ND 550 ID.-NR. 276608-02 HEIDENHAIN STANDARD DISPLAY UNITS FOR 3 AXES WITH 4-FOLD SUBDIVISION FUNCTIONS: 2 DATUM POINTS MM/INCH CONVERSION RADIUS/DIAMETER DISPLAY SETUP FUNCTION "EDGE" AND "CENTERLINE" (WITH TOOL) SHRINKAGE COMPENSATION

ND 730 ID.-NR. 339729-02 HEIDENHAIN NUMERICAL DISPLAY UNIT FOR LATHES WITH 2 AXES FOR ENCODERS WITH SINUSOIDAL CURRENT SIGNALS SIGNAL SUBDIVISION : MAX. 1024-FOLD FUNCTIONS : 9 TOOLS RADIUS / DIAMETER DISPLAY TAPER CALCULATION MM/INCH CALCULATOR REFERENCE DISPLAY NON-LINEAR AXIS ERROR COMPENSATION OVER 64 POINTS

ND 280 ID.-NR. 636280-01 HEIDENHAIN DIGITAL READOUT FOR METROLOGY APPLICATIONS NUMBER OF ENCODER INPUTS: 1X NUMBER OF SLOTS: NONE POSITION ENCODER: 1VPP/11µAPP/ENDAT22 TYPE OF DISPLAY: TFT SCREEN MONOCHROM DATA INTERFACE: USB/RS

ND 750 ID.-NR. 339726-01 HEIDENHAIN NUMERICAL DISPLAY UNIT FOR 3 AXES FOR ENCODERS WITH SINUSOIDAL CURRENT SIGNALS SIGNAL SUBDIVISION : MAX. 20-FOLD FUNCTIONS : 2 DATUMS HOLE PATTERNS SETUP FUNCTIONS "EDGE SETTING" AND "CENTERLINE" (WITH TOOL) SHRINKAGE COMPENSATION MM/INCH CALCULATOR REFERENCE DISPLAY NON-LINEAR AXIS ERROR COMPENSATION OVER 16 POINTS

ND 770 ID.-NR. 339730-01 HEIDENHAIN NUMERICAL DISPLAY UNIT FOR LATHES WITH 3 AXES

ND 760 ID.-NR. 339728-02 HEIDENHAIN NUMERICAL DISPLAY UNIT NUMERICAL DISPLAY UNIT FOR 3 AXES ENCODERS WITH SINUSOIDAL CURRENT SIGNALS, SIGNAL SUBDIVISION : MAX. 1024-FOLD, FUNCTIONS : 9 DATUMS, HOLE PATTERNS, SETUP FUNTIONS "EDGE SETTING", "CENTERLINE" CIRCLE CENTER (WITH TOOL), SHRIKANGE COMPENSATION, MM/INCH CALCULATOR REFERENCE DISPLAY, NON-LINEAR AXIS ERROR COMPENSATION, OVER 64 POINTS, ACCESSORIES INCLUDED : POWER CONNECTOR

ND 7013 ID.-NR. 1089178-01 HEIDENHAIN DIGITAL READOUT FOR MANUAL OPERATED MACHINE TOOLS APPLICATION: MILLNG/TRNING DISPLAY: 7-INCH, COLOR, WIDE SCREEN (15:9), RESOLUTION 800 X 480 NUMBER OF ENCODER INPUTS: 3 ENCODER INTERFACE: 1VPP ENCODER CONNECTION: BUILT-IN D-SUB CONNECTOR WITHOUT HOUSING, 2-ROW, FEMALE, 15-PIN, FASTENING TYPE: 50 MM X 50 MM, 4 X M4, APPLICATION SOFTWARE: MANUALLY OPERATED MACHINE TOOL

ND 287 ID.-NR. 636287-01 HEIDENHAIN DIGITAL READOUT FOR METROLOGY APPLICATIONS, BASIC ID NUMBER OF 646118 FEATURES: LENGTH, SOFTWARE 1: ANGLE, ERROR COMPENSATION, AXIS COMPENSATION AND STATISTICS NUMBER OF ENCODER INPUTS: 1X, 1X OPTIONAL NUMBER OF SLOTS: POSITION ENCODER: 1VPP/11µAPP/ENDAT22 TYPE OF DISPLAY: TFT SCREEN COLOR DATA INTERFACE: MULTI

