Roary a. Angled Measurement Systems

ROD 426E-720 ID.-NR. 232956-0H HEIDENHAIN INCREMENTAL ROTARY ENCODER LINE COUNT 720, ELECTRICAL CONNECTION 01 FREE CABLE END AXIAL 1,00 M, OUTPUT SIGNAL TTL SQUARE-WAVE SIGNALS TTL LEVELS

ROD 426-3000-02S12-03 ID.-NR 295434-CM HEIDENHAIN INCREMENTAL ROTARY ENCODER OUTPUT SIGNALS SQUAREWAVE TTL, ELECTRICAL CONNECTION CABLE 6M WITH CONNEC. RADIAL

ROD 456RA 500I ID.-NR. 376856-E6 HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT 500 OUTPUT SIGNAL 11µAPP, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 9-PIN, RADIAL

ROD 250-9000 ID.-NR. 213116-27 HEIDENHAIN INCREMENTAL ANGLE ENCODER LINE COUNT 9000, OUTPUT SIGNAL SINUSOIDAL CURRENT SIGNALS 11µ ASS, ELECTRICAL CONNECTION 01 FREE CABLE END, RADIAL 1,00 M

ROD 250.0000-9000 ID.-NR. 213116-53 HEIDENHAIN INCREMENTAL ANGLE ENCODER LINE COUNT 9000, OUTPUT SIGNAL 11µASS SINUSOIDAL CURRENT SIGNALS, ELECTRICA CONNECTION 02S09 CONNECTOR, MALE 9-PIN, CABLE OUTLET RADIAL 4,00 M

ROD 2700009-18000 ID.-NR. 311849-04 HEIDENHAIN INCREMENTAL ANGLE MEASURING SYSTEM WITH INTERGRIERTER 5-FOLD INTERPOLATION LINE COUNT 18000, ELECTRICAL CONNECTION 01 FREE CABLE END, CONNECTION DIRECTION R RADIAL,  OUT PUT SIGNAL TTLX5 SQUARE-WAVE SIGNALS, TTL LEVELS WITH 5-FOLD INTERPOLATION

ROD 270-18000 02S12-03 ID.-NR. 512131-04 HEIDENHAIN INCREMENTAL ANGLE ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT 18000, OUTPUT SIGNAL TTLX5, ELECTRICAL CONNECTION FREE CABLE END, CABLE OUTLET FOR AXIAL AND RADIAL USE 1,00 M

ROD 250.0000-6000 ID.-NR. 213116-88 HEIDENHAIN INCREMENTAL ANGLE ENCODER LINE COUNT 6000, OUTPUT SIGNAL 11µ SINUSOIDAL CURRENT SIGNALS, ELECTRICAL CONNECTION 02S09 CONNECTOR, MALE 9-PIN, CABLE OUTLET RADIAL 5,00 M

ROD 260-18000 HEIDENHAIN INCREMENTAL ROTARY ENCODER

RON 225.5001-18000 ID.-NR. 262763-01 HEIDENHAIN INCREMENTAL ANGLE ENCODER WITH HOLLOW SHAFT COUT LINE: 18000, OUTPUT SIGNAL TTL SQUARE-WAVE SIGNALS, TTL LEVELS, REFERENCE MARK: ONE, ELECTRICAL CONNECTION CABLE 1M WITH PLUG, CONNECTION DIRECTION: RADIAL

RON 255C-18000-02S09-04 ID.-NR. 358697-79 HEIDENHAIN INCREMENTAL ANGLE ENCODER WITH INTEGRAL BEARING AND INTEGRATED STATOR COUPLING LINE COUNT: 18000, SYSTEM ACCURACY: ±5.0'', OUTPUT SIGNAL: ~11µAPP, REFERENCE MARK: ANALOG, REF. MARK CODED, NOMINAL INCREMENT 1000, ELECTRICAL CONNECTION: CONNECTOR M23, MALE, 9-PIN, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE CABLE LENGTH: 5,00 M

RCN 8380 ID.-NR. 667596-01 HEIDENHAIN ABSOLUTE ANGLE ENCODER (SINGLETURN) WITH INTEGRAL BEARING AND INTEGRATED STATOR COUPLING SYSTEM ACCURACY: ±2.0'', DATA INTERFACE: ENDAT02, POSITIONS PER REVOLUTION: 536870912 OUTPUT CODE: DUAL LINE COUNT: 32768 OUTPUT SIGNAL: ~1VPP, ELECTRICAL CONNECTION: FLANGE SOCKET ULTRA-LOCK, MALE, 12-PIN, CONNECTING DIRECTION: TANGENTIAL

