10 + 5 + 0

6FX8002-2CF02-1BF0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED FOR RESOLVERS 3X (2X0.14) C+4X 0.14+2X0.5 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=9.2 MM LENGTH (M)= TYPE: 6FX8002-2CF02 LENGTH (M) = 0 + 10 + 5 + 0

6FX8002-2CF04-1BA0 SIEMENS SIGNAL CABLE EXTENSION FOR BASE 6FX8002-2CF02-XXXX 3X (2X0.14) C+4X 0.14+2X0.5 C CONNECTOR FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=9.2 MM LENGTH (M)= TYPE: 6FX8002-2CF04 LENGTH (M) = 0 + 10 + 0 + 0

6FX8002-2DC40-1BA0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED TYPE: 6FX8002-2DC40 DRIVE-CLIQ WITH 24 V M17 FEMALE SPEED-CONNECT/ RJ45 IP20 MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=7.1 MM LENGTH (M)= 0 + 10 + 0 + 0

6FX8002-2DC34-1BA0 SIEMENS DRIVE-CLIQ EXTENSION FOR BASE TYPE: 6FX8002-2DC34 DRIVE-CLIQ WITH 24V M12 MALE/M12 FEMALE MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=7.1MM LENGTH (M)=10

6FX8002-2DC38-1BA0 SIEMENS DRIVE-CLIQ ADAPTER CABLE PRE-FABRICATED TYPE: 6FX8002-2DC38 DRIVE-CLIQ WITH 24 V M12 MALE/ RJ45 IP67 MOTION-CONNECT 800PLUS MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=7.1 MM LENGTH (M)=10

6FX8002-2DC42-1BA0 SIEMENS SIGNAL CABLE PRE-ASSEMBLED TYPE: 6FX8002-2DC42 DRIVE-CLIQ WITH 24 V RJ45 IP67/M17 MALE SPEED-CONNECT-READY MOTION-CONNECT 800PLUS UL/CSA, DESINA, TRAILABLE DMAX=7.1 MM LENGTH (M)= 0 + 10 + 0 + 0

6FX8002-2SL10-1BA0 SIEMENS SINGLE LINE DISPLACEMENT TYPE: 6FX8002-2SL10 FOR TEMPERATURE SENSOR 3X 2X 0.5+1X 1 C M17 MALE VG ON M17 FEMALE VG MOTION-CONNECT 800PLUS UL/CSA, DESINA, TRAILABLE DMAX=11 MM TYPE OF DELIVERY: RING LENGTH (M)= 0 + 10 + 0 + 0

6FX8002-2CA15-1AF0 SIEMENS SIGNAL LINE PRE-ASSEMBLED FOR GEAR WHEEL ENCODER FOR 611D HSA 3X (2X0.14) C+4X 0.14+2X0.5 C PLUG FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=9.2 MM LENGTH (M)= TYPE: 6FX8002-2CA15 LENGTH (M) = + 0 + 0 + 5 + 0

6FX8002-2SL10-1AF0 SIEMENS SINGLE LINE DISPLACEMENT TYPE: 6FX8002-2SL10 FOR TEMPERATURE SENSOR 3X 2X 0.5+1X 1 C M17 MALE VG ON M17 FEMALE VG MOTION-CONNECT 800PLUS UL/CSA, DESINA, TRAILABLE DMAX=11 MM TYPE OF DELIVERY: RING LENGTH (M)= 0 + 0 + 5 + 0

6FX8002-2CA20-1CF0 SIEMENS SIGNAL CABLE, PRE-ASSEMBLED TYPE: 6FX8002-2CA20 FOR INCREMENTAL ENCODER WITH C/D TRACKS IN MOTOR AH20 CONNECTOR FULL THREAD M17 (3X 2X 0.14) C+4X 0.14+2X 0.5+4X 0.22 C MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.8 MM; LENGTH (M)= 0 + 20 + 5 + 0

6FX8002-4EB10-1BC0 SIEMENS SIGNAL LINE PRE-ASSEMBLED TYPE: 6FX8002-4EB10 MPI BUS CABLE (SINAMICS) TRAILABLE 2 PLUGS WITH 35 DEGREES AND 1 PLUG WITH AXIAL CABLE OUTLET 1 X PG CONNECTION LENGTH 1=(M) 1 LENGTH 2=(M) 0 + 10 + 2 + 0

6FX8002-2CK00-1BA0 SIEMENS SIGNAL LINE PRE-ASSEMBLED FOR INCREMENTAL LINEAR MEASURING SYSTEM CURRENT SIGNAL 3X (2X0.14) C+2X0.5C C PLUG FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE UL/CSA DESINA DMAX=9.4 MM LENGTH (M)= TYPE: 6FX8002-2CK00 LENGTH (M) = 0 + 10 + 0 + 0

6FX8002-2CB42-1CF0 SIEMENS  SIGNAL LINE PRE-ASSEMBLED FOR ENCODER ROD320 IN MOTOR 4X (2X0.34)+4X 0.5 C PLUG FULL THREAD M23 ANGLED MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=9.3 MM LENGTH (M)= TYPE: 6FX8002-2CB42 LENGTH (M) = 0 + 20 + 5 + 0

6FX8002-2CB51-1CA0 SIEMENS SIGNAL LINE PRE-ASSEMBLED FOR INCREMENTAL ENCODER TTL 5V, 6FX2001-2 4X (2X0.34)+4X 0.5 C PLUG FULL THREAD M23 MOTION-CONNECT 800PLUS TRAILABLE, UL/CSA, DESINA DMAX=9.3 MM LENGTH (M)= TYPE: 6FX8002-2CB51 LENGTH (M) = + 0 + 20 + 0 + 0

6FX8002-2DC10-1DB0 SIEMENS SIGNAL CABLE, PRE-ASSEMBLED TYPE: 6FX8002-2DC10 DRIVE-CLIQ WITH 24 V PLUG RJ45 IP20 ON MODULE SIDE AND IP67 ON MOTOR SIDE MOTION-CONNECT 800PLUS RELEASED ONLY UP TO 75 M LENGTH DMAX=7.1 MM LENGTH (M)= 0 + 30 + 1 + 0