PT 850D ID.-NR. 265320-01 HEIDENHAIN POSITIP 850 PROGRAMMABLE DISPLAY UNIT WITH PROGRAMMING MEMORY AND CRT DISPLAY FOR CONNECTION TO ENCODERS WITH GRATING PERIOD FROM 0,004 TO 0,200 MM INCLUDING POWER CABLE, LENGTH 3 M (10 FT)

ND 5023 ID.-NR. 1197249-01 HEIDENHAIN DIGITAL READOUT FOR MANUAL OPERATED MACHINE TOOLS FOR TURNING, MILLING AND GENERAL APPLICATIONS NUMBER OF ENCODER INPUTS:3X ENCODER INTERFACE: ENCODER CONNECTION: BUILT-IN D-SUB CONNECTOR WITHOUT HOUSING, 2-ROW, FEMALE, 9-PIN DISPLAY: 7-INCH, COLOR, WIDE SCREEN (15:9), RESOLUTION 800 X 480 USER INTERFACE: MEMBRANE KEYBOARD DATA INTERFACE: USB TYPE C FASTENING TYPE: VESA MIS-D, 100

PT 855 ID.-NR. 278730-01 HEIDENHAIN DISPLAY UNIT FOR 4 AXES WITH FLAT SCREEN FOR LINEAR AND ROTARY AXES POSITIP 855

ND 282 ID.-NR. 283001-11 HEIDENHAIN DISPLAY UNIT WITH 200-FOLD SUBDIVISION AND ADVANCED FEATURES, DATA INTERFACE BCD, FUNDTIONS 2 DATUM POINTS MM/INCH CONVERSION SORTING AND TOLERANCE CHECKING MINIMUM/MAXIMUM-MEMORY TRIGGERING SIGNAL INPUTS AND OUTPUTS

ND 1102 ID.-NR 665405-08 HEIDENHAIN DIGITAL READOUT FOR METROLOGY APPLICATIONS ELECTRICAL CONNECTION BUILT-IN D-SUB CONNECTOR WITHOUT HOUSING, 2-ROW, FEMALE, 9-PIN, TOUCH PROBE INPUTS PROBE INTERFACE, DIN FLANGESOCKET, FEMALE, 5-PIN, SWITCH SIGNAL FOOT SWITCH AND REMOTE  KEYPAD INPUT, RJ-45

ND 1302 ID.-NR. 665407-03 HEIDENHAIN DIGITALE ANZEIGE FÜR MESSANWENDUNGEN ANWENDUNG 2D-ANZEIGETYP: TOUCHSCREEN-FARBE, ANZAHL DER ENCODER-EINGÄNGE 2X EINGANGSSIGNAL: ~1VPP, INTERPOLATIONSFAKTOR SKALENSIGNAL MIT 10 MULTIPLIZIEREN. ELEKTRISCHER ANSCHLUSS: EINBAU-D-SUB-STECKER OHNE GEHÄUSE, 2-REIHIG, BUCHSE, 15-POLIG, SCHALTSIGNAL EINGANG FÜR FUßSCHALTER UND FERNBEDIENUNG, RJ-45

POTENTIOMETER ID.-NR. 385502-05 HEIDENHAIN POTENTIOMETER MIT ZUBEHÖR

POTENTIOMETER ID.-NR. 322500-01 HEIDENHAIN POTENTIOMETER 10K LIN KPL.

POTENTIOMETER ID.-NR. 322144-01 HEIDENHAIN POTENTIOMETER ACHSE ... 1,00 KOHM ...

POTENTIOMETER ID.-NR. 322772-01 HEIDENHAIN POTENTIOMETER 1K0 LIN KPL. CNC5000/VME

POTENTIOMETER ID.-NR. 385502-09 HEIDENHAIN POTENTIOMETER S WITH ACCESSORIES

POTENTIOMETER ID.-NR. 330595-04  HEIDENHAIN POTENTIOMETER LÄNGE 190MM

POTENTIOMETER ID.-NR. 235525-01 HEIDENHAIN POTENTIOMETER ACHSE CERMET 3W... 10,00 KOHM 10 % …

ZWISCHENPLATTE ID.-NR. 579017-01 HEIDENHAIN INTERMEDIATE PLATE

MEMBRANKUPPLUNG K01 ID.-NR. 200301-02 HEIDENHAIN HIGH-PRECISION DIAPHRAGM COUPLING K01

MEMBRANKUPPLUNG K17/03 ID.-NR. 296746-03 HEIDENHAIN DIAPHRAGM COUPLING K17/03 HUB SHAFT DIAMETER: DIAMETER 1 = 10,000 MM, DIAMETER 2 = 10,000 MM, LENGTH: 30 MM, WITH SCREWDRIVER 2,5MM (202500-04)