ROD 1250B-1024/18000 I/U ID.NR. 276211-01 HEIDENHAIN INCREMENTAL ENCODER WITH DUAL TRACK SCANNING, TRACK 1 - 1024 LINES, SQUARE WAVE SIGNAL TRACK 2 - 18000 LINES, SINUSOIDAL SIGNAL CABLE OUTLET RADIAL, CABLELENGTH 0,19 M

ROQ 425.5DSK-13B12 ID.-NR. 295557-01 HEIDENHAIN ABSOLUT MULTITURN ROTARY ENCODER LINE COUNT 2048, DIFFERENTIABLE REVOLUTIONS 4096, POSITION PER REV 8192, OUTPUT CODE DUAL-CODE, SHAFT DIMENSIONS 10 MM, DATA INTERFACE ENDAT01 SYNCHRONOUS ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS ENDAT 2.1 OT 2.2 COMMAND SET, ELECTRICAL CONNECTION 03S17 COUPLING MALE 17-PIN, CONNECTION DIRECTION RADIAL

ROD 426-1250-03S12-03 ID.-NR. 376846-E5 HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT: 1250 OUTPUT SIGNAL: TTL, ELECTRICAL CONNECTION: COUPLING, MALE 12-PIN, CABLE OUTLET FOR AXIAL AND RADIAL USE 1,00 M

ROD 426B-1250 I/U ID.-NR. 254204-0X HEIDENHAIN INCREMENTAL ROTARY ENCODER LINE COUNT 1250, KABELLÄNGE 1,00 M

ROD 660-77.622.002-500 I/U HEIDENHAIN INCREMENTAL ROTARY ENCODER

ROD 426-3600 ID.-NR. 376846-7S HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT: 3600, OUTPUT SIGNAL: TTL, ELECTRICAL CONNECTION: FREE CABLE END, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE, CABLE LENGTH: 3.00 M

ROD 456-4500 I/U ID.-NR. 376856-F7 HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT: 4500 OUTPUT SIGNAL: ~11µAPP, ELECTRICAL CONNECTION: FREE CABLE END, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE CABLE LENGTH: 5.00 M

ROD 426-600 I/U ID.-NR. 223675-66 HEIDENHAIN INCREMENTAL ROTARY ENCODER LINE COUNT 600, OUTPUT SIGNAL TTL SQUARE-WAVE SIGNALS, TTL LEVELS, REFERENCE SIGNAL RV GATED WITH UA1 AND UA2, ELECTRICAL CONNECTION 01 FREE CABLE END, CONNECTION DIRECTION AXIAL, CABLE LENGTH AXIAL

ROD 426E-1800 ID.-NR. 249884-13 HEIDENHAIN INCREMENTAL ROTARY ENCODER LINE COUNT 1800, OUTPUT SIGNAL TTL SQUARE-WAVE SIGNALS, ELECTRICAL CONNECTION 27S12 FLANGE SOCKET MALE 12-PIN, CONNECTION DIRECTION RADIAL

ROD 420D-2500 ID.-NR. 256455-08 HEIDENHAIN INCREMENTAL ROTARY ENCODER LINE COUNT 2500

ROD 426-600 ID.-NR. 376846-0N HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT: 600 OUTPUT SIGNAL: TTL, ELECTRICAL CONNECTION: FREE CABLE END, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE CABLE LENGTH: 3.00 M

ERN 421-1800 I/U ID.-NR. 538723-12 HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR MOUNTING BY STATOR COUPLING LINE COUNT 1800, OUTPUT SIGNAL TTL, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 17-PIN, CANON MODEL, CABLE OUTLET FOR AXIAL AND RADIAL USE

ROD 436-180 ID.-NR. 376836-65 HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT: 180 OUTPUT SIGNAL: HTL, ELECTRICAL CONNECTION: FREE CABLE END, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE CABLE LENGTH: 1.00 M

ROD 426-2000 ID.-NR. 376846-0C HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT: 2000 OUTPUT SIGNAL: TTL, ELECTRICAL CONNECTION: FREE CABLE END, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE, CABLE LENGTH: 1.00 M

ROD 456-500 I/U ID.-NR. 376856-5N HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT: 500 OUTPUT SIGNAL: ~11µAPP, ELECTRICAL CONNECTION: CONNECTOR M23, MALE, 9-PIN, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE CABLE LENGTH: 0.20 M

ROD 426-2048 ID.-NR. 376846-0H HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT: 2048, OUTPUT SIGNAL: TTL, ELECTRICAL CONNECTION: CONNECTOR M23, MALE, 12-PIN, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE CABLE LENGTH: 1.00 M

ROD 426-5000-02S12-03 ID.-NR. 295436-19 HEIDENHAIN INCREMENTAL ROTARY ENCODER LINE COUNT 5000, ELECTRICAL CONNECTION 02S12 CONNECTOR MALE 12-PIN AXIAL 5,00M. OUTPUT SIGNAL TTL SQUARE-WAVE SIGNALS TTL LEVELS

