Motori
1PH
1PH7167-2NF00-0BJ0 1PH7167-2NF00-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 37 KW, 1500 RPM, 235.5 NM, VC: 41 KW, 1750 RPM, 223.7 NM, 82 A, VC: 79 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH
1PH
1PH7167-2ND03-0CJ0 1PH7167-2ND03-0CJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 28KW, 1000RPM, 267.4NM VC: 31KW, 1150RPM, 257.4NM 71A, VC: 70A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY LEVEL S, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED
1PH
1PH7167-2NF03-0DC2 1PH7167-2NF03-0DC2 SIEMENS SIMOTICS M COMPACT ASYNCHRONOUS MOTOR 37 KW, 1500 RPM, 235.5 NM VC: 41 KW, 1750 RPM, 223.7 NM 82 A, VC: 79 A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE SR, SHAFT AND FLANGE ACCURACY R FITTED KEY + FULL-KEY BALANCING DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED AS FLANGE WITH SHAFT SEALING RING
Motori Posmo
6SN2132-1BC11-1BA0 6SN2132-1BC11-1BA0 SIEMENS SIMODRIVE POSMO A PROGRAMMABLE POSITIONING MOTOR PROFIBUS-DP STANDARD SLAVE BRUSHLESS MOTOR 24 V 75 W PLANETARY GEAR I=4.5 IP54 INCREMENTAL POSITION ENCODER 2-WIRE CABLE TERMINAL CONNECT
Motori Posmo
6SN2132-1BF11-1BA1 6SN2132-1BF11-1BA1 SIEMENS SIMODRIVE POSMO A PROGRAMMABLE POSITIONING MOTOR PROFIBUS DP STANDARD SLAVE BRUSHLESS MOTOR 24 V / 75 W PLANETARY GEARBOX I=8 IP54
1PH
1PH6138-4NG46-Z 1PH6138-4NG46-Z SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 28 KW, 2000 REV/MIN, 134 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B 35
1PH
1PH7163-2NG00-0BJ0 1PH7163-2NG00-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 36 KW, 2000 RPM, 171.9 NM, VC: 38 KW, 2300 RPM, 157.8 NM, 85 A VC: 82 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH
1PH
1PH6103-4NG46 1PH6103-4NG46 SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 7 KW, 2000 REV/MIN, 33 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B35
1PH
1PH7224-2NF00-0DJ0 1PH7224-2NF00-0DJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 100 KW, 1500 RPM, 636.6 NM, 188 A, W/O BRAKE; WITH FAN, PG CABLE ENTRY; REL. MOTOR ENCODER 1 VPP 2048 R/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 BEARING F. COUPLING OUTPUT, VIBRATION SEVERITY GRADE SR, SHAFT A. FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, PRIMED
1PH
1PH7137-2NG00-0BJ0 1PH7137-2NG00-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 28 KW, 2000 RPM, 133.7 NM, VC: 29 KW, 2300 RPM, 120.4 NM 60 A, VC: 56 A, W/O BRAKE, 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, WITHOUT PAINT FINISH
1PH
1PH7167-2NF03-0DA0 1PH7167-2NF03-0DA0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 37 KW, 1500 RPM, 235.5 NM, VC: 41 KW, 1750 RPM, 223.7 NM, 82 A, VC: 79 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE SR, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + HALF-KEY BALANCING AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH
1PH
1PH4163-4NF26 1PH4163-4NF26 SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V, 37 KW, 235 NM, 1500 RPM, WATER-COOLED, IP65, SHAFT GLAND IP55, ENCODER 1 VPP 2048 INCR/REV, IM B35, TERMINAL BOX, SIGNAL CONNECTOR
1PH