FÜHRUNGSSCHIENE ID.-NR. 209820-02 HEIDENHAIN FÜHRUNGSSCHIENE 160X 2,0 - PPE GR

MODUL A1101 PE192X ID.-NR. 322521-01 HEIDENHAIN MODUL

MODUL A701 PE1927 ID.-NR. 322522-01 HEIDENHAIN MODUL A701 PE1927

MESSSYSTEMWEICHE ID.-NR. 211526-01 HEIDENHAIN ENCODER COMBINER ENABLES OPTIONAL OPERATION OF TWO MEASURING SYSTEMS ON ONE INTERFACE ELECTRONICS UNIT. SWITCHING OCCURS VIA EXTERNAL ACTIVATION OF A RELAY.

ADAPTERKABEL APK 02 03 ID.-NR. 270420-06 HEIDENHAIN ADAPTER CABLE FOR DIFFERENT CONNECTOR CONNECTION CABLE TYPE: PUR Ø 6.0 MM, CABLE LENGTH: 6.00 M ENCODER SIDE: LS SOCKET, SMALL, 8-PIN SIDE OF SUBSEQUENT D-SUB CONNECTOR, 2-ROW, ELECTRONIC: WITH LOCKING SCREWS, MALE, 9-PIN

FAGOR MASSSTABKABEL MIT 3 METER SCHUTZSCHLAUCH

ADAPTERKABEL APK 02 05 ID.-NR. 533631-05 HEIDENHAIN ADAPTER CABLE FOR DIFFERENT CONNECTOR CONNECTION CABLE TYPE: PUR Ø 6.0 MM, CABLE LENGTH: 5.00 M ENCODER SIDE: APPLIANCE CONNECTOR M12, 14-PIN SIDE OF SUBSEQUENT ELECTRONIC: COUPLING, MALE 17-PIN

ADAPTERKABEL APK 01 03 ID.-NR. 545547-06 HEIDENHAIN ADAPTER CABLE FOR DIFFERENT CONNECTOR CONNECTION CABLE TYPE: PUR Ø 4.5 MM, CABLE LENGTH: 6.00 M, ENCODER SIDE: APPLIANCE CONNECTOR M12, 14-PIN SIDE OF SUBSEQUENT CONNECTOR, M.D. RIBBON, ELECTRONIC: LOCKING MECHANISM USING LATCH, FEMALE, 15-PIN IN HOUSING 20-PIN

VERBINDUNGSKABEL 7POL. ID.-NR. 214001-01 HEIDENHAIN CABLE ADAPTER FOR TNC

ADAPTERKABEL APK 02 05 ID.-NR. 360974-20 HEIDENHAIN ADAPTER CABLE FOR DIFFERENT CONNECTOR CONNECTION CABLE TYPE: PUR Ø 6.0 MM CABLE LENGTH: 20.00 M ENCODER SIDE: APPLIANCE CONNECTOR M12, 14-PIN SIDE OF SUBSEQUENT D-SUB CONNECTOR, 2-ROW, ELECTRONIC: WITH LOCKING SCREWS, FEMALE, 15-PIN

ADAPTERKABEL APK 02 05 ID.-NR. 360974-15 HEIDENHAIN ADAPTER CABLE FOR DIFFERENT CONNECTOR CONNECTION CABLE TYPE: PUR Ø 6.0 MM, CABLE LENGTH: 15.00 M ENCODER SIDE: APPLIANCE CONNECTOR M12, 14-PIN SIDE OF SUBSEQUENT D-SUB CONNECTOR, 2-ROW, ELECTRONIC: WITH LOCKING SCREWS, FEMALE, 15-PIN

ADAPTERKABEL 46B012 ID.-NR. 369124-02 HEIDENHAIN ADAPTER CABLE LS CONNECTOR, LARGE, 12-PIN COUPLING, MALE 17-PIN CABLE TYPE: PUR Ø 6.0 MM, CABLE LENGTH: 2.00 M