ERN 480-4096-27S12-03 ID.-NR. 385480-49 HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR MOUNTING BY STATOR COUPLING LINE COUNT 4096 OUTPUT SIGNAL 1VPP, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 12-PIN, CABLE OUTLET RADIAL

ERN 1381- 1024 I/U ID.-NR. 534118-05 HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR MOUNTING BY STATOR COUPLING LINE COUNT 1024, OUTPUT SIGNAL 1VPP, ELECTRICAL CONNECTION PLUG CONNECTOR, STRAIGHT, DOUBLE-ROW, 12-PIN, WITH LOCKING MECHANISM AND WALLS, CABLE OUTLET FOR AXIAL AND RADIAL USE

RCN 226-16384 03S17-7V ID.-NR. 533110-02 HEIDENHAIN ABSOLUTE ANGLE ENCODER (SINGLETURN) WITH INTEGRAL BEARING AND INTEGRATED STATOR COUPLING SYSTEM ACCURACY: ±5.0'', DATA INTERFACE: ENDAT02, POSITIONS PER REVOLUTION: 67108864, OUTPUT CODE: DUAL, LINE COUNT: 16384, OUTPUT SIGNAL: ~1VPP, ELECTRICAL CONNECTION: COUPLING, MALE 17-PIN, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE, CABLE LENGTH: 1.00 M

ROD 429 - 1024 ID.-NR. 514777-94 HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT 1024 OUTPUT SIGNAL TTL, ELECTRICAL CONNECTION FLANGE SOCKET, MALE, 12-PIN WITH POLARIZING PIN, RADIAL

ROD 426-1024 ID.-NR. 376846-1W HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT: 1024, OUTPUT SIGNAL: TTL, ELECTRICAL CONNECTION: COUPLING, MALE 12-PIN, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE, CABLE LENGTH: 5.00 M

ROD 1424.039B/1250 ID.-NR. 297252-03 HEIDENHAIN INCREMENTAL ROTARY ENCODER IN CAST-METEL HOUSING LINE COUNT 1250, OUTPUT SIGNAL TTL SQUARE-WAVE SIGNALS TTL LEVELS, ELECTRICAL CONNECTION 27S12 FLANGE SOCKET, MALE 12PIN WITH POLARIUING PIN RADIAL

RON 705-18000-02S09-04 ID.-NR. 355879-01 HEIDENHAIN INCREMENTAL ANGLE ENCODER WITH INTEGRAL BEARING AND INTEGRATED STATOR COUPLING LINE COUNT: 18000; SYSTEM ACCURACY: ±2.0''; OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP), REFERENCE MARK: ANALOG, ELECTRICAL CONNECTION: CONNECTOR M23, MALE, 9-PIN, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE CABLE LENGTH: 1.00 M

ROD 450-1000 I/U ID.-NR. 376850-78 HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT 1000 OUTPUT SIGNAL ~11µAPP, ELECTRICAL CONNECTION CONNECTOR, MALE, 9-PIN, CABLE OUTLET FOR AXIAL AND RADIAL USE 1,00 M

ECN 223 F-2048 I/U ID.-NR. 536301-01  HEIDENHAIN ABSOLUTE ANGLE ENCODER (SINGLETURN) WITH INTEGRAL BEARING FOR MOUNTING BY STATOR COUPLING SYSTEM ACCURACY: ± 10.0'', DATA INTERFACE: FANUC02 SERIAL INTERFACE, POSITIONS PER REVOLUTION: 8388608, OUTPUT CODE: DUAL, SHAFT: HOLLOW THROUGH SHAFT WITH ECCENTRIC CLAMPING, DIAMETER 50 MM, ELECTRICAL CONNECTION: COUPLING, MALE 17-PIN, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE CABLE LENGTH: 3.00 M

ROD 426.009-5000 ID.-NR. 211515-27 HEIDENHAIN INCREMENTAL ROTARY ENCODER LINE COUNT 5000, ELECTRICAL CONNECTION 07B12 SOURIAU COUPLING FEMALE 12 PIN AXIAL, OUTPUT SIGNAL TTL SQUARE-WAVE SIGNALS TTL LEVELS

ROD 280-18000 03S12-03 ID.-NR. 512132-05 HEIDENHAIN INCREMENTAL ANGLE ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT 18000, OUTPUT SIGNAL ~1VPP, ELECTRICAL CONNECTION COUPLING, MALE 12-PIN CABLE OUTLET FOR AXIAL AND RADIAL USE

ROD 420-250 I/U ID.-NR. 376840-37 HEIDENHAIN INCREMENTAL ROTARY ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT: 250 OUTPUT SIGNAL: TTL, ELECTRICAL CONNECTION: FREE CABLE END, CABLE OUTLET FOR AXIAL AND RADIAL USE