1PH7184-2NE00-0AJ0 1PH7184-2NE00-0AJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 40 KW 1250 RPM, 306 NM, 85 A W/O BRAKE WITH FAN, PG CABLE ENTRY; REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 BEARING F. COUPLING OUTPUT, VIBRATION SEVERITY GRADE R, SHAFT A. FLANGE ACCURACY GR. N PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, PRIMED
1PH
1PH7186-2NE00-0AJ0 1PH7186-2NE00-0AJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 60 KW, 1250 RPM, 458.4 NM, 120 A, W/O BRAKE; WITH FAN, PG CABLE ENTRY; REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 BEARING F. COUPLING OUTPUT, VIBRATION SEVERITY GRADE R, SHAFT A. FLANGE ACCURACY GR. N PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, PRIMED
1PH
1PH5167-4CF40-Z 1PH5167-4CF40-Z SIEMENS AC MAIN SPINDLE MOTOR 34 KW AT 1500 REV/MIN 216 NM IM B 3
1PH
1PH6138-4NF06-Z 1PH6138-4NF06-Z SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 22 KW, 1500 REV/MIN, 140 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B 35
1PH
1PH7107-2NF33-0BJ0 1PH7107-2NF33-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 9 KW, 1500 RPM, 57.3 NM, VC: 10 KW, 1750 RPM, 54.6 NM, 23.5 A, VC: 23 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE LEFT DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH
1PH
1PH7137-2NG33-0BJ0 1PH7137-2NG33-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 28KW, 2000RPM, 133.7NM VC: 29KW, 2300RPM, 120.4NM 60A, VC: 56A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON LEFT DESIGN IM B35 (IM V15, IM V36) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED
1PH
1PH5161-4CF46-Z 1PH5161-4CF46-Z SIEMENS AC MAIN SPINDLE MOTOR 20 KW AT 1500 REV/MIN 127 NM IM B 35 INCLUDING ORDER CODE K04
1PH
1PH6138-1NF06-Z 1PH6138-1NF06-Z SIEMENS AC-HSA-MOTOR, ZK 600 V 22 KW, 1500 U/MIN, 140 NM FREMDBELUEFTET, OPT. INKR.,IP54 KLEMMENKASTEN, SIGNALSTECKER; MIT ERN 1381-GEBEREINBAU; BAUFORM IM B35; KLEMMENKASTEN; OBEN; KABELEINFUEHRUNG RECHTS; RUNDLAUFGENAUIGKEIT TOLERANZ N SCHWINGSTAERKE STUFE R BEI DOP- PELLAGERUNG; WELLENENDE AUF AS, MIT PASS- FEDER, AUSBLASRICHTUNG UNTEN; SCHUTZART IP 54
1PH
1PH7224-2NF23-0DC0 1PH7224-2NF23-0DC0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 100 KW, 1500 RPM, 636.6 NM, 188 A, W/O BRAKE; WITH FAN, PG CABLE ENTRY; REL. MOTOR ENCODER 1 VPP 2048 R/REV TERMINAL BOX ON TOP, CABLE ON NON-DRIVE END DESIGN IM B35 BEARING F. COUPLING OUTPUT, VIBRATION SEVERITY GRADE SR, SHAFT A. FLANGE ACCURACY GR. R FITTED KEY + FULL-KEY BALANCING AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, PRIMED
1PH
1PH7167-2NF00-0BA0 1PH7167-2NF00-0BA0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 37 KW, 1500 RPM, 235.5 NM, VC: 41 KW, 1750 RPM, 223.7 NM, 82 A, VC: 79 A, W/O BRAKE; 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT DESIGN IM B3 (IM V5, IM V6), VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + HALF-KEY BALANCING AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH
1PH
1PH5137-4CF46-Z 1PH5137-4CF46-Z SIEMENS AC MAIN SPINDLE MOTOR 15 KW AT 1500 REV/MIN 95 NM IM B 35
1PH
1PH7105-2NF02-0BJ0 1PH7105-2NF02-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 7 KW, 1500 RPM, 44.6 NM, VC: 8 KW, 1750 RPM, 43.7 NM, 17.5 A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH
1PH
1PH6167-1NF06-5BN0 1PH6167-1NF06-5BN0 SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 37 KW, 1500 REV/MIN, 236 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B35; TERMINAL BOX; RIGHT; CABLE INFEED/D-END; ROT. ACCURACY TOLERANCE R VIBRATION SEVERITY S WITH TWIN-BEARINGS; SHAFT END ON D-END, W/O FEATHER KEY , AIR FLOW DIR. BOTTOM; DEGREE OF PROT. IP 54
1PH
1PH7105-2NF02-0BC0 1PH7105-2NF02-0BC0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 7 KW, 1500 RPM, 44.6 NM, VC: 8 KW, 1750 RPM, 43.7 NM, 17.5 A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + FULL-KEY BALANCING AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH
1PH
1PH7105-2NF00-0BD0 1PH7105-2NF00-0BD0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 7 KW, 1500 RPM, 44.6 NM, VC: 8 KW, 1750 RPM, 43.7 NM, 17.5 A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B3 (IM V5, IM V6) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY GR. R FITTED KEY + FULL-KEY BALANCING AIR FLOW FROM NON-DRIVE END TO DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH
1PH
1PH7107-2NF02-0BJ0 1PH7107-2NF02-0BJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 9KW, 1500RPM, 57.3NM VC: 10 KW, 1750RPM, 54.6NM 23.5A, VC: 23A, WITHOUT BRAKE 400V 3AC 50HZ, WITH FAN REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R SMOOTH SHAFT WITHOUT FITTED KEY DIRECTION OF AIR FLOW FROM DE TO NDE IP55, FAN IP54 UNPAINTED
1PH
1PH5107-4CF40-Z 1PH5107-4CF40-Z SIEMENS AC MAIN SPINDLE MOTOR 6.5 KW AT 1500 REV/MIN 41 NM IM B 3
1PH
1PH6135-1NF46-0AA0 1PH6135-1NF46-0AA0 SIEMENS AC MAIN SPINDLE MOTOR, DC LINK 600 V 15 KW, 1500 REV/MIN, 95 NM SEPARATE VENTILATION, INCR. OPTICAL ENCODER, IP54, TERMINAL BOX, SIGNAL CONNECTOR; WITH ERN 1381 ENCODER FITT.; TYPE IM B35; TERMINAL BOX; ON TOP; CABLE INFEED/RIGHT; ROT. ACCURACY TOLERANCE N VIBRATION SEVERITY R WITH TWIN-BEARINGS; SHAFT END ON D-END, W. FEATHER KEY , AIR FLOW DIR. BOTTOM; DEGREE OF PROT. IP 54
1PH
1PH5101-4CF41 1PH5101-4CF41 SIEMENS AC MAIN SPINDLE MOTOR 3 KW AT 1500 REV/MIN 19 NM IM B 5 INCLUDING ORDER CODE K04
1PH
1PH5131-4CF44-Z 1PH5131-4CF44-Z SIEMENS AC MAIN SPINDLE MOTOR 9 KW AT 1500 REV/MIN 57 NM IB V 1 INCLUDING ORDER CODE K04
1PH
1PH7103-2NF02-0CJ0 1PH7103-2NF02-0CJ0 SIEMENS SIMOTICS M COMPACT INDUCTION MOTOR 5.5 KW, 1500 RPM, 35 NM, VC: 6.3 KW, 1750 RPM, 34.4 NM 13 A, W/O BRAKE 3AC 400 V 50 HZ, WITH FAN REL. MOTOR ENCODER 1 VPP 2048 P/REV TERMINAL BOX ON TOP, CABLE ON THE RIGHT SIDE DESIGN IM B5 (IM V1, IM V3) VIBRATION SEVERITY GRADE S, SHAFT AND FLANGE ACCURACY GR. R PLAIN SHAFT W/O FITTED KEY, AIR FLOW FROM DRIVE END TO NON- DRIVE END IP 55, FAN IP 54, W/O PAINT FINISH
1PH
1PH7224-2NF00-0FB3 1PH7224-2NF00-0FB3 SIEMENS SIMOTICS M COMPACT ASYNCHRONOUS MOTOR 100 KW, 1500 RPM, 636.6 NM 188 A, WITHOUT BRAKE WITH FAN CABLE GLAND ENTRY REL. MOTOR ENCODER 1 VSS 2048 P/U TERMINAL BOX ON TOP, CABLE ON RIGHT TYPE OF CONSTRUCTION IM B3 BEARING FOR BELT OUTPUT VIBRATION SEVERITY GRADE R, SHAFT AND FLANGE ACCURACY R FITTED KEY + HALF-KEY BALANCING DIRECTION OF AIR FLOW FROM NDE TO DE IP55, FAN IP54 STANDARD PAINT FINISH (RAL 7016)