VERBINDUNGSKABEL VBK 03 ID.-NR. 298400-06 HEIDENHAIN CONNECTING CABLE FOR ENCODER CONNECTION, CABLE TYPE: PUR Ø 8.0 MM, CABLE LENGTH: 6.00 M, ENCODER SIDE: COUPLING M23, FEMALE, 12-PIN, SIDE OF SUBSEQUENT ELECTRONIC: CONNECTOR M23, MALE, 12-PIN

MT 12 ID.-NR. 243602-06 HEIDENHAIN INCREMENTAL LENGTH GAUGE HEIDENHAIN-METRO ACCURACY GRADE: 0.5 µM, ELECTRICAL CONNECTION: CONNECTOR M23, MALE, 9-PIN, CABLE LENGTH: 1.50 M>, OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP)

MT 25 ID.-NR. 243603-07 HEIDENHAIN INCREMENTAL LENGTH GAUGE HEIDENHAIN-METRO ACCURACY GRADE: 0.5 µM, ELECTRICAL CONNECTION: CONNECTOR M23, MALE, 9-PIN, CABLE LENGTH: 1.50 M>, OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP)

MT 10 HEIDENHAIN INCREMENTAL LENGTH GAUGE

MT 2571 ID.-NR. 331667-01 HEIDENHAIN INCREMENTAL LENGTH GAUGE HEIDENHAIN-METRO ACCURACY GRADE: 0.2 µM, ELECTRICAL CONNECTION: D-SUB CONNECTOR, 2-ROW, WITH LOCKING SCREWS, WITH INTEGRATED ELECTRONICS, COATED, MALE, 15-PIN, CABLE LENGTH: 1.50 M, OUTPUT SIGNAL: SQUARE-WAVE SIGNALS, TTL LEVELS WITH 5-FOLD INTERPOLATION

MT 25W HEIDENHAIN INCREMENTAL LENGTH GAUGE

TS 512 ID.-NR. 236346-01 HEIDENHAIN TOUCH PROBE

ST 1277 ID.-NR. 355914-02 HEIDENHAIN LENGTH GAUGE SYSTEM ACCURACY: +/-0,001MM, ELECTR. CONNECTION: CABLE 1,5M WITH D-SUB- CONNECTOR, MALE 15-POLIG, OUTPUT SIGNALS: SQUARE WAVE SIGNALS TTL, CABLE EXIT: AXIAL

MT 25 P ID.-NR. 232715-03 HEIDENHAIN INCREMENTAL LENGTH GAUGE HEIDENHAIN-METRO ACCURACY GRADE: 0.5 µM, ELECTRICAL CONNECTION: CONNECTOR M23, MALE, 9-PIN, CABLE LENGTH: 1.50 M>, OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP)

TS 632 ID.-NR. 331397-18 HEIDENHAIN SWITCHING 3D-TOUCH PROBE FOR WORKPIECE MEASUREMENT OUTPUT SIGNAL: INFRARED TRANSMISSION DIRECTION OF BEAM IN DEGREES: 0, TOOL HOLDER: DIN 69871; SK-A 40; M16

TS 640 ID.-NR. 359575-01 HEIDENHAIN SWITCHING 3D-TOUCH PROBE FOR WORKPIECE MEASUREMENT OUTPUT SIGNAL: INFRARED TRANSMISSION DIRECTION OF BEAM IN DEGREES: +30, POWER SUPPLY: 2 X SIZE C, TOOL HOLDER: DIN 69871; SK-AD/B 40; M16

MT 60K ID.-NR. 311784-02 HEIDENHAIN INCREMENTAL LENGTH GAUGE ACCURACY GRADE 0,5 µM, ELECTRICAL CONNECTION 02S09 CONNECTOR MALE 9-PIN, CABLE LENGTH 1,50 M, OUTPUT SIGNAL 11µAPP SINUSOIDAL CURRENT SIGNALS

MT 60M HEIDENHAIN INCREMENTAL LENGTH GAGE

MT 12B ID.-NR. 243602-16 HEIDENHAIN INCREMENTAL LENGTH GAUGE HEIDENHAIN-METRO ACCURACY GRADE: 0.5 µM, ELECTRICAL CONNECTION: CONNECTOR M23, MALE, 9-PIN, CABLE LENGTH: 1.50 M>, OUTPUT SIGNAL: SINUSOIDAL CURRENT SIGNALS (11 µAPP)