ROD 1424.003-1024 ID.-NR. 250040-24 HEIDENHAIN INCREMENTAL ROTARY ENCODER LINE COUNT 1024, OUTPUT SIGNALS TTL, CABLE OUTLET AXIAL

ROD 1424.039B/500 ID.-NR. 297252-05 HEIDENHAIN INCREMENTAL ROTARY ENCODER IN CAST-METEL HOUSING LINE COUNT 500, OUTPUT SIGNAL TTL SQUARE-WAVE SIGNALS, TTL LEVELS, ELECTRICAL CONNECTION 27C12 FLANGE SOCKET, MALE, 12-PIN WITH POLARIZING PIN

ROD 270-18000 01ID.-NR 331882-01 HEIDENHAIN INCREMENTAL ANGLE ENCODER WITH INTEGRATED COUPLING AND 5-FOLD INTERPOLATION LINE COUNT 18000, OUTPUT SIGNAL TTLX5 SQUARE-WAVE SIGNALS, TTL LEVELS, ELECTRICAL CONNECTION 01 FREE CABLE END, CABLE OUTLET AXIAL AND RADIAL AVAILABEL 5,50 M

ECN 413-2048-03S17-58 ID.-NR. 586645-14 HEIDENHAIN ROTARY ENCODER WITH INTEGRAL BEARING POSITIONS PER REVOLUTION: 8192, DATA INTERFACE: ENDAT01 SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, OUTPUT CODE: DUAL, LINE COUNT: 2048, OUTPUT SIGNAL: ~1VPP, SHAFT: BLIND HOLLOW SHAFT WITH CLAMPING RING, DIAMETER 12 MM, DEPTH 24 MM, ELECTRICAL CONNECTION: COUPLING, MALE 17-PIN, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE, CABLE LENGTH: 1.00 M

ROD 750-18000-01-04 ID.-NR. 377555-04 HEIDENHAIN INCREMENTAL ANGLE ENCODER WITH INTEGRAL BEARING FOR SEPARATE SHAFT COUPLING LINE COUNT 18000, ELECTRICAL CONNECTION FREE CABLE END, CABLE OUTLET FOR AXIAL AND RADIAL USE 1,00 M

RON 786C-36000-03S12-03 ID.-NR. 355884-22 HEIDENHAIN INCREMENTAL ANGLE ENCODER WITH INTEGRAL BEARING AND INTEGRATED STATOR COUPLING LINE COUNT: 36000 SYSTEM ACCURACY: ±2.0'' OUTPUT SIGNAL: SINUSOIDAL VOLTAGE SIGNALS (1 VPP), REFERENCE MARK: ANALOG, REF. MARK CODED, NOMINAL INCREMENT 1000, ELECTRICAL CONNECTION: COUPLING, MALE 12-PIN, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE CABLE LENGTH: 3.00 M

RON 275-18000-03S12-03 ID.-NR. 358698-60 HEIDENHAIN INCREMENTAL ANGLE ENCODER WITH INTEGRAL BEARING AND INTEGRATED STATOR COUPLING LINE COUNT: 18000, SYSTEM ACCURACY: ±5.0'', OUTPUT SIGNAL: TTLX10, REFERENCE MARK: 90°, ELECTRICAL CONNECTION: COUPLING, MALE 12-PIN, CONNECTING DIRECTION: CABLE OUTLET FOR AXIAL AND RADIAL USE, CABLE LENGTH: 1.00 M

ERN 1387.003-2048 ID.-NR. 312215-67 HEIDENHAIN INCREMENTAL ROTARY ENCODER FOR INTEGRATION WITH COMMUTATION SIGNALS LINE COUNT 2048, ANALOGUE OUTPUT SIGNALS 1,1 VPP SINUSOIDAL VOLTAGE SIGNALS, ELECTRICAL CONNECTION 62S14 PCB CONNECTOR, MALE 14-PIN, CABLE OUTLET FOR AXIAL AND RADIAL USE

EQN 1325-2048 ID.-NR. 312214-54 HEIDENHAIN MODULAR-ROTARY-ENCODER SHAFT DIMENSIONS 19 TAPER SHAFT 1:10, FUNCTIONAL DIAMETER 9,25 MM, CODE OF OUTPUT D PURE BINARY, DATA INTERFACE ENDAT01 SYNCHRONOUS SERIAL ENDAT 2.1 WITH INCREMENTAL SIGNALS, MODE COMMANDS, ENDAT 2.1 OR 2.2 COMMAND SET, OUTPUT SIGNAL 1VSS SINUSOIDAL VOLTAGE SIGNALS, ELECTRICAL CONNECTION 62S12 PCB CONNECTOR MALE 12-PIN, CONNECTION DIRECTION AXIAL AND RADIAL CABLE EXITS AVAILABLE
